HULALA
H
O
M
E
ITEM NO.SP-14KSBLS0845
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
01/29

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-14KSBLS0845 and is the answer not in the manual?

Questions and answers

Related Manuals for HULALA HOME SP-14KSBLS0845

Summary of Contents for HULALA HOME SP-14KSBLS0845

  • Page 1 HULALA ITEM NO.SP-14KSBLS0845 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/29...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.

  • Page 3: Explosive View

    EXPLOSIVE VIEW 2PERSONEN 03/29...

  • Page 4: Parts List

    PARTS LIST 04/29...

  • Page 5: Hardware List

    HARDWARE LIST Ø Ø M6*50mm M3.5*14mm Ø15*11mm 6*35mm 8*30mm TOOL LIST HARDWARE SPARE LIST Ø Ø M3.5*14mm 6*35mm M6*50mm Ø15*11mm 8*30mm 05/29...
  • Page 6 ASSEMBLY INSTRUCTIONS STEP-1 Insert wooden dowel #2 into the corresponding hole of panel (A) and then screw bolt #1 into the corresponding hole of panel (A), tighten bolt #1 with screwdriver #15. Ø Ø 8*30mm 6*35mm 06/29...
  • Page 7 ASSEMBLY INSTRUCTIONS STEP-2 Use screw#11 to attach part#11 to the corresponding hole of toppanel(A),tighten screw#11 with screwdriver#15.And then slide therebounder#11 into the rebounder base as picture show. 07/29...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-3 Insert side panel (D)&(C) 、 middle vertical panel(E) into the preassemble top panel (A),and then insert cam bolt #5 into the corresponding hole of side panel (D)&(C)&middle vertical panel(E),tighten cam bolt #5 with screwdriver #15,finally stick paster #8 to it for look nice.
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-4 Use screw #4 to attach wine glass holder #14 to panel (A) ,tighten screw #4 with screwdriver #15 . M3.5*14mm 09/29...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-5 Insert panel(G) into preassemble top panel(A) as picture show ， and then insert cam bolt #5 into the corresponding hole of panel (G),tighten cam bolt #5 with screwdriver #15 ， finally stick paster #8 to it for look nice.
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-6 Carefully align and slide panel (F) into the groove along rear edge of pre-assemble step 5,and then insert wooden dowel #2 into the corresponding hole of panel(D)&&(E)&(C) . Ø 8*30mm 11/29...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-7 Insert bottom panel (B) into preassemble step 6 ， make sure all holes aligned and then use bolt #3 to attach them ， tighten bolt #3 with allen key #16. M7*50mm 12/29...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-8 Screw the four leg(K) onto the base plate(B),and screw the middle leg(L) onto the bottom plate(B). 13/29...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-9 Attention: Before the next step, adjust the feet of the locker to keep it level. Attention: Before the next step, adjust the feet of the locker to keep it level. 14/29...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP-10 Use screw #9 to attach plastic shelf #9 to the corresponding hole of panel (A)&(D)&(G)&(E)&(C)&(B) as picture show , make sure all holes aligned and tighten screw #9 with screwdriver #15. 15/29...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP-11 Nsert shelf holder #8 into the corresponding hole of panel (C)&(E)&(D) ， make all shelf holder #7 same level and then attach adjustable shelf(H) to it. Shelf holder can be adjusted up or down & & 16/29...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-12 Use screw #12 to attach top plate #12 to bottom plate (B) ,tighten screw #12 with screwdriver #15 . 17/29...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP-13 Use screw #4 to attach metal plate #11 to door (I) ,tighten screw #11 with screwdriver #15 . Use screw #4 to attach hinge #6 to door (I) ,tighten screw #4 with screwdriver #15 . M3.5*14mm 18/29...
  • Page 19 ASSEMBLY INSTRUCTIONS STEP-14 Use screw #12 to attach metal plate #12 to door (I) ,tighten screw #12 with screwdriver #15 . 19/29...
  • Page 20 ASSEMBLY INSTRUCTIONS STEP-15 Use screw #4 to attach door (I) to the corresponding hole of side panel (C)&(E) ， tighten screw with screwdriver #15 . M3.5*14mm 20/29...
  • Page 21 ASSEMBLY INSTRUCTIONS STEP-16 Use screw #4 to attach metal plate #11 to door (J) ,tighten screw #11 with screwdriver #15 . Use screw #4 to attach hinge #6 to door (J) ,tighten screw #4 with screwdriver #15 . M3.5*14mm 21/29...
  • Page 22 ASSEMBLY INSTRUCTIONS STEP-17 Use screw #12 to attach metal plate #12 to door (J) ,tighten screw #12 with screwdriver #15 . 22/29...
  • Page 23 ASSEMBLY INSTRUCTIONS STEP-18 Use screw #4 to attach door (J) to the corresponding hole of side panel (E)&(D) ， tighten screw with screwdriver #15 . M3.5*14mm 23/29...
  • Page 24 ASSEMBLY INSTRUCTIONS STEP-19 1.Short press: Cycle switch white light, warm light, neutral light. 2.Long press: When the light is on, press the button to adjust the brightness without releasing it. Release the button to lock the brightness. Key: 1.The initial state is off. 2.Press the first button to enter the steady state.
  • Page 25 ASSEMBLY INSTRUCTIONS STEP-20 After adjusting the induction lamp #13 to your favorite light source, as shown in the figure,remove the back protective layer and attach the induction lamp #13 to the panel(A). USB charging port 25/29...
  • Page 26 ASSEMBLY INSTRUCTIONS ① ⑤ STEP-21 Use nylon packaging # 10 Inside screw ⑤ to attach bracket ① to the corresponding hole of top panel(A) ， tighten screw with screwdriver #15 . ① ⑤ ① ⑤ ① ⑤ 26/29...
  • Page 27 ASSEMBLY INSTRUCTIONS ② ③ ① STEP-22: 1.Mark the position on the wall, that corresponds to the location of bracket ① on the back of top panel A; Drill and insert the expandable screw ② by hammer. 2.Assemble the bracket ① to the wall. Align the hole in the bracket ① with the expandable screw ②...
  • Page 28 ASSEMBLY INSTRUCTIONS ④ STEP-23 ④ ① 3.Let the plastic belt pass through bracket and pull tightly. If you encounter difficulties during the installation process, please watch the installation video! ① ④ ×2 ① ④ ① ④ 28/29...

  • Page 29: Warranty

    WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
