HULALA
H
O
M
E
ITEM NO.SCBSD0810
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
01/26

Advertisement

loading
Need help?

Need help?

Do you have a question about the SCBSD0810 and is the answer not in the manual?

Questions and answers

Summary of Contents for HULALA HOME SCBSD0810

  • Page 1 HULALA ITEM NO.SCBSD0810 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/26...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
  • Page 3: Explosive View

    EXPLOSIVE VIEW 2PERSONEN 03/26...
  • Page 4: Parts List

    PARTS LIST 04/26...
  • Page 5: Hardware List

    HARDWARE LIST #2 x20 #1 x10 Ø Ø M7*50mm M6*50mm 6*35mm 8*30mm M3.5*14mm M6*40mm Ø15*11mm #11 x4 #9 x4 ∅ #17 x4 #15 x24 #19 x4 M4*30mm M4*35mm TOOL LIST HARDWARE SPARE LIST #19 x1 Ø M6*40mm M3.5*14mm M7*50mm M6*50mm M4*35mm 6*35mm M4*30mm...
  • Page 6 ASSEMBLY INSTRUCTIONS STEP-1 Insert wooden dowel #2 into the corresponding hole of top panel (A),screw bolt #1 into the corresponding hole of top panel (A),tighten bolt #1 with screwdriver #20. Ø Ø 6*35mm 8*30mm 06/26...
  • Page 7 ASSEMBLY INSTRUCTIONS STEP-2 Use screw#6 to attach wine rack(N) to top panel (A),tighten screw#6 with screwdriver#20. M3.5*14mm 07/26...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-3 Insert panel (D)&(E)&(F)&(C) into top panel (A) as picture show,and then insert cam bolt #7 into the corresponding hole of panel (D)&(E)&(F)&(C),tighten cam bolt #7 with screwdriver#20,finally,stick paster #14 on the corresponding hole of panel (D)&(E)&(F)&(C). E&F &...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-4 Carefully align and slide panel (J)&(I) into the groove along rear edge of pre-assemble unit at step 3,slide the panel (J)&(I) into the bottom,and the insert wooden dowel #2 into the corresponding hole of panel (C)&(D)&(E)&(F). (C)&(D)&(E)&(F) Ø8x30mm 09/26...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-5 Use bolt #3 to attach bottom panel (B) to the corresponding hole of panel (C)&(E)&(F)&(F)&(D)tighten bolt #3 with allen key #21. M7*50mm 10/26...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-6 M6*40mm 11/26...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-7 Use bolt #4 to attach preassemble step 6 to the corresponding hole of bottom panel(B), make sure all holes aligned and tighten all bolts 70 % with allen key #21 . M6*50mm 12/26...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-8 Attention: Before the next step, adjust the feet of the locker to keep it level. Attention: Before the next step, adjust the feet of the locker to keep it level. 13/26...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-9 Use screw #6 to attach part #15 to bottom panel (A)&(B)&(C)&(D)&(E)&(F),tighten screw #6 with screwdriver #20. M3.5*14mm 14/26...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP-10 Insert shelf holder #8 into the corresponding hole of (C)&(D)&(E)&(F) panel and then attach adjustable shelf (G) &(H)to it. Shelf holder can be adjusted up or down & & & 15/26...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP-11 (K),tighten screw #6 with Use screw #6 to attach hinge #10 to door screwdriver #20. M3.5*14mm 16/26...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-12 Insert part #16 into the corresponding position of door (K),and then M4*30mm ∅ 17/26...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP-13 ,tighten Use screw #6 to attach preassemble hinge #10 to panel (C)&(D) screw #6 with screwdriver #20. M3.5*14mm 18/26...
  • Page 19 ASSEMBLY INSTRUCTIONS STEP-14 (K),tighten screw #6 with Use screw #6 to attach hinge #11 to door screwdriver #20. M3.5*14mm 19/26...
  • Page 20 ASSEMBLY INSTRUCTIONS STEP-15 Insert part #16 into the corresponding position of door (K),and then screwdriver M4*30mm ∅ 20/26...
  • Page 21 ASSEMBLY INSTRUCTIONS STEP-16 ,tighten Use screw #6 to attach preassemble hinge #16 to panel (F) screw #6 with screwdriver #20. M3.5*14mm 21/26...
  • Page 22 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS HINGE ADJUST Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method...
  • Page 23 ASSEMBLY INSTRUCTIONS M3.5*14mm STEP-17 Use screw #6 to attach plastic bracket #12 to panel (A),tighten screw #6 with screwdriver #20. 23/26...
  • Page 24 ASSEMBLY INSTRUCTIONS M4*35mm STEP-18: 1. Mark the position on the wall, that corresponds to the location of bracket on the top panel (A); Drill and insert the expandable screw by hammer. 2. Assemble the bracket to the wall. Align the hole in the bracket with the expandable screw , use screw to attach...
  • Page 25 ASSEMBLY INSTRUCTIONS STEP-19 3. Let the plastic belt pass through bracket and pull tightly. If you encounter difficulties during the installation process, please watch the installation video! ×2 25/26...
  • Page 26: Warranty

    WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
