TECHNICAL SPECIFICATIONS

BiDi-Shutter is produced by Nice S.p.A. (TV).
Warning
All technical specifications stated in this section refer to an ambient temperature of 20 °C (± 5 °C). Nice S.p.A. reserves the right to modify the
product when necessary, while maintaining the same functionalities and intended use.
Table A1 - BiDi-Shutter - Specifications
Type
Power supply
Motor rated current
Motor rated power
Required circuit breaker
Casing protection rating
Operating temperature
Dimensions (mm)
Weight
Table A2 - BiDi-Shutter - Radio transceiver
Frequency band
Code
No. of memorisable transmitters
Transceiver range
Max. transmit power
(*) The transceiver range is strongly influenced by other devices operating at the same frequency with continuous transmission, such as
alarms and radio headphones which interfere with the control unit transceiver.
in-wall/flush box mounted control unit for tubular motors
100–240 V AC, 50/60 Hz
2 A
480 VA for Vn = 240 V;
460 VA for Vn = 230 V;
240 VA for Vn = 120 V;
200 VA for Vn = 100 V
Compliant with IEC/EN 60898-1;
Curve code: B;
Rated current: up to 16 A;
Breaking capacity: 6 kA;
Rated insulation voltage: 500 V;
Rated impulse withstand voltage: 4 kV;
IP 20
0–35 °C
45 x 36 x h 23
20 g
OPERA/FLOR (rolling code), PLN2+ (rolling code)
30, including climatic sensors
Estimated at 150 m in open space and 20 m inside buildings (*)
433.05–434.04 MHz
10 dBm
