- Page 1 HULALA ITEM NO.SCBSD0590 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/23...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
-
Page 3: Explosive View
EXPLOSIVE VIEW 2PERSON OVERVIEW 03/23... -
Page 4: Parts List
PARTS LIST 04/23... -
Page 5: Hardware List
HARDWARE LIST 6x35mm x50mm x40mm x50mm x14mm x35mm ∅ M3.5 HARDWARE SPARE LIST 6x35mm x50mm x40mm x50mm x14mm x35mm ∅ M3.5 05/23... -
Page 6: Tool List
HARDWARE LIST 8x30mm 15x11mm 20mm ∅ ∅ ∅ 8x30mm ∅ TOOL LIST 06/23... - Page 7 ASSEMBLY INSTRUCTIONS STEP-1: Insert wooden dowel #7 into the corresponding hole of top panel (A),screw bolt #1 into the corresponding hole of top panel (A),tighten bolt #1 with screwdriver #18. #7x6 #1x6 6x35mm ∅ 8x30mm ∅ 07/23...
- Page 8 ASSEMBLY INSTRUCTIONS STEP-2: Insert panel (D)&(E)&(C) into top panel (A) as picture show,and then insert cam bolt #8 into the corresponding hole of panel (D)&(E)&(C),tighten cam bolt #8 with screwdriver #18，finally，stick paster #9 on the corresponding hole of panel (D)&(E)&(C). #8 #9 #8 #9 &...
- Page 9 ASSEMBLY INSTRUCTIONS STEP-3: Carefully align and slide panel (G) into the groove along rear edge of pre-assemble unit at step 2,slide the panel (G) into the bottom,and the insert wooden dowel #7 into the corresponding hole of panel (D)&(E)&(C). #7x6 &...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-4: Use bolt #2 to attach bottom panel (B) to the corresponding hole of panel (D)&(E)&(C),tighten bolt #2 with allen key #17. #2x6 & & x50mm 10/23...
- Page 11 ASSEMBLY INSTRUCTIONS STEP-5: Use bolt #3 to attach leg (J) to rail (K),tighten bolt #3 with allen key #17. #3x2 x40mm 11/23...
- Page 12 ASSEMBLY INSTRUCTIONS STEP-6: Use bolt #4 to attach preassemble leg (J)&(K) to the corresponding hole of bottom panel (B),tighten bolt #4 with allen key #17. #4x7 x50mm 12/23...
- Page 13 ASSEMBLY INSTRUCTIONS STEP-7: Attention: Before the next step, adjust the feet of the locker to keep it level. Attention: Before the next step, adjust the feet of the locker to keep it level. 13/23...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-8: Use screw #5 to attach part #16 to bottom panel (A)&(B)&(C)&(D)&(E),tighten screw #5 with screwdriver #18. #5x8 #16x8 x14mm M3.5 14/23...
- Page 15 ASSEMBLY INSTRUCTIONS STEP-9: Insert shelf holder #10 into the corresponding hole of panel(C)&(D)&(E) and then attach adjustable shelf (F) to it. C&E&D Shelf holder can be adjusted up or down #10x8 15/23...
- Page 16 ASSEMBLY INSTRUCTIONS STEP-10: (I)&(H),tighten screw #5 Use screw #5 to attach hinge #11 to door with screwdriver #18. #5x8 & #11x4 x14mm M3.5 16/23...
- Page 17 ASSEMBLY INSTRUCTIONS STEP-11: Use screw #5 to attach preassemble hinge #11 to panel (C)&(D) tighten screw #5 with screwdriver #18. #5x16 & & & & x14mm M3.5 17/23...
- Page 18 ASSEMBLY INSTRUCTIONS Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method 18/23...
- Page 19 ASSEMBLY INSTRUCTIONS STEP-12: Insert part #12 into the corresponding position of door (I)&(H),and then (H)&(I),make sure all holes use screw #5 to attach part #12 to door aligned and tighten screw #5 with screwdriver #18. #12x2 #5x4 & x14mm M3.5 19/23...
- Page 20 ASSEMBLY INSTRUCTIONS x14mm M3.5 STEP-13: Use screw #5 to attach plastic bracket #13 to panel (C)&(D),tighten screw #5 with screwdriver #18. #5x4 #13x2 & 20/23...
- Page 21 ASSEMBLY INSTRUCTIONS x35mm 8x30mm ∅ STEP-14: 1. Mark the position on the wall, that corresponds to the location of bracket on the side panel (C)&(D); Drill and insert the expandable screw by hammer. 2. Assemble the bracket to the wall. Align the hole in the bracket with the expandable screw , use screw to attach it...
- Page 22 ASSEMBLY INSTRUCTIONS STEP-15 3. Let the plastic belt pass through bracket and pull tightly. #15x2 #15x2 22/23...
-
Page 23: Warranty
WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
