Quick Guide
Roughneck AI V2008B-W310LPR and V2008B-W818LPR
License Plate Recognition Outdoor Vandal Bullet Camera
XX324-20-02
Cybersecurity Notification:
accessing the device. To that end, these network cameras do not have a default password. A user defined
password with minimum password strength requirements must be set to access the device. See page 15 of
this Quick Guide for set-up instructions.
Be sure to check Vicon's website to be see if you have the most up-to-date camera firmware.
Vicon Industries Inc. does not warrant that the functions contained in this equipment will
meet your requirements or that the operation will be entirely error free or perform precisely as
described in the documentation. This system has not been designed to be used in
life-critical situations and must not be used for this purpose.
Document Number: 8009-8324-20-02 Product specifications subject to change without notice.
Issued: 1/2023 Copyright © 2023 Vicon Industries Inc. All rights reserved.
All network connected devices should use best practices for
Link to Setup Guide
Vicon Industries Inc.
Tel: 631-952-2288) Fax: 631-951-2288
Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON
UK: 44/(0) 1489-566300
www.vicon-security.com
(800-348-4266)
Advertisement
Table of Contents
Related Manuals for Vicon Roughneck AI V2008B-W310LPR
Summary of Contents for Vicon Roughneck AI V2008B-W310LPR
- Page 1 See page 15 of this Quick Guide for set-up instructions. Be sure to check Vicon’s website to be see if you have the most up-to-date camera firmware. Link to Setup Guide Vicon Industries Inc.
-
Page 2: Table Of Contents
V2008B-LPR Series Quick Guide Table of Contents Product Overview Physical Characteristics Installation and Connection Package Contents Installation 2.2.1 Checking Appearance 2.2.2 LPR Installation Guidelines 2.2.3 Mounting Preparation 2.2.4 Mounting the Camera 2.2.5 Connecting the Cables 2.2.6 Adjusting the Camera Position 2.2.7 Adjusting the Protection Shield Hood Connection... - Page 3 V2008B-LPR Series Quick Guide WARNING This camera operates at 12 VDC/24 VAC/PoE+ (IEEE 802.3at Class 4). Installation and service should be performed only by qualified and experienced technicians and comply with all local codes and rules to maintain your warranty. We are NOT liable of any damage arising either directly or indirectly from inappropriate installation which ...
- Page 4 V2008B-LPR Series Quick Guide FCC Compliance Statement Information to the user: This unit has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 5: Product Overview
V2008B-LPR Series Quick Guide 1 Product Overview 1.1 Physical Characteristics Figure 1 - 1: Physical Dimension Unit: mm (in.) Figure 1 - 2: Parts Pictorial Index... - Page 6 V2008B-LPR Series Quick Guide Name Description Connect an Ethernet cable terminated with RJ-45 connector to RJ-45 Ethernet/PoE Port the PoE RJ-45 port for both power supply and network connectivity purposes simultaneously. Power the camera via a 12 VDC or 24 VAC power source. Pay 12 VDC or 24 VAC Port attention to the polarities when connecting to 12 VDC power supply.
- Page 7 V2008B-LPR Series Quick Guide Figure 1 - 3: Internal Interface Pictorial Index Interface Description Insert a micro SD card (supplied) into the slot for recording and file Micro SD Card Slot storage. Reset Button Press the button for 1 second to reboot the camera. Press the button for 6 seconds to restore camera’s settings to factory Default Button default settings.
-
Page 8: Installation And Connection
V2008B-LPR Series Quick Guide 2 Installation and Connection Package Contents Check if all items listed below are included in the packing box. LPR Bullet Camera * 1 Plastic Anchor * 6 Self-tapping Screw (T10) * 6 T10 Security Torx Bit * 1 Mounting Template * 1 SD Card * 1 Installation... - Page 9 6.6 – 19.7 ft (2 - 6 m) for the 3.6-10 mm lens or 16 – 36 ft (5 – 11 m) for the 8-18 mm lens. Refer to the Vicon LPR Camera Setup and Integration Guide for details on setting up the proper field-of-view (FOV).
-
Page 10: Mounting Preparation
V2008B-LPR Series Quick Guide 2.2.3 Mounting Preparation Insert the SD card into the slot. Refer to Figure 1-3. The SD card then has to be recognized and formatted in the camera’s GUI, Event Setting, SD Card tab. Refer to the LPR Camera Setup Guide for details. Use the guide pattern to mark out and prepare a mounting area. - Page 11 V2008B-LPR Series Quick Guide Figure 2 - 3: Connecting the Wires Type II – Mounting Surface Hole Note When installing your camera using method (Type II), it is recommended that the connections be made in a junction box to protect against environmental factors such as dust and water. Position the camera to match the 6 holes embedded with the plastic anchors on the surface.
-
Page 12: Connecting The Cables
V2008B-LPR Series Quick Guide 2.2.5 Connecting the Cables 1. Based on your needs, connect the power cable to the power port via one of the following 3 options. • 24 VAC: Connect a power cable that supplies 24 VAC power source to the terminal block and then insert the terminal block into the power port. - Page 13 V2008B-LPR Series Quick Guide Locking Screw Figure 2 - 6: Adjusting the Camera Position Limitation for three axes position: Pan range: ±360° Caution Tilt range: 0° ～ 90° Rotation range: ±360° Note After adjustments, make sure to tighten each joint to prevent the camera from moving.
-
Page 14: Adjusting The Protection Shield Hood
V2008B-LPR Series Quick Guide 2.2.7 Adjusting the Protection Shield Hood This camera is designed with capability to operate under rugged environments and may possibly be subject to the influence from sunlight or rain. The protection shield hood is consequently attached to the camera to prevent from impact from those outside effects. -
Page 15: Connection
V2008B-LPR Series Quick Guide 3 Connection Network The camera, which is equipped with Ethernet RJ-45 network interface, can deliver live view image in real time via both Internet and Intranet manners. Review the topology drawings shown below. System Requirements The table below lists the minimum requirement to implement and operate the camera. It is recommended not to use any hardware/software component below these requirements for proper performance. -
Page 16: Connecting Process
The camera can be accessed directly from its web page or using Vicon’s PRONTO Device Manager, which can be found on Vicon’s website. Note that when accessing the camera for the first time, a message will display to reset the password. -
Page 17: Pronto Device Manager
V2008B-LPR Series Quick Guide PRONTO Device Manager PRONTO is Vicon’s device manager (Discovery tool) that can be used to discover all Vicon cameras on a system. The complete User Manual can be found on Vicon’s website. Figure 3 - 2: PRONTO Interface Upon startup of the PRONTO Device Manager, the tool’s auto-discovery function generates a list of...
