- Page 1 Bamboo Clamp-on Keyboard Tray SKU: MOUNT-KB05O Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/mount-kb05e...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 Package Contents B (x2) A (x1) Slider Bracket Keyboard Tray D (x2) C (x2) Clamp Included Hardware & Tools S-A (x8) S-B (x8) M4x7mm Screw ST5x14mm Screw Tools Needed: Weight Capacity: 11lbs (5kg) Phillips Screwdriver...
-
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Attach Slider Brackets (B) to Keyboard Tray (A) using ST5x14mm Screws (S-B), and tighten with a Phillips screwdriver. Note: With the Tray flipped upside-down, the Bracket with the “R” sticker will go on the left side of the assembly, and the Bracket with the “L” sticker will go on the right. The Slider Brackets (B) should protrude from the back of the Keyboard Tray. - Page 5 STEP 2 Choosing Assembly Method Tray features two assembly options based on the desired extension distance. Extended Standard Standard Extended Tray will extend 9” (23cm) from desktop Tray will extend 10”(25.4cm) from edge when extended. desktop edge when extended. *Ensure you have 12” under desk clearance *Tray will remain partially extended free of obstacles for tray to fully retract.
- Page 6 STEP 3 Loosen Clamps (C) and place Pads (D) on the underside of each Clamp. Place assembled Keyboard Mount on the edge of the desk and tighten Clamps to secure. Slide keyboard tray forward/back as desired. Tray locks at fully extended position and at fully stored position.
- Page 7 [ THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK]...
- Page 8 LAST UPDATED: 12/19/24 REV2 v1.2 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
