Vicon Roughneck V2008PTZ-IR Installation & Operation Manual

Ptz dome camera

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Installation & Operation Manual

R-180-1

V2008PTZ-IR

Roughneck PTZ Dome Camera

XX341-00-00

Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your

requirements or that the operation will be entirely error free or perform precisely as described in the documentation.

This system has not been designed to be used in life-critical situations and must not be used for this purpose.

Document Number: 8009-8341-00-00 Product specifications subject to change without notice.

Vicon Industries Inc.

Tel: 631-952-2288) Fax: 631-951-2288

Toll Free: 800-645-9116

24-Hour Technical Support: 800-34-VICON

(800-348-4266) UK: 44/(0) 1489-566300

www.vicon-security.com

Table of Contents

Need help?

Do you have a question about the Roughneck V2008PTZ-IR and is the answer not in the manual?

Questions and answers

Summary of Contents for Vicon Roughneck V2008PTZ-IR

Page 1 XX341-00-00 Vicon Industries Inc. Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your Tel: 631-952-2288) Fax: 631-951-2288 requirements or that the operation will be entirely error free or perform precisely as described in the documentation.
Page 2: Table Of Contents
Accessing the Camera’s Configuration Menu (Graphical User Interface) 10 Network - 802.1x ................40 Pronto Device Manager ..............10 Network - SNMP ................41 Web Browser .................11 Network - Firewall ................42 Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 3 Event - SMTP ..................60 Event - Network Storage ..............62 Event - Relay Handler ..............64 Event - SD Record Handler .............65 Event - TCP Notify ................69 Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 4: Preface
▪ Follow all warnings and cautions in this manual. in any form or by any means without the prior written consent from Vicon ▪ Do not place the unit on an unstable surface, cart, or stand.
Page 5: Rohs Compliance
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm. In order to meet the RoHS compliant directives, Vicon has established an engineering and manufacturing task force to implement the introduction of green products.
Page 6: Installation Recommendations
Technical Support and Assistance Ensure you have a stable, clean working environment. Dust and dirt can get 1. For the most updated information of Vicon products, visit Vicon’s website into components and cause a malfunction. Use containers to keep small at www.vicon-security.com.
Page 7: Conventions Used In This Manual
Caution: CAUTION! CAUTION! CAUTION! Information to avoid damaging components or losing data. Note: Provides additional information to complete a task easily. viii Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 8: Package Contents
Quick Installation Guide The camera accessory bag includes a safety rope. Refer to the illustration below for the location of the safety rope hole. Safety Rope Hole Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 9: Chapter 1: Product Introduction
▪ Privacy Mask: 32 individual 3D privacy masks ▪ Image Stabilization: OIS ▪ Defog (Optical): Support ▪ Speed Dry: Support ▪ Analytics: Object Tracking (people) Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 10 ▪ Sunshield: Support ▪ ONVIF: Profile S, G, T ▪ Dimensions: 9.8*14.2*(ø)7.5 in. (250*362*(ø)190 mm) ▪ Weight: 11 lb (5 kg) ▪ Certification (compliant): CE/FCC Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 11: Important Guidelines For Camera Power Adapter Usage
Note that these methods can help resolve voltage drop issues caused by power adapter may vary depending on the region of shipment. long distance cables, ensuring proper camera operation. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 13: Di/O & Function Description
24 VAC INPUT LINE OUT+ Reset Button ALARM IN- LINE IN- Power Switch ALARM IN+ LINE IN+ ALARM OUT- RJ-45 PoE LAN Port ALARM OUT+ Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 14 (A) on the wall mount and pull the cable through the wall mount; fasten screws to secure the wall mount on the wall. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 15 Hook the other end of the safety wire on (D). Connect the cable with Attach camera and wall mount [align (E) with (F)]. terminal block and plug-in the corresponding holes and RJ-45 connector. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 16 This is the wrong installation for reference. DO NOT let the lens face angle over the A line. SD Card The lens should face down Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 17: Wall Mount Bracket Assembly
(the hole inf tube). Tighten the hexagonal screw (A) with proper tool. stainless steel anchors (x3). Pull the safety wire and cables through the bottom case of pendant mount and tighten the screws. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 18 Connect the cable with terminal block and plug-in the corresponded holes and RJ-45 connector. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 19 This is the wrong installation for reference. DO NOT let the lens face angle over the A line. SD Card The lens should face down Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 20 Chapter 1: Product Introduction DO NOT install the product on unstable poles, brackets, surfaces or walls. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 21: Chapter 2: Camera Configuration
User Manual be found on Vicon’s website. The camera can be accessed directly from its web page or using Vicon’s PRONTO Device Manager, which can be found on Vicon’s website. • Upon startup of the PRONTO Device Manager, the tool’s auto-discovery function generates a list of the discovered cameras on the network in a Since this is a network-based camera, an IP address must be assigned.
Page 22: Web Browser
(the default Admin user name is ADMIN) and password (customer selected) according to the parameters required. If this is the first time logging in, re-type password and click Save Password. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 23: Main Screen Overview
Video Format: Set the video format; the available options are H.264 and MJPEG. • PTZ Control: Select this option to manually control the PTZ. Snapshot Capture the current image. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 24 Chapter 2: Camera Configuration Pause Pause the image. Speed Dry Activate the speed dry function. Maximizing the Window Click to go full screen. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 26: Video - Video Configuration
Enter a numeric value from 1~255 to configure max dynamic GOP. Bit Rate Configure the bit rate; the range is 500~12000 kbits/s. Users can enter the value or adjust it using the slider bar. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 27 Enter a numeric value from 1~255 to configure max dynamic GOP. Bit Rate Configure the bit rate; the range is 500-8000 kbits/s. Users can enter a value or adjust it using the slider bar. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 28 Enter a numeric value from 1~255 to configure max dynamic GOP. Bit Rate Configure the bit rate; the range is 500-8000 kbits/s. Users can enter a value or adjust it using the slider bar. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 29: Video - Audio Configuration
High, Mid, and Low. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 30: Image - Exposure
The range is 1/7~1/16000. It is available for editing when Lock is selected in the AE Mode. Gain Control The available options are OFF, High, Medium, and Low. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 31 The available options are OFF and Noise Reduction Enable this function to reduce noise. The available options are OFF, High, Medium, and Low. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 32 The available options are Auto, Sync Day Night, Force Day, and Force Night. Current Day NIght Level Select the Day to NIght and Night to Day Switching Level from the dropdown list, 1 - 20. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 33: Image - Basic Settings
Configure the sharpness of the image; the range is 0~255, with 0 being the lowest sharpness. Enter a value or adjust the slider bar to increase or decrease the value. The default value is 127. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 34: Image - Roi
Click the Set Area button for the setting to take effect. The ROI area will then be seen on the video stream. Click the Del Area button or select OFF (step 1) to delete the ROI area. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 35: Image - Osd
+ date/time, preset, or direction. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 36: Ptz - Manual
After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Pan Left Limit Click the Set button to configure pan left limit. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 37: Ptz - Preset
(1~256) and click Delete to remove the preset. Preset go (1~256) The preset will show in the drop-down menu; select preset and click Run to operate. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 38: Ptz - Cruise
Click the Set button to start record. Record End Click the Set button to end record. Cruise Run Select the cruise and click the Run to operate. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 39: Ptz - Auto Pan
After all the settings are complete, click the Save button to apply the Auto Pan Path configurations for the changes to take effect Select the auto pan path from 1~4, then click Run to operate. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 40: Ptz - Preset Tours
After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Preset Tours Run Select a Preset Tours from 1~8; then click the Run button to operate. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 41: Ptz - Home Function
Available options are 1~256. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 42: Ptz - Tilt Range
Enter a maximum tilt angle from 80~90 degree. The default is 90 degree. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 43: Ptz - Privacy Zone
Click Set Area button when all options are configured. To remove the mask, choose the mask number and click Del Area button. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 44: Ptz - Ptz Setting
Click the Set button to position East. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 45: Ptz - Track
Click Stop to end tracking. Click Run button to start tracking. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 46: Ptz - Schedule
If the camera is executing a schedule and there is an interruption, it will resume the schedule according to the configured idle time once the interruption is completed. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 47: Network - Basic
There are 3 modes that can be selected: Stateless, Stateless DHCP, and Stateful DHCP. Enable IPv6 Auto; then the address prefix won’t be able to be inputted. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 48 Configure the web URL address. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 49: Network - Ftp
1~10. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 50: Network - Ssl
Press Next after selecting the installation method. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 51: Network - 802.1X
Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 52: Network - Snmp
Trap Configuration Specify the destination IP address to send the SNMP trap messages. Download MIB Download MIB file for SNMP. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 53: Network - Firewall
A total of 8 IP addresses can be added to the list. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 54: Network - Ldap
LDAP server. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 55: Network - Ddns
Type the same password again for confirmation. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 56: Network - Rtsp
Default URL Path of Stream 1 to Stream 3 Stream 1: rtsp://cameraIP/stream1 Stream 2: rtsp://cameraIP/stream2 Stream 3: rtsp://cameraIP/stream3 Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 57 After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Configure the time-to-live threshold of the multicast datagram before it is discarded by the router. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 58: Network - Bonjour / Upnp
Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 59: System - Date / Time
After all the settings are complete, click the Save button to apply the Time Zone configurations for the changes to take effect. Select the time zone relevant to your location in the drop-down menu. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 60: System - Maintenance
Click this button to restore all the camera’s setting back to factory default except IP address (keeps all the settings on the Network Basic setting page). Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 61 Click Switch Video System button to select a desired video system type. Switching the video system type will cause the camera to restart and reset to default. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 62: System - User Management
Press New User to add a new account and set up the authorization level of this user from the following User Information. To delete an account, press the Delete User button. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 63 Retype the same password to confirm. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 64: Event - Alarm Handler
After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Close Press to exit the schedule setting page. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 65: Event - Motion Detection
Set up the minimum size of the object to capture motion (default is 5% for the scene). Click Set to use the cursor to select the size. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 66 After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Close Press to exit the schedule setting page. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 67: Event - Museum Search
Configure the sensitivity of Museum Search; the range is 1 to 100. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 68: Event - Tampering Alarm
After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Close Press to exit the schedule setting page. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 69: Event - Network Loss Detection
Enable or disable the network loss detection function. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 70: Event - Ftp Upload
Select Sub Folder or Single Folder. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 71: Event - Smtp
Subject Specify the subject of the message. Message Specify the message content. Attach JPEG Snapshot Enable or disable e-mail delivery of trigger event snapshots. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 72 Alarm, Motion, or Tampering. A maximum of 10 e-mail addresses can be configured. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 73: Event - Network Storage
Specify the IP address of the network storage server. Share Specify the shared folder name on the network storage server. Record Type Specify the event trigger action. The options are Snapshot and Video. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 74 Network Storage Status will display not_mounted. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 75: Event - Relay Handler
When night mode is detected, the external IR LED will be triggered. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 76: Event - Sd Record Handler
• Enable Trigger Alarm Detection • Enable Trigger Motion Detection • Enable Trigger Tampering Detection • Enable Trigger Network Loss Detection • Enable Trigger Scheduled Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 77 Enable or disable SD card overwrite. Record Type Configure the recording method to record the stream on to the SD card. The options are Video and Snapshot. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 78 Network_Rec, and ScheduledSD, respectively. Server Path Configure a folder name on the SD card. The default folder names are videoAlarm, videoMotion, videoTampering, videoNetwork, and videoSchedule, respectively. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 79 Available options are None, AllDay, Schedule1, and Schedule2. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 80: Event - Tcp Notify
Input messages for the detection. Save After all the settings are complete, click the Save button to apply the configurations for the changes to take effect. Copyright © 2024 Vicon Industires Inc. All Rights Reserved. V2008PTZ-IR PTZ Dome Camera User Manual...
Page 81 VICON INDUSTRIES INC. For office locations, visit the website: www.vicon-security.com...
