- Page 1 LM-EX53 HDBaseT Ultra Slim Extender Kit HDR, 4K@60Hz 4:4:4, up to 40M Operating Instruction...
-
Page 2: Safety Precautions
Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. - Page 3 CONTENTS 1.INTRODUCTION................4 2.APPLICATIONS.................4 3. PACKAGE CONTENTS..............4 4. SYSTEM REQUIREMENTS............4 5. FEATURES..................5 6. SPECIFICATIONS................5 7. OPERATION CONTROLS AND FUNCTIONS......6 7.1 Transmitter Front and Rear............6 7.2 Receiver Front and Rear Panels............7 8. CONNECTION DIAGRAM............8 9. MAINTENANCE................9 10. PRODUCT SERVICE..............9 11. WARRANTY..................9 Operating Instruction Operating Instruction...
-
Page 4: Package Contents
Operating Instruction 1. INTRODUCTION 9.MAINTENANCE This Model allows HDMI signals to be transmitted over a Single CAT5e/6 cable. This solution has the Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to added features of RS232 and 2-way IR control functionality over the same CAT5e/6 cable. It can clean this unit. -
Page 5: Specifications
Transmit up to 70m under 1080p, 40m under 4k Support HDR10, 3D With 1x looping HDMI out at Transmitter and 2 x HDMI out at Receiver Bi-directional wide band IR and RS232 Pass through Dual POC (Receiver powered by transmitter or transmitter powered by Receiver) ... - Page 6 7.1 Transmitter Front and Rear 1 HDMI Out1: Connect to a HDMI equipped TV/Monitor for display of the HDMI input source signal 2 HDMI out2: Connect to a HDMI equipped TV/Monitor for display of the HDMI 1 HDMI In: Connect to HDMI source equipment such as DVD or Blu-ray player input source signal 2 HDMI Out: Connect to a HDMI equipped TV/Monitor for display of the HDMI 3 IR Out: Connect to the supplied IR blaster cable for IR signal transmission.
