 I/O: It lights up when the module is connected to the diagnostic tool via USB
cable (Currently disabled and only reserved for subsequent function extension).
 Wireless: It lights up when the module works as a Wi-Fi hotspot or wireless
adaptor.
4. USB port
Currently disabled and only reserved for subsequent function extension.

1.3.2 VCI module (SmartLink C V2.0)

The SmartLink C V2.0 device features powerful functions and it can be applied
in the following situations:
1). When as a VCI (Vehicle Communication Interface), it needs to work in
conjunction with the Diagnose module of the tablet, which is used to obtain
vehicle data, and then send it to the tablet for analysis wirelessly or via data
cable.
2). When as a SmartLink C (Customer) dongle, it does not communicate with
the tablet, but it needs to work together with the SmartLink module of the
tablet. The tablet is mainly used to issue remote diagnostic requests, and
the SmartLink C dongle is networked to receive and execute commands
from the remote SmartLink B (Business).
Note: For detailed operations, please refer to Chapter 5.3.1.
3). When as a local J2534 PassThru device, it can be used in conjunction with
the PC installed with OEM diagnostic software.
Note: For detailed operations, please refer to Chapter 10.
