INSTALLATION AND OPERATION INSTRUCTIONS FOR
BI-30-XTRASLIM
BI-40-XTRASLIM
BI-50-XTRASLIM
BI-60-XTRASLIM
SAFETY INFORMATION
WARNING
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BI-30-XTRASLIM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Amantii BI-30-XTRASLIM

Summary of Contents for Amantii BI-30-XTRASLIM

  • Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR BI-30-XTRASLIM BI-40-XTRASLIM BI-50-XTRASLIM BI-60-XTRASLIM SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 2: Table Of Contents

    Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS........................... 3 UNPACKING AND TESTING APPLIANCE ......................

  • Page 3: Important Instructions

    IMPORTANT INSTRUCTIONS Read all instructions before installing or using this heater. 2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front of the heater; keep them away from sides and rear as well. 3.

  • Page 4: Unpacking And Testing Appliance

    UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. GROUNDING APPLIANCE This appliance is for use on 120 Volts.

  • Page 5: Bi-30-Xtraslim

    BI-30-XTRASLIM This appliance has been tested in accordance with the UL Standard 2021 Description BI-30-XTRASLIM for fixed and location dedicated Voltage 120V AC 60Hz electric room appliances in the United Watts 1500W Max States and Canada. If you need NO HEATER...

  • Page 6: Bi-40-Xtraslim

    BI-40-XTRASLIM This appliance has been tested in accordance with the UL Standard 2021 Description BI-40-XTRASLIM for fixed and location dedicated Voltage 120V AC 60Hz electric room appliances in the United Watts 1500W Max States and Canada. If you need NO HEATER assistance during installation, please MOTOR HEATER contact your local dealer.

  • Page 7: Bi-50-Xtraslim

    BI-50-XTRASLIM This appliance has been tested in Description BI-50-XTRASLIM accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States and NO HEATER Canada. If you need assistance during MOTOR HEATER installation, please contact your local Appliance Width...

  • Page 8: Bi-60-Xtraslim

    BI-60-XTRASLIM Description BI-60-XTRASLIM This appliance has been tested in accordance Voltage 120V AC 60Hz with the UL Standard 2021 for fixed and Watts 1500W Max location dedicated electric room appliances NO HEATER in the United States and Canada. If you need MOTOR HEATER assistance during installation, please contact your local dealer.

  • Page 9: Safety Drill Screw Area

    SAFETY DRILL SCREW AREA There is a safety drill screw area as show below. Please make sure that the fix screws are in this area. Sa fe ty d rill s cre w a re a (Da rk a re a ) T h e m a n u a l c o n tro l p a d p o s itio n HARD- WIRE INSTALLATION Turn off the appliance completely and let cool before servicing.

  • Page 10: For Bathroom Use

    2. Attach the wiring to the junction block. Please make sure the live wire goes into the “L”, the neutral wire into “N” and the ground wire into “G”. 3. Put the plate back and screw back. FOR BATHROOM USE If this unit is installed in a bathroom it must be protected by a GIF receptacle or circuit.

  • Page 11: Outdoor Installations

    OUTDOOR INSTALLATIONS The BI-XTRASLIM series electric fireplaces are suitable for installation in outdoor areas protected from direct water impingement. In addition to maintaining the listed mantel and combustibles clearances, a rain protection overhang factor of 1/2 shall be constructed to the front and to each side of the installed appliance.

  • Page 12: Installation

    Note: The optional steel surround is not firmly attached and can be removed from the unit by simply pulling it off. It is recommended that two people remove the surround. The rough wall opening size of the fireplace: W(＂) D(＂) H(＂) BI-30-XTRASLIM 4 1/2 20 3/8 BI-40-XTRASLIM 4 1/2 20 3/8...
  • Page 13 2. Remove the optional trim from the unit as illustrated below. Remove the wall framing plates from the unit. 3. Re-attach the framing plates to the unit as shown below.
  • Page 14 4. Bend the framing plates as shown. 5. Lift the unit into the wall opening. Note: Two people are required...
  • Page 15 6. Drive the mounting screws threw the framing plates securing the unit into the wall studs. 7. Using desired materials, finish to the glass for a clean face installation OR re-attach the steel surround that was removed in STEP 1.

  • Page 16: Installation Wall-Mount

    Wall-mount installation instructions Note: The mantel is available for Optional Purchase only and does not come with the unit. 1. Take out the unit from the box. Please do the pre-test before you install the fireplace. 2. Pull out the optional trim from the unit as shows below. Remove the framing plates from the unit.
  • Page 17 3. Fix the brackets as the picture shows below. You can find the brackets in the plastic bag with the manual. 4. Make sure the brackets are fixed the right way as the picture shows below.
  • Page 18 5. Put the fireplace into the back of the wooden frame. 6. Screw the brackets with the wooden frame and make sure the fireplace and the wooden frame are firmly fixed.
  • Page 19 7. Take the hanger from the back of the fireplace by removing screws. Select a location for the hanger to be fixed that is not prone to moisture and is located at least 0.91 m or 3 feet away from combustible materials such as curtains, drapes, furniture, bedding, paper, etc.
  • Page 20 Fix a bracket beneath the fireplace to ensure the fireplace won’t move.

  • Page 21: Media Options

    MEDIA OPTIONS The only media that comes with this version is Clear decorative media. Consumers may purchase optional decorative media if they choose. See dealer for more details. Clear Removing the front glass Unplug the unit from the power and make sure it is switched off. Unscrew the adjustable screws to take off the front glass.

  • Page 22: Operation

    OPERATION The fireplace can be operated either by the switches located on the left bottom of the fireplace unit or by supplied remote control. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1. The main power ON/OFF switch in position O, the fireplace is OFF. 2.
  • Page 23 REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and main power switch located on the bottom left hand side is at position I. When operating the remote make sure you point the remote to the centre of the fireplace and make sure each time you press the button the buzzer inside the unit will bee p once.

  • Page 24: Installing Wall Thermostat

    INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS Wire the wall thermostat prior to installing the fireplace. WALL THERMOSTAT WIRING(24 VAC) Install Wall Thermostat per instructions provided with kit and per the following information: 1. Turn off circuit breaker. 2. Remove cover plate located on the left side of appliance. Pull the wire out and cut the inside thermostat.

  • Page 25: Replacement Parts

    REPLACEMENT PARTS This list contains replacement parts PART NUMBER DESCRIPTION QTY. BI-30-XTRASLIM BI-40-XTRASLIM BI-50-XTRASLIM BI-60-XTRASLIM 3147501 3109501 3057501 3110501 TRIM 10201505 ADJUSTABLE SCREW 3133009 FRONT GLASS BRACKET 10701273 10701248 10701250 10701252 FRONT GLASS 10702197 10702182 10702184 10702186 FLAME EFFECT GLASS...

  • Page 26: Exploded View

    EXPLODED VIEW...

  • Page 27: Wiring Diagram

    Wiring diagram...

  • Page 28: Trouble Shooting

    TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns off and Appliance has overheated and Turn off the main switch, allow...

  • Page 29: Service History

    SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...
