VITRONICS-SOLTEC REFLOW SOLDERING SYSTEMS
CONTROL PANEL SYMBOLS
Use Caution
NOTICE
WHEN CONTROL POWER IS INTERUPTED, PARTS OF THE OVEN ARE ELECTRICALLY
POWERED AND DANGEREROUS TO PERSONNEL!
SELECTOR SWITCH
KEY SWITCH RAISES
ADJUSTS RAIL
AND LOWERS THE
IN or OUT
OVEN HOOD
OPERATOR CONTROL STATION
4
October 10, 2008
XPM2 / XPM3 Technical Reference Manual
Conveyor Systems
