- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR WALL- MOUNT AND BUILT- IN UNITS WM-BI-2428-VLR operation 09 13-01...
-
Page 2: Table Of Contents
TABLE OF CONTENTS CONGRATULATIONS! In selecting this Amantii Wall Mount OR Built-in electric fireplace, you have chosen the finest and most dependable fireplace on the market today. A beautiful and functional addition to the finest homes. Welcome to the family of satisfied Amantii electric fireplace owners. -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS WARNING! 5. Do not use outdoors. grounded Cover Of Grounded Outlet Box Metal Screws Grounding Pin Adapter Grounding Means Grounding Fig. 1 SAVE THESE INSTRUCTIONS... -
Page 4: Wm-Bi-2428-Vlr
WM-BI-2428-VLR This appliance has been tested in accor- Model Number WM-BI-2428-VLR dance with the UL Standand 2021 for Built-In or Wall Mount Appliance Voltage 120V AC,60Hz appliances in the United States and Cana- da. If you need assistance during installa-... -
Page 5: Installation Overview
INSTALLATION OVERVIEW NOTE: BEFORE YOU INSTALL SITE SELECTION wall. rapes, pillow Review and consider all of the following condi- re etc. wo (2) wall ht and away fr overhead light- ing. ethods: electric et for ease of electric t-In (page 7) nt (Page 8) and all hardware fr ox and r... -
Page 6: Package Contents
PACKAGE CONTENTS Part Glass ( Flat or curve) Appliance Wall bracket Decorative Meida Brackets for Optional Surround CONTENTS Description Quantity Picture Part Screw 0.16 in. x 1.0 in. Wall Plug 0.3 in. x 1.5 in. Wood Screw 0.16 in. x 0.6 in. -
Page 7: Built-In Installation
FIREPLACE INSTALLATION - BUILT-IN NOTE BEFORE YOU INSTALL The WM-BI-2428-VLR can be built-in.See the next page for wall mount and corner mount instructions. just the unit to achieve the desired amount of depth. wall and the wall studs. 3/4" 20mm The rough wall opening size of the fireplace. -
Page 8: Wall Mount Installation
NOTE: BEFORE YOU INSTALL It is strongly recommended that the screws be Mounting holes for flat mount. screwed into the wall studs where possible. If Stakes for hanging. anchors are used. 1. Affix the provided mounting bracket ( as shown in right) to the flat wall or corner wall as your wish. -
Page 9: Media Options
Media op ons The WM-BI-2428--VLR comes with fire glass media, real coal and 6 piece log set. See below for media installation instructios. 6 piece log set Sable Real coal Decorative Media Installation 1. Installing the decorative media. Pour the fire glass media into the tray as shown below. Fee free to use any combina on of fire glass, coal or log set that you find most appealing. -
Page 10: Front Installation
FRONT INSTALLATION NOTE: BEFORE YOU INSTALL It is recommended that two people install the front onto the appliance, w ear sa fety glasses and gloves when handling glass. 1.Lift fireplace front and line up the brackets with the four (4) shoulder screws on the side of appliance body NOTE: Before you lift the front glass. -
Page 11: Operating The Unit
OPERATING THE UNIT 1. Make sure the appliance is switched OFF (refer on the right hand side of the unit. 3. Plug unit into electrical outlet. HARD-WIRE INSTALLATION If it is necessary to hard wire this appliance, a qualified electrician may remove the cord connection, and wire the appliance directly to the house hold wiring. - Page 12 OPERATING THE UNIT A: Romote Operations 1. For the remote to function make sure the heater is plugged in and main power switch is turned on. Note: The heater may release a slight odor the first time it is turned on. This is normal. The heating elements inside the heater will burn off any accumulated oils or dust during initial heating.
- Page 13 1. Power ON/OFF switch 2. Heat control button 3. Flame control button 4. HEATER LED 5. POWER LED Plug the heater into a suitable outlet. 1) “Power ON/OFF” Set this switch to position I to turn the product ON. Setting it to O to turn the product OFF. The POWER LED will be lit when the fireplace insert is on.
-
Page 14: Replacing The Remote Control Battery
REPLACING THE REMOTE CONTROL BATTERY When the remote control stops operating or its range seems reduced, it is time to replace the batteries with new ones. Remove the batteries if the remote control won’t be used for a long period of time. 1. -
Page 15: Care And Maintenance
CARE AND MAINTENANCE CLEARANCE TO COMBUSTIBLES Keep electrical cords, drapery, furniture and other combustibles at least 3 ft. from the front of the heater and away from the sides. CLEANING TRIM Clean the metal trim using a soft cloth, slightly dampened with a citrus oil-based product and buff with a clean soft cloth. -
Page 16: Fireplace Maintenance
FIREPLACE MAINTENANCE WARNING: Disconnect power before performing any maintenance or cleaning to reduce the risk of LED LIGHT BULB REPLACEMENT LED light bulbs are to be replaced by the manufacturer, it’s service agent or similar quali- WARNING: UNIT DISPOSAL Do not dispose with other household wastes. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the... -
Page 17: Trouble Shooting
TROUBLE SHOOTING WARNING Disconnect power before performing any maintenance and allow to cool before servic- SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION Fireplace doesn’t work. Fireplace inner temperature over Reset switch by turning main power switch off and waiting five heatng or home circuit breaker mimutes, then turning it back on. -
Page 18: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Dealer service technician Date service Performed special Concerns Name Name NOTES:... -
Page 19: Warranty
Products covered by this limited warranty have been tested and inspected prior to shipment and, subject to the provisions of this war- ranty, Amantii warrants such products to be free from defects in material and workmanship for a period of one (1) year from the date of the first purchase of such products. - Page 20 ELECTRIC FIREPLACES...
