- Page 1 LM-DEX60 DVI-CAT-60M Extender U S E R M A N U A L...
- Page 2 Operating Instructions Dear Customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Table of contents Features Specifications Package Contents Panel Descriptions Connecting and Operating Maintenance...
-
Page 3: Specifications
Specifications Operating Temperature Range -5 to +35℃(+23 to +95℉) Operating Humidity Range 5 to 90%RH (No Condensation) Input Video Signal 0.5-1.0 Volts P-P Input DDC Signal 5 volts p-p(TTL) Support Video Format DTV/HDTV:UP TO 1920x1200 Video Output DVI/HDMI DTS-HD Master Audio、Dolby true-HD Support Audio Format etc. - Page 4 Panel Descriptions Transmitter Panel OUT：RJ45 OUT EDID: Copy EDID or EDID reset DC5V: 5V Power input PW: Power LED SIG: Signal input led DVI IN: DVI/HDMI input Receiver Panel IN: RJ45 IN DC5V： 5V Power input PW: Power LED SIG: Signal input led DVI OUT: DVI/HDMI output Connecting and Operating 1) Connect the DVI signal sources (Such as PC etc) to...
- Page 5 Attention: Insert/Extract cables gently. Product Service 1) Damage requiring service: The unit should be serviced by qualified service personnel (a) The DC power supply cord or AC adaptor has been damaged; (b) Objects or liquids have gotten into the unit; (c) The unit has been exposed to rain;...
- Page 6 During the "Labor" Limited Warranty period there will be no charge for labor. During the "Parts" warranty period, there will be no charge for parts. You must mail-in your product during the warranty period. This Limited Warranty is extended only to the original purchaser and only covers product purchased as new.
