> CONFIGURATION IMPORT (CFG)
To import the configuration file jedi_config.txt, you must save the file within the root directory* of a
USB drive, insert the drive to the USB slot and power cycle your HDMI Modulator. When you see this
message "cfg from USB", select Yes or No and press the MENU/OK button to confirm the import
process. When the process is completed, the unit will reboot with the new configuration!
*IMPORTANT: Use only FAT32 partitions. In any other case, the configuration file will not be read and
the device will reboot normally!
32
> FAST PRE-CONFIG FUNCTION / 50 ID'S SELECTABLE
This feature enables the user to operate the unit hassle free by automatically setting the appropriate
broadcasting table information to provide a more convenient installation, easy to adjust anytime with
no tools required!*
This feature is important when there are several HDMI modulators operating within the same TV coaxial
distribution network. Τhe user should change each unit's broadcasting table information to be able for
the end user devices to receive the channels.
*IMPORTANT: In order to change the Channel Name, you have first to select the PRE-CONFIG ID
Number or to use the CFG function to extract, edit and load the modified configuration file.
Example of 7* different ID's:
ID01 ID02 ID03
Name
TV-1 TV-2 TV-3
LCN 1 2 3
TSID 1 2 3
ONID 1 2 3
NetworkID 1 2 3
Videopid 2101 2102 2103
Audiopid 2201 2202 2203
PmtpID 2301 2302 2303
ServiceID
2401 2402 2403
*IMPORTANT: 7 sample ID configurations, out of 50 installed in the HDMI Modulator.
HDMI MODULATOR 3in1 pro
ID04 ID05 ID06 ID07
TV-4 TV-5 TV-6 TV-7
4 5 6 7
4 5 6 7
4 5 6 7
4 5 6 7
2104 2105 2106 2107
2204 2205 2206 2207
2304 2305 2306 2307
2404 2405 2406 2407
