Name
Shows the Channel Name. Use Left/Right and
Up/Down keys to change the Name after you
have selected the Pre-config ID Number.
LCN Type
Shows the current LCN type. Use the Up/Down
keys to set the desired LCN type.
LCN
Shows the current LCN number. Use the Left/Right
and Up/Down keys to set the desired LCN number.
Constellation
Shows the current Constellation. Use the Up/
Down keys to set the desired Constellation.
Bandwidth (only on DVB-T / ISDB-T Mode)
Shows the current Bandwidth. Use the Up/Down
keys to set the desired Bandwidth.
FEC
Shows the current FEC. Use the Up/Down keys
to set the desired FEC.
FFT
Shows the current FFT. Use the Up/Down keys to
set the desired FTT.
28
Guard Int.
Shows the current Guard Interval. Use the Up/
Down keys to set the desired Guard Interval.
ONID
Shows the current ONID. Use the Left/Right and
Up/Down keys to set the desired ONID.
TSID
Shows the current TSID. Use the Left/Right and
Up/Down keys to set the desired TSID.
Network ID
Shows the current Network ID. Use the Left/Right
and Up/Down keys to set the desired Network ID.
Network Name
Shows the current Network Name. Use Left/Right
and Up/Down keys to change the Network Name.
PCR GAP
Shows the current PCR GAP. Use the Up/Down keys
to set the Audio/Video sync in steps (max +-5).
Audio bitrate
Shows the current Audio bitrate. Use the Up/
Down keys to set the desired Audio bitrate.
Audio format
Shows the current Audio format. Use the Up/
Down keys to set the desired Audio format.
Audio pid
Shows the current Audio pid. Use Left/Right and
Up/Down keys to set the desired Audio pid.
Video pid
Shows the current Video pid. Use Left/Right and
Up/Down keys to set the desired Video pid.
Pmt pid
Shows the current Pmt pid. Use Left/Right and
Up/Down keys to set the desired Pmt pid.
Service ID
Shows the current Service ID. Use Left/Right and
Up/Down keys to set the desired Service ID.
Video bitrate
Shows the current Video bitrate. Use Left/Right
and Up/Down keys to set the desired Video bitrate.
Resolution
Shows the current Input Resolution.
HDMI MODULATOR 3in1 pro
LCD Standby
Shows the LCD Display Standby mode. Use the
Up/Down keys to set the Standby mode ON/OFF.
Factory reset
Factory defaults. Press the key UP to restore to
factory defaults.
Save to USB
Configuration file extraction (CFG). Press the key
UP to extract the current configuration to the
USB storage device.
Soft Version
Shows the current Software version.
TV Standard
Shows the TV STANDARD modulation signals.
Use the Up/Down keys to change to DVB-T,
DVB-C, or ISDB-T mode.
