Outdoor Square Flat Disc Fire Pits
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
This fi re pit requires a minimum 18-square inches (per side) of cross ventilation.
Failure to provide proper ventilation can void the warranty.
Warning:
Warning: For Outdoor Use Only
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
MODELS
25" Square Stainless Flat Disc with 22" Burning Spur
30" Square Stainless Flat Disc with 22" Burning Spur
34" Square Stainless Flat Disc with 31" Burning Spur
40" Square Stainless Flat Disc with 36" Burning Spur
46" Square Stainless Flat Disc with 36" Burning Spur
INSTALLATION PRECAUTION:
Description
Match Light (MT)
Advertisement
Table of Contents
Related Manuals for Firegear FPB-25SDBS22MT-N
Summary of Contents for Firegear FPB-25SDBS22MT-N
- Page 1 MODELS Natural Gas Description Match Light (MT) FPB-25SDBS22MT-N 25” Square Stainless Flat Disc with 22" Burning Spur FPB-30SDBS22MT-N 30” Square Stainless Flat Disc with 22" Burning Spur FPB-34SDBS31MT-N 34” Square Stainless Flat Disc with 31" Burning Spur FPB-40SDBS36MT-N 40” Square Stainless Flat Disc with 36" Burning Spur FPB-46SDBS36MT-N 46”...
- Page 2 CARBON MONOXIDE HAZARD DANGER This appliance can produce carbon monoxide which has no odor. Using it in an enclosed area can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. WARNING DANGER If you smell gas: Do not store or use gasoline or other...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Specifications Preparation for Non-Combustible Structure Hard Piping to Fire Pit Cross Ventilation Requirements High Elevation Gas Pipe Sizing Chart Installation into an Approved Enclosure Operation & Lighting Instructions Replacement Parts Replacement Parts List Fire Pit Maintenance Trouble Shooting Optional Accessories All media (i.e. -
Page 4: Specifications
46" x 46" 44" 18” 36” 96” 18” Table1. Disc Dimensions Model Number Clarifi cation: First number denotes pan size, second number (i.e. FPB-25SDBS22MT-N) denotes burner size. 24” Overhang 96” Ground Level (Earth) Fig. 1 Flat Disc Dimensions; refer to Table 1. -
Page 5: Preparation For Non-Combustible Structure
A minimum of 18 square inches of 2- 1” x 9” Slots Per Side or cross ventilation (2 sides) is required to keep the 2- Firegear 6 x12 vents components in good working order. Use Fig. 3 as guide to assist to incorporate proper ventilation. -
Page 6: Gas Pipe Sizing Chart
GAS PIPE SIZING CHART REFERENCE GAS PIPE SIZING NATURAL GAS : PIPE SIZING CHART Length of Pipe in Feet 1/2” 3/4” 1” 1 - 1/4” 1 - 1/2” 2” 2 - 2 1/2” 3” 4” • Natural Gas (NG) flow is given in 1237 2259 3640... - Page 7 INSTALLATION OF FIRE PIT INTO AN APPROVED ENCLOSURE REQUIREMENTS 1. Only non-combustible materials should come in direct contact with any part of the fi re pit. Underneath area should be non-combustible or a fl at level combustible surface according to the clearances specifi ed in this manual.. 2.
- Page 8 Cement Block Illustration Stone Cap Flat Disc With Spur 6x12 Vent NOTE: Key valve and fl exible gas lines are supplied. Gas shut-off is not supplied. Note: A 1¼” x 2” black iron or galvanized coupler/nipple (not supplied) can be used as a spacer between the manual valve and the valve fl ange to add additional Non-...
-
Page 9: Operation & Lighting Instructions
OPERATION CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance. WARNING: Do not use this appliance if any part has been under water. -
Page 10: Replacement Parts
FLAT DISC REPLACEMENT PARTS Drawings are not to scale Square Flat Disc Fire Pits REV. 1-15-18 Page 10... -
Page 11: Replacement Parts List
FLAT DISC REPLACEMENT LIST Item Qty. Part Number Description 25-inch Square Flat Stainless Steel Disc PAN-SS25SF 30-inch Square Flat Stainless Steel Disc PAN-SS30SF 34-inch Square Flat Stainless Steel Disc PAN-SS34SF 40-inch Square Flat Stainless Steel Disc PAN-SS40SF 46-inch Square Flat Stainless Steel Disc PAN-SS46SF 22-inch Spur (used on 25 &... -
Page 12: Fire Pit Maintenance
FIRE PIT MAINTENANCE 1. The fire pit should be inspected and cleaned before initial use at least annually by a qualified field service person. 2. Any component that is found faulty must be replaced with an approved component. 3. Any tampering or modifying with the fire pit is dangerous and voids all warranties. 4. -
Page 13: Optional Accessories
OPTIONAL ACCESSORIES The following accessories are available from your local Firegear dealer/distributor. Each accessory comes with a separate installation manual. Read each instruction thoroughly before installing. Lava Stones: 1” to 2” size (15lbs) Lava Boulders: 6” to 12” size (30lbs) Lava Rock: 1”... - Page 14 Lava Rock and Lava Stones are not may not apply to you. covered by warranty For Commercial applications, the liability of Firegear Outdoors End User must provide a bill of sale, canceled check, or payment is limited to the express terms of this warranty. We expressly...
