CONVEYOR OVERVIEW

CONVEYOR TYPES

This Section describes the five types of conveyor transport systems available on the Vitronics-Soltec Reflow
Ovens. They are:
1)
2)
3)
4)
5)
The Mesh Belt system is base standard conveyor on Vitronics-Soltec Reflow Ovens. The Rail-Only, Combo,
XCS, or MBS Conveyor Systems are offered on new ovens by special order.
BELT-ONLY MESH BELT CONVEYOR SYSTEM
The mesh belt conveyor system is used to process single sided surface mount printed circuit boards.
October 10, 2008
VITRONICS-SOLTEC REFLOW SOLDERING SYSTEMS
Belt-Only Mesh Belt Conveyor System.
Rail-Only Edge Rail Conveyor System.
Combo Edge Rail and Belt Conveyor System
XCS Edge Rail System with Extruded Center Support
MBS Combination Edge Rail and Belt System with Metal Band Support
7
XPM2 / XPM3 Technical Reference Manual Conveyor Systems
