- Page 1 BiDi-Dimmer Bidirectional interface for lights indoor EN - Instructions and warnings for installation and use v1.5...
-
Page 2: Warnings And General Precautions
PRODUCT DESCRIPTION INSTALLATION AND CONFIGURATION The BiDi-Dimmer control unit enables the control of a mains-powered, single light source. The light source can be turned on, turned off or dim- med (if dimmable). The control unit has an algorithm of a light source detection. It automatically selects a suitable control mode and adjusts maximum and minimum light levels. -
Page 3: Technical Specifications
BiDi-Dimmer is produced by Nice S.p.A. Warnings All technical specifications stated in this section refer to an ambient temperature of 20 °C (± 5 °C). Nice S.p.A. reserves the right to modify the product when necessary, while maintaining the same functionalities and intended use. - Page 4 • The BiDi-Dimmer control unit was designed for insertion in a junction box or wall box; its housing doesn't have any protection against water and has only basic protection against contact with solid parts. Never place BiDi-Awning in inadequately protected environments.
- Page 5 The electric power supply of the control unit needs to be connected using terminals L and N (Line, Neutral) according to Figure 2. If no Neutral wire is present in the box, connect the N terminal with the Sx terminal according to Figure 3. The BiDi-Dimmer control unit can operate with supply voltage of 100 to 240 Volts and frequency of 50 or 60 Hz.
- Page 6 5.2 - Memorising transmitters in Mode I When there is no transmitter memorised, the first one can be memorised during startup according to the following procedure: Table A6 - BiDi-Dimmer - Memorising first transmitter during startup in Mode I Nº...
- Page 7 The transmitters can be memorised using the programming pushbutton according to the following procedure: Table A7 - BiDi-Dimmer - Memorising first and other transmitters in Mode I Nº Description Example Press and hold the programming pushbutton. Release the programming pushbutton when the LED illuminates with red (the 1 position).
- Page 8 5.4 - Memorising transmitters in Mode II Table A9 - BiDi-Dimmer - Memorising first and other transmitters in Mode II Nº Description Example Press and hold the programming pushbutton. Release the programming pushbutton when the LED illuminates with orange color (the 2 position).
- Page 9 The control unit performs the calibration, the load can blink and change the brightness level. The load is switched off when the process is completed. The programming procedure ends automatically. Table A12 - BiDi-Dimmer - Calibration with memorised transmitter equipped with PRG button Nº Description Example Press the PRG pushbutton on the bound transmitter.
- Page 10 The control unit allows to connect the momentary or toggle switches to S1 and S2 inputs. By default, the toggle switch type is set. To change type of connected switch, follow the steps from the table below: Table A14 - BiDi-Dimmer - Setting type of connected switches Nº...
-
Page 11: Led Signals
7.1 - Programming menu When pressing and holding the programming pushbutton on the control unit, the LED signals the following positions of the programming menu. Table A18 - BiDi-Dimmer - Menu positions when holding the programming pushbutton Nº Color Description... - Page 12 CAUTION! – local legislation may envisage serious fines in the event of abusive disposal of this product. DECLARATION OF CONFORMITY Nice S.p.A. declares that the radio equipment type BiDi-Awning complies with Directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at: http://www.niceforyou.com/en/support...
- Page 13 Nice S.p.A Oderzo TV Italia www.niceforyou.com info@niceforyou.com...
