> CONFIGURATION EXTRACTION (CFG)
For faster configuration of the HDMI Modulator, you must extract the configuration file to a USB drive,
modify it and import it again in the HDMI Modulator.
To extract the configuration file named jedi_config.txt*, you must connect a USB drive** to the USB
slot, enter the Main Menu, go to Save to USB MENU and press key UP to extract the file to the USB drive.
When the message "success!" appears, the process has been successfully completed.
*IMPORTANT: Τhe configuration file jedi_config.txt should not be renamed!
**IMPORTANT: Use only FAT32 partitions! In any other case, the message "failed!" will indicate that the
process has not been completed.
Configuration file details (jedi_config.txt)
<attribute>value<attribute> Description: Allowed values
DVB-T or ISDB-T MODΕ
RF channel: DVB-T 05-12 & 21-69 ISDB-T 07-13 & 14-69
<channel>43<\channel>
DVB-C MODE
RF Output Frequency: DVB-C 47-862 MHz
<frequency>474000<\frequency>
DVB-C MODE
DVB-C QAM 0=16QAM, 1=32QAM, 2=64QAM, 3=128QAM, 4=256QAM
qam>4<\qam>
DVB-C MODE
DVB-C Symbolrate Width: 200 up to 6960000 KHz
<symbolrate>6900000<\symbolrate>
DVB-T or ISDB-T MODΕ
Channel Bandwidth: 6000, 7000, 8000 KHz
<bandwidth>8000<\bandwidth>
<FEC>2<\FEC> FEC: 0: 1/2, 1: 2/3, 2: 3/4, 3: 5/6, 4: 7/8
<FFT>1<\FFT> FFT: 0: 2K, 1: 8K, 2: 4K
30
<attribute>value<attribute> Description: Allowed values
<GI>0<\GI> Guard Interval: 0: 1/32, 1: 1/16, 2: 1/8, 3: 1/4
<Name>TV-1<\Name> Channel Name: Max 12 characters
<RF_Level>0<\RF_Level> RF Level: 6,4,2,0,-2,-4,-6,-8,-10,-12,-14
<LCN_Type>1<\LCN_Type> LCN Type: 0: ITC(Norway), 1: Italy
<LCN>1<\LCN> LCN: 1 to 999
<TSID>1<\TSID> Transport Stream ID: 1 to 65534
<ONID>1<\ONID> Original Network ID: 1 to 65534
<NetworkID>1<\NetworkID> Network ID: 1 to 65534
Audio Bitrate: 0=64kbps, 1=96kbps, 2=128kbps, 3=192kbps, 4=256kbps,
<audio_bitrate>3<\audio_bitrate>
5=320kbps, 6=384kbps
<PCR_GAP>0<\PCR_GAP> PCR Gap: Audio/Video sync max +-5
<audio_format>0<\audio_format> Audio format: 0 MPEG2 L2, 1 AAC MPEG2
<videopid>1002<\videopid> Video PID: 1 to 8000
<audiopid>1001<\audiopid> Audio PID: 1 to 8000
<pmtpid>1003<\pmtpid> PMT PID: 1 to 8000
<serviceID>1000<\serviceID> Service ID: 1 to 9999
<video_bitrate>12500<\video_bitrate> Video Bitrate: 0 to 31668 Mbps
<Netname>EDISION<\Netname> Network Name, Max 12 characters
<LCD_Standby>1<\LCD_Standby> LCD Display Standby mode: 1 ON, 0 OFF
<TV_Standard>0<\TV_Standard> Modulation Mode: 0 DVB-T, 1 DVB-C, 2 ISDB-T
