PURPOSE OF THIS MANUAL & WHO SHOULD USE IT
This manual is intended to meet the needs of service personnel responsible for the regular service of Vitronics-
Soltec Reflow Ovens. Vitronics-Soltec does not consider this manual a specification for Vitronics-Soltec products
or any components contained in those products and reserves the right to change information contained in this
manual without notification.
This manual is intended to be a reference. Some of the topics explain manufacturing and assembly methods and
practices; however, many topics deal with specific service information and methods. Hopefully, insight will be
provided about the various sub-systems of the electrical control system to allow quick identification of problems
and possible solutions.
IMPROPER SAFETY PRECAUTIONS OR UNSAFE WORK METHODS MAY RESULT IN SERIOUS INJURY!
This Manual is NOT INTENDED as a substitute for proper technical training or educational
background in the various technologies used in reflow ovens.
This manual is for service of Vitronics-Soltec ovens by Trained Qualified Personnel. An appropriate
understanding and use of safety procedures when working on and around the oven is
NECESSARY.
The following conditions may be encountered when working on any reflow oven:
Þ High Temperature areas
Þ High Voltage areas
Þ High Current areas
Þ Moving Mechanical Parts and Systems
Þ Heavy Components
Þ Sensitive Electronic Components
Some people who might use this manual are:
October 10, 2008
VITRONICS-SOLTEC REFLOW SOLDERING SYSTEMS
Vitronics-Soltec service technicians
Customer service technicians
Customer facilities maintenance personnel
Technical operators
ATTENTION
Caution
o
(up to 350 C)
(up to 480 VAC)
(up to 200 Amps)
