2. The indicator 1/X shown on the bottom of the screen stands for the current
page/total page number. Swipe the screen from the right/left to advance/return to the
next/previous page.
There are 3 types of display modes available for data viewing, allowing you to
view various types of parameters in the most suitable way.
 Value – This is the default mode which displays the parameters in texts and
shows in list format.
 Graph – Displays the parameters in waveform graphs.
 Combine – This option is mostly used in graph merge status for data
comparison. In this case, different items are marked in different colors.
On-screen Buttons:
Graph(Single): Tap to view the parameter in waveform graph.
• Min/Max: Tap to define the maximum / minimum value. Once the value
goes beyond the specified value, the system will alarm.
Graph: Tap to view the parameters in waveform graphs.
