01.
SIGNATURE
SAFETY INFORMATION
If the information in these instructions
are not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other.
CONSUMER: RETAIN THIS MANUAL FOR
FUTURE REFERENCE.
INSTALLER: LEAVE THIS MANUAL WITH
256438
THE APPLIANCE.
WARNING: This product can expose you to chemicals including
lead in the wiring, which is [are] known to the State of California
to cause birth defects or other reproductive harm. For more
information visit: www.p65warnings.ca.gov
www.amantii.com
INSTALLATION /
OWNERS MANUAL
WARNING
MODEL SKU:
01
BI-TRD-38-SIG
TS2210010-1
Version:202405
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amantii SIGNATURE BI-TRD-38-SIG
Summary of Contents for Amantii SIGNATURE BI-TRD-38-SIG
- Page 1 256438 THE APPLIANCE. WARNING: This product can expose you to chemicals including lead in the wiring, which is [are] known to the State of California to cause birth defects or other reproductive harm. For more information visit: www.p65warnings.ca.gov www.amantii.com Version:202405...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Please read and carefully follow all of the instruction found in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii Electric Fireplace. IMPORTANT INSTRUCTIONS CAUTIONS... -
Page 3: Important Instructions
1. Read all instructions before installing or using this heater. 2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surface. If provid- ed, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front, sides and rear of the heater. -
Page 4: Cautions
CAUTIONS Always install the heater in accordance with this guide. If in doubt obtain expert advice. Always make sure the electrical socket is accessible and located adjacent to, but not above the heater. Always disconnect the heater from the electrical supply before moving it, or carrying out cleaning, maintenance. -
Page 5: Fcc Cautions
FCC CAUTIONS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifcations not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. -
Page 6: Unpacking And Testing Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Test all aspects of its operation (manual switches, remote and heater) to make sure all components are operating correctly. As with most electronic devices, your new electric fireplace has been designed to operate at temperatures between 5 ℃(41℉）... -
Page 7: Product Specification
PRODUCT SPECIFICATION This appliance has been tested in accordance with the UL Standard 2021 for fixed and location dedicated electric room appliances in the United States and Canada. If you need assistance during installation, please contact your local dealer. NOTE: This appliance must be electrically wired and grounded in accordance with local codes. -
Page 8: Outdoor Installations
OUTDOOR INSTALLATIONS The Symmetry Bespoke Series electric fireplaces are suitable for installation in outdoor areas protected from direct water impingement. In addition to maintaining the listed mantel and combustibles clearances, a rain protection overhang factor of 1/2 shall be constructed to the front and to each side of the installed appliance. -
Page 9: Installation- Built-In
INSTALLATION- BUILT-IN NOTE: Due to the many different materials used to build walls, it is highly recommended that you consult your local builder before you install this appliance on a wall. PREPARATION Select a location that is not prone to moisture and is located at least 0.91m or 3 feet away from combustible materials such as curtains, drapes, furniture, bedding, paper, etc. -
Page 10: Hardwire Installation
HARDWIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hardwire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring. This appliance must be electrically connected and grounded in accordance with local codes, if hardwired. - Page 11 Connect to 240V 1. Remove the cover plate from the left side of the appliance by removing the four screws as shown below. Pierce wire grommet with a knife. 2. Attach the wiring to the junction block. Please make sure the live wire goes into the “L”, the neutral wire into “N”...
-
Page 12: Decorative Media Installation
DECORATIVE MEDIA INSTALLATION Consumers may purchase optional decorative media if they choose. See dealer for more details. 1. Unscrew 2 screws and remove the front glass brackets which are fending the front glass. 2. Remove the front glass carefully. - Page 13 3. Unscrew 6 screws and remove the brackets which are fending the black glass liners. 4. Remove the black glass liners. 5. Remove the Tray Glass. Tray Glass...
- Page 14 6. Put the cassette in the appropriate position and wire it according to the instructions attached with the cassette. cassette cassette Main PCB N Power switch Heater N Heater L Fireplace grounded N3 N2 N1 N L2’ L2 L1’ L1 G N3 N2 N1 N L2’...
-
Page 15: Cassette Installation
5. You'll want to Wire the cassette into the Amantii Signature electric fireplace block so that the units can operate on a single cord. ( Refer to page 14 in the manual for wiring diagram, as well as the link for further instructions from Dimplex: https://amantii.com/Optimyst/Installlation%20Guide.pdf ) - Page 16 7. Once the cassette has been wired to the Amantii Signature fireplace, the cassette can then be placed into the Amantii Signature fireplace. 8. When placing the cassette into the Signature unit, simply slot it into the notches at the far back and slide it all the way in.
-
Page 17: Manual Operation
MANUAL OPERATION The fireplace operates either by the touch panel located on the left front top side of the fireplace or by supplied remote control. Ensure that the ON / OFF Power Switch on the fireplace is in the ON position. Touch the control panel once to “wakes up”... -
Page 18: Remote Control Operation
REMOTE CONTROL OPERATION For the remote to function make sure the fireplace is plugged in and the ON / OFF Power Switch on the fireplace is in the ON position and the remote has batteries. Important: When operating the remote make sure you point the remote to the center of the fireplace. - Page 19 Each time Speed Button is pressed, the speed of the flame will change. Three options are available: Medium- High- Low. The Moodlight Button turns the moodlight on and off. When in on position, the display screen of the remote control shows AD 1, when the number “1” flash, you can set the color of moodlight with keys.
- Page 20 7 day timer function NOTE: Ensure that the current time setting accurate, otherwise the effective time of the 7 day timer function will be different from what you set. Press the key once, 7 days from Monday to Sunday will display on the LCD screen of the remote control, press key within 5 seconds to enter 7 day timer function .
-
Page 21: Trouble Shooting
TROUBLE SHOOTING Fault code Fault Cause Solution The heater overheating Call after-sales service. NTC is defective. Call after-sales service. If the vents are dirty or clogged. Unplug the power, The heater not working. clean the dust and debris of the vent area. Wait for 5 minutes, plug in and turn on the heater. -
Page 22: Wiring Diagram
WIRING DIAGRAM peripheral unit L1’ EMBER BED LIGHT AC120V XTL:26MHz L2’ ANTENNA peripheral unit WIFI PCB POWER PCB KEY PCB BLUETOOTH PCB ANTENNA XTL:24MHz LOUDSPEAKER peripheral unit L1’ AC240V EMBER BED LIGHT XTL:26MHz L2’ AC120V ANTENNA peripheral unit WIFI PCB POWER PCB KEY PCB BLUETOOTH PCB... -
Page 23: Exploded View
EXPLODED VIEW... -
Page 24: Electric Fireplace Warranty
Should a product or part covered by this limited warranty be proven to be defective, in material or workmanship, and during the two (2) year limited warranty period, Amantii will replace such defective product or part without charge. If Amantii is unable to replace such product, or if replacement is not commercially practicable or cannot be timely done, in its sole discretion Amantii may, in lieu of replacement, choose to refund the purchase price for such product or part. - Page 25 The provisions of the United Nations Convention on Contracts for the Sale of Goods shall not apply to this limited warranty or the sale of products covered by this limited warranty. GENERAL Amantii reserves the right to make changes at any time without notice, in design, material, specifi cations, prices and the right to discontinue styles and products. GLASS...
