When the product is installed, apply a wrench to the outside of the piping connection while paying
attention that it will not come into contact with the coil.
5. Do not warm the coil section with a heat insulator, etc.
When insulation is used as a countermeasure against freezing, the insulation should be limited to the
piping and body only. Do not insulate the coil. This can cause the coil to burn out.
6. If air leakage increases or equipment does not operate properly, stop operation.
After installation or during maintenance, check that the product is correctly mounted with appropriate
functional and leakage inspections by supplying compressed air and power supplies. Do not use the
product when the equipment does not operate correctly.
7. Do not touch the valve while it is being energized or right after it has been energized.
Valves will reach high temperatures after operation. Use caution, as there is a danger of being burnt if
a valve is touched directly.
Caution
1. Painting and coating
Warnings or specifications printed or labeled on the product should not be erased, removed, or covered up.
6. How to Assemble Brackets
Caution
1. Body material: Stainless steel (N.C. specification, Port size: 1/8,
N.O. specification, Port size:1/8〜3/8）, Brass, Aluminum
How to assemble
1) Mount the bracket ① to the bottom of the valve using the mounting screws ②.
Tightening torque
Bracket Assembly Part Nos. (With mounting screws)
Size Body material
10 Brass, Stainless steel
Stainless steel
20
Brass, Stainless steel
30
20
Aluminum
30
∗1 Only N.O. specification is available.
2. Body material: Stainless steel (N.C. specification, Port size: 1/4, 3/8)
How to assemble
1) Insert the bracket ① into the IN port side of the valve.
2) Secure it with the hexagon socket head set screw ②.
Caution regarding assembly
1) Pay attention to the bracket insertion direction. There is only a
positioning hole on the IN port side. Therefore, the bracket
cannot be mounted to the OUT port side.
2) The bracket should be mounted after connecting the fitting.
(Refer to the "Piping" section)
* The bracket is shipped together with the product.
Bracket Assembly Part Nos. (With set screw)
Port
Size
size
1/4
20,30
3/8
,
Port size
1/8
1/8, 1/4, 3/8
∗
1
1/8, 1/4, 3/8
1/8, 1/4, 3/8
1/4, 3/8
Thread Bracket assembly part
type no. (With set screw)
Rc,NPT,G
JSX022-12A-2-1
Rc,NPT
G JSX022-12A-2-2
Thread Bracket assembly
type part no.
JSX021-12A-3
JSX022-12A-3
Rc
NPT JSX20-12A-4
G
VX021N-12A
VX022N-12A
Weight
(g)
40
Stainless
40
- 9 -
Weight
(g)
10
30
Stainless
40
20
30
Bracket
Material
steel
Bracket
material
steel
