270 D EG R E E AWNI N G
MO UN TS
INS TAL L I NSTRUC T ION S
Please read the mounting instructions below carefully before attempting to install.
Be sure to check out the install video on the product page, if available.
Thank you for purchasing from JcrOffroad! Checkout our website, www.jcroffroad.com for other great off-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don't hesitate to call us at 269-353-1184!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for JCROffroad VRKAWN270
Summary of Contents for JCROffroad VRKAWN270
- Page 1 Be sure to check out the install video on the product page, if available. Thank you for purchasing from JcrOffroad! Checkout our website, www.jcroffroad.com for other great off-road products. Be sure to rate and review our product online. If you have any questions or are missing parts, please...
-
Page 2: I Nclu D E D Hardware
I NCLU D E D HARDWARE INCLUDED BO LT PACK(S ) 0 46-015 7 Note: Some Victory 4x4/JCR Offroad/SquatchProof products share hardware kits. Any extra hardware you may recieve that is not listed below can be repurposed or discarded. 1/4”-20 x .75” 1/4”-20 T-Slot Stud Flange Locknut... -
Page 3: Included Parts
I NCLU D E D PARTS Awning Mount... -
Page 4: Installation
INSTA L L AT I ON To install, you can either start by loosely installing the 270 brackets right to your awning using manufactuer supplied hardware, leaving room for left to right adjustment when installing the assembly to your roof rack or bed rack. - Page 5 INSTA L L AT I ON To install the brackets to your crossbars, first measure how wide your awning is relative to your rack to know where to mount your brackets in the most optimal position. Then slide in the provided T-slot bolts into the top slots of your crossbars.
- Page 6 INSTA L L AT I ON If you are mounting to a bed rack, you will use the larger (2) slots on the top face of the brackets with the supplied hex head bolts, washers and flange nuts, as shown in the orientation below.
- Page 7 I NS TAL L ATI ON With your brackets in place on your roof rack or bed rack, refer back to step 2a if you need help on how to mount the awning to your brackets. Once your awning is in place on your roof or bed rack, make any final adjustments that may need to be made as far as clearances to your vehicle, rack, or any accessories you may have.
