> FEATURES
• HDMI MODULATOR to DVB-T, DVB-C or
ISDB-T with HDMI loop-through & IR Tx
• INPUT signal: 1x HDMI
• RF OUTPUT signal: 1 x Digital Terrestrial
DVB-T, ISDB-T or Cable DVB-C MPEG4
• Frequency Range:
DVB-T: VHF (CH.5-12) & UHF (CH.21-69)
ISDB-T: VHF (CH.7-13) & UHF (CH.14-69)
DVB-C: 47-862 MHz
• RF loop-through support
• HDMI loop-through support
• IR control over coaxial ready, through
the embedded IR Transmitter
> TECHNICAL SPECIFICATIONS
Processor
800MHz 32Bit ARM9 CPU
Memory DDRIII 16bit 1GBit/s (Embedded) & NOR Flash 32Mbit
HDMI Input/Output HDMI v1.4a
USB Type USB 2.0 HOST, Fat32 support
Power Consumption 10W max, 100-240V AC to DC adapter 5V 2A
Video Encoder MPEG1, MPEG2 MP@HL, MPEG4 SP@L3 to ASP@L5,
MPEG4 AVC HP@level4.1, MP@level4.1
Aspect Ratio 16:9 wide screen, 4:3 letter box, 4:3 pan scan
Resolution
up to 1080p@60FPS
Audio encoder
MPEGI L1/2, MPEGII LII, AAC LC, HE-AAC v1/v2 (2-CH)
22
• High Video Resolution up to 1080p 60FPS
• Adjustable RF Output Level / Default 90dbμV
• MER more than 35dB
• Fast Pre-Config Function / 50 ID's Selectable
• Backup Config File by USB / Software Upgrade by USB
• Ports: RF IN, RF OUT, IR OUT, USB, HDMI IN, HDMI
OUT, DC 5V/2.0A, GROUND
• LCD Display
• 6 Front panel buttons: Lock, Menu/OK, Left, Right, Up,
Down
• Power Supply: AC 100-240 50/60Hz / Low Power
Consumption
> RF SPECIFICATIONS
Output Signal
DVB-T, DVB-C or ISDB-T / VHF & UHF band
Frequency Range
DVB-T: VHF (CH.5-12) & UHF (CH.21-69), DVB-C: 47-862 MHz,
ISDB-T: VHF (CH.7-13) & UHF (CH.14-69)
Impendance 50Ω
RF IN RF signal mix through
FEC 1/2, 2/3, 3/4, 5/6, 7/8
Guard Interval 1/4, 1/8, 1/16, 1/32
Constellation DVB-T/ISDB-T: QPSK, 16, 64 QAM / DVB-C: 16, 32, 64, 128, 256 QAM
RF Output level
~90dBuV Adjustable from 0 to -14dB 0 to +6dB
Bandwidth
6MHZ, 7MHZ, 8MHZ
FFT 2K, 8K
Reed Solomon 202, 188, T=8
Symbol Rate up to 31.668 MBPS
MER >35dB at Maximum RF output level
IR OUT Stereo Jack 3,5mm (embedded IR Transmitter)
> IR CONTROL SYSTEM EDI-RX SPECIFICATIONS
Modulation Type ASK
Frequency bandwidth VHF III (174-230 MHZ) & UHF (470-862 MHZ)
RF IN Input 1x Female IEC-type
RF OUT Output 1x Male IEC-type
IR Receiver OUT Stereo Jack 3,5mm (Jack to IR EDI-Rx)
DC OUT 5V/500mA (DC to USB cable)
IR Signal LED
IR status indication
