INSTALLATION AND OPERATION INSTRUCTIONS FOR BI-SLIM
BI-40-SLIM
BI-50-SLIM
BI-60-SLIM
BI-72-SLIM
BI-88-SLIM
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
UNITS
SAFETY INFORMATION
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BI-60-SLIM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Amantii BI-60-SLIM

  • Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR BI-SLIM UNITS BI-40-SLIM BI-50-SLIM BI-60-SLIM BI-72-SLIM BI-88-SLIM SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
  • Page 2: Table Of Contents

    Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS............................3 UNPACKING AND TESTING APPLIANCE .......................5...
  • Page 3: Important Instructions

    IMPORTANT INSTRUCTIONS 1. Read all instructions before installing or using this heater. 2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front of the heater; keep them away from sides and rear as well. 3.
  • Page 4 Cautions ·Always install the heater in accordance with this guide. If in doubt obtain expert advice. ·Always make sure the electrical socket is accessible and located adjacent to, but not above the heater. ·Always disconnect the heater from the electrical supply before Do’s moving it, or carrying out cleaning, maintenance.
  • Page 5: Unpacking And Testing Appliance

    UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. Test all aspects of its operation (manual switches, remote and heater) to make sure all components operate correctly.
  • Page 6: Bi-40-Slim

    BI-40-SLIM This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated Watts 1500W Max electric room appliances in the United NO HEATER States and Canada. If you need MOTOR HEATER assistance during installation, please Appliance Width...
  • Page 7: Bi-50-Slim

    BI-50-SLIM This appliance has been tested in accordance Model Number BI-50-SLIM with the UL Standard 2021 for fixed and Voltage 120V AC 60Hz location dedicated electric room appliances Watts 1500W Max in the United States and Canada. If you need NO HEATER assistance during installation, please contact MOTOR HEATER...
  • Page 8: Bi-60-Slim

    BI-60-SLIM This appliance has been tested in accordance Description Built-in Appliance with the UL Standard 2021 for fixed and Voltage 120V AC 60Hz location dedicated electric room appliances Watts 1500W Max in the United States and Canada. If you need...
  • Page 9: Bi-72-Slim

    BI-72-SLIM This appliance has been tested in accordance Description Built-in Appliance with the UL Standard 2021 for fixed and Voltage 120V AC 60Hz location dedicated electric room appliances Watts 1500W Max in the United States and Canada. If you need NO HEATER assistance during installation, please contact MOTOR HEATER...
  • Page 10: Bi-88-Slim

    BI-88-SLIM This appliance has been tested in accordance Description Built-in Appliance with the UL Standard 2021 for fixed and Voltage 120V AC 60Hz location dedicated electric room appliances Watts 1500W Max in the United States and Canada. If you need NO HEATER assistance during installation, please contact MOTOR HEATER...
  • Page 11: Safety Drill Screw Area

    SAFETY DRILL SCREW AREA There is a safety drill screw area as show below. Please make sure that the fix screws are in this area. Sa fe ty d rill s cre w a re a (Da rk a re a ) T h e m a n u a l c o n tro l p a d p o s itio n HARD- WIRE INSTALLATION Turn off the appliance completely and let cool before servicing.
  • Page 12: For Bathroom Use

    2. Attach the wiring to the junction block. Please make sure the live wire goes into the “L”, the neutral wire into “N” and the ground wire into “G”. 3. Put the plate back and screw back. FOR BATHROOM USE If this unit is installed in a bathroom it must be protected by a GIF receptacle or circuit.
  • Page 13: Outdoor Installations

    OUTDOOR INSTALLATIONS The BI-SLIM series electric fireplaces are suitable for installation in outdoor areas protected from direct water impingement. In addition to maintaining the listed mantel and combustibles clearances, a rain protection overhang factor of 1/2 shall be constructed to the front and to each side of the installed appliance.
  • Page 14: Installation

    The rough wall opening size of the fireplace: W(") D(") H(") BI-40-SLIM BI-50-SLIM BI-60-SLIM BI-72-SLIM 73 1/2 BI-88-SLIM 89 1/4 1. Take out the unit from the box. Please do the pre-test before you install the fireplace. Pull out the optional trim from the unit as shows below.
  • Page 15 2. Remove the framing plates from the unit framing plate 3. Re-fix the framing plates to the unit as the picture shows framing plate...
  • Page 16 4. Bend up the framing plates. 5. Put the unit into the opening.
  • Page 17 6. Drive the mounting screws into the framing plates on the unit and the wall studs. framing plate 7. After checking that the fireplace operates properly, cover the glass panel with protective plastic bag and install plywood or drywall. NOTE: In order to use the supplied trim kit, the thickness of the desired wall finish can not exceed 1 inch.
  • Page 18 8. Decorate the plywood or drywall with glazed tile, wallpaper, etc. Fireplace 9. Put back the trim that you’ve removed from the unit at STEP 1. trim...
  • Page 19: Panorama Cover Installation

    PANORAMA COVER INSTALLATION Make sure install the pan-cover when the fireplace used in outdoors. Remove the cover from the packaging. The handles will need to be attached to the cover with the provided hardware as shown in fig. 1 Fig 1 First, place a plate washer and then a spring washer on the screw as shown in fig.
  • Page 20: Media Options

    Media Options The BI-40-SLIM, BI-50-SLIM, BI-60-SLIM is shipped with 3 large glass nuggets, clear and blue diamond shaped media . The BI-72-SLIM, BI-88-SLIM is shipped with 6 large glass nuggets, clear and blue diamond shaped media . Fire Glass Media-Log Installation 1.
  • Page 21: Operation

    OPERATION The fireplace can be operated either by the switches located on the left bottom of the fireplace unit or by supplied remote control. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1. The main power ON/OFF switch in position O, the fireplace is OFF. 2.
  • Page 22 REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and main power switch located on the bottom left hand side is at position I. When operating the remote make sure you point the remote to the centre of the fireplace and make sure each time you press the button the buzzer inside the unit will bee p once.
  • Page 23: Installing Wall Thermostat

    INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS Wire the wall thermostat prior to installing the fireplace. WALL THERMOSTAT WIRING(24 VAC) Install Wall Thermostat per instructions provided with kit and per the following information: 1. Turn off circuit breaker. 2. Remove cover plate located on the left side of appliance. Pull the wire out and cut the inside thermostat.
  • Page 24: Replacement Parts

    REPLACEMENT PARTS This list contains replacement parts DESCRIPTION QTY. NO. BI-40-SLIM BI-50-SLIM BI-60-SLIM BI-72-SLIM BI-88-SLIM 602120B 602120B 602120B 602120B 602120B BLOWER AND HEATER ASSEMBLY FIREPLACE BOX 10104010 10104010 10104010 10104010 10104010 SWITCH 601032B 601032B 601032B 601032B 601032B CONTROL PANEL 601097...
  • Page 25: Exploded View

    EXPLODED VIEW...
  • Page 26: Trouble Shooting

    TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns off and Appliance has overheated and Turn off the main switch, allow...
  • Page 27: Service History

    SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...
