Advantech MIC-75S20 Startup Manual

MIC-75S20
PCIE Expansion Module for MIC-7 Series
Embedded System
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following items have been shipped:
1. MIC-75S20 Module x1
2. MIC-75S20 Startup Manual x1
3. Warranty Card
4. Card Clamp Pad x 4
5. Wall-Mount BKT (Left) x1
6. Wall-Mount BKT (Righ) x1
7. SATA cable x 2
8. SATA power cable x2
9. HDD tray power cable x1
If any of these items are missing or damaged, please
contact your distributor or sales representative immediately.
Acrobat Reader is required to view any PDF file.
Note:
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the MIC-75S20 Series Rev. A1.
Part No. 20015S2000
Printed in China
P/N: MIC-75S20-00A1E
P/N: 20015S2000
P/N: 2190000902
P/N:1990024989T000
P/N: 1960070545N001
P/N: 1960070543N001
P/N : 1700014518
P/N : 1700023566-02
P/N : 1700024985-01
1st Edition
February 2016
Specifications
PCIe Slots
• One PCIex16 socket
Note 1: PCIEx16 power consumption supports 35W.
• One PCIex4 socket
Note 1: PCIEx4 supports 15W power consumption.
Note 2: MIC-75S20 does not support MIC-7300 series
systems.
• Storage: 2 x 2.5' hot swappable HDD tray
Environment
• Operating Temperature:
-20 ~ 60 °C with 0.7 m/sec air flow: with 1 x Industrial SSD
without PC expansion boards
0 ~ 45 °C with 0.7 m/sec air flow: with 1 x 2.5" HDD
without PC expansion boards
• Storage Temperature: - 40 ~ 85 °C (-40 ~185 °F)
• Relative Humidity: 95% @ 40 °C (non-condensing)
Mechanical
• Dimensions (H x W x D): 92 x 90 x 230 mm
Note 1: Please add a fan onto the i-module, if add-on
card total power consumption is over 45W.
