HD-KVM 200M EXTENDER MANUAL
We reserve the copyright have product details, if the parameters
and a minor change and appearance from time to tome, the factory
specifications shall prevail, the company reserves final
interpretation
Product Features
1.Transmit HDMI signal up to 200m over a single CAT5/5e cable.
2.Support video resolution up to 1920×1080@60Hz.
3.Support local and remote HDMI monitors.
4.Supports USB(keyboard and mouse).
5.Built-in lightning protection.
Industrial Products
Information Release Screen Splicing
Video Conference Teaching Projection
@ 2016. all rights reserved
LM-K200H
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LINK-MI LM-K200H
Summary of Contents for LINK-MI LM-K200H
- Page 1 HD-KVM 200M EXTENDER MANUAL LM-K200H Industrial Products Information Release Screen Splicing Video Conference Teaching Projection We reserve the copyright have product details, if the parameters and a minor change and appearance from time to tome, the factory specifications shall prevail, the company reserves final interpretation @ 2016.
-
Page 2: Product Introduction
Product Introduction LINK-MI LM-K200H The HD-KVW extender, used for HD and non-condensed signal up to 200 meters, consists of a sender and a receiver. This product through a CAT5/5e or above Copper twisted pair (line sequence: white w/orange . orange. white w/green . blue . white w/blue. green. white w/brown . brown) extends those up to 1920 *... -
Page 3: Connection Diagram
Connection diagram Note: This extender supports independent digital audio. If you do not need,you can connect it with the HDMI line to output video and audio. - Page 4 Parameter Items Description Transmission Signal Type HDMI,USB Mouse,Independent Digital Audio Function Transmission Channel 1 Line Transmission Distance 200m Power Supply Mode External Power Supply Power Section Adaptive Voltage Range 5VDC 1A Support HDMI Version HDMI1.3 Support HDCP Version HDCP1.2 HDMI Resolution 1920*1080@60HZ downward Compatibility HDMI Performance Peak Transfer Rate...
-
Page 5: Packing List
Packing List * A pair of 200 meters HD-KVM extender * 2 (5V 1A) power adapter * Operating manual Matters Need Attention 1.Due to the design of the HDMI interface is specific,all equipments with HDMI interface are not allowed using hot swap operation in principle.In order to protect HDMI as much as possible during the process of installing and connecting the HDMI extender, please power off the device power supply (DPS) that host and display needs to be connected to.When the HDMI line and cable are connected，plug the HDMI extender and open the power supply...
