MODELS:
FPB-19DSI/N (19-inch Round Fire Pit)
FPB-25DSI/N (25-inch Round Fire Pit)
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO
NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
This fire pit requires a minimum 18-square inches of cross ventilation. Failure to
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
Outdoor Fire Pit
INSTALLTION PRECAUTION:
provide proper ventilation can void the warranty.
Warning: For Outdoor Use Only
MODELS:
FPB-1414DSI/N (14-inch Square Fire Pit)
FPB-2020DSI/N (20-inch Square Fire Pit)
FPB-2626DSI/N (26-inch Square Fire Pit)
Advertisement
Table of Contents
Related Manuals for Firegear FPB-19DSI/N
Summary of Contents for Firegear FPB-19DSI/N
- Page 1 MODELS: MODELS: FPB-1414DSI/N (14-inch Square Fire Pit) FPB-19DSI/N (19-inch Round Fire Pit) FPB-2020DSI/N (20-inch Square Fire Pit) FPB-25DSI/N (25-inch Round Fire Pit) FPB-2626DSI/N (26-inch Square Fire Pit) Outdoor Fire Pit Installation and Operating Instructions IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO...
- Page 2 !"#$%& )"&*+#,-+#+.(!%,/"00"&! 1234,56673589:,958,6;<=>9:,95;?<8,@<8<A3=:, B2392,254,8<,<=<;C, D438E,3F,38,58,:897<4:=,4659:,958,G377,H<>C, #:I:;,>4:,F234,56673589:,38,58,:897<4:=,4659:, 4>92,54,5,95@6:;J,F:8FJ,95;,<;,2<@:C, !"#$%& '"&#(#$ "#!$%&!'()**!+,'-! .%!/%0!'0%1)!%1!&')!+,'%*2/)!%1!%03)1! #*,((,4*)!5,6%1'!,/7!*28&27'!2/!03)! 5292/20$!%#!032'!%1!%03)1!,66*2,/9):! 1. Shut off gas to the appliance. ;/!<=>9$*2/7)1!/%0!9%//)90)7!#%1!&')! 2. Extinguish any open flame. '3,**!/%0!4)!'0%1)7!2/!03)!5292/20$!%#!032'! %1!,/$!%03)1!,66*2,/9):! 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department.
- Page 3 Most fire pits are equipped for Natural gas (NG) however, if you are considering converting to LP gas use the guidelines below for proper tank storage. REMOTE PROPANE / LP GAS ENCLOSURES INSTALLATION GUIDELINES If this fire pit is permanently connected to a gas piping •...
-
Page 4: Table Of Contents
"#$%&!#&$'!()!*+&!,(-$'!+..%(+)/$&0!+)'!12$!.-3'#/1&!3,!/345#&1(3)!3,!&#/2!,#$%&0!/3)1+()! /2$4(/+%&!6)37!13!12$!81+1$!3,!9+%(,3-)(+!13!/+#&$!/+)/$-0!5(-12!'$,$/1&!+)':3-!312$-!-$.-3'#/1(;$! 2+-4<!=2(&!7+-)()*!(&!(&&#$'!.#-&#+)1!13!9+%(,3-)(+!>$+%12!?!8+,$1@!93'$!8$/<ABACD<E! TABLE OF CONTENTS Specifications Preparation for Non-Conbustible Structure Hard Piping to Fire Pit Cross Ventilation Requirements Installation Into An Approved Enclosure Requirements Installation of Battery Pack Installation of Lava Rock/Media Learning the Remote to Module Operation Initial Start Up Replacement Parts Replacement Parts List Fire Pit Maintenance... -
Page 5: Specifications
Figure 2. Clearance to Combustibles (Not to be used in an enclosed space) Model High Btu’s Low Btu’s Natural/Propane (LP) Natural/Propane (LP) Min. 5.0”WC 11.0”WC FPB-19DSI/N 80,000 Btu’s 50,000 Btu’s Inlet FPB-25DSI/N 110,000 Btu’s 50,000 Btu’s Max. 10.5”WC 13.0”WC FPB-1414DSI/N 45,000 Btu’s... -
Page 6: Hard Piping To Fire Pit
WARNING: Proper clearances from combustible, construction and materials must be maintained from all sides, top and bottom of this appliance. This appliance should never be placed on any combustible surface. This appliance should never be placed under any combustibles closer then 96-inches. This appliance should never be placed closer than 36-inches from any side to any combustible construction or materials (See fig. -
Page 7: Requirements
INSTALLATION OF FIRE PIT INTO AN APPROVED ENCLOSURE REQUIREMENTS 1. Only non-combustible materials should come in direct contact with any part of the Fire Pit. Underneath area should be non-combustible as well. 2. Only use ¾” gas supply line to the Fire Pit. Based on the selection of the fire pit size, the proper brass fittings should be used to ensure a proper installation. -
Page 8: Installation Of Battery Pack
NSTALLATION OF BATTERY PACK During the installation the location of the Battery Pack should be installed in the location that is easy to service. The best location is in the vertical enclosure of the Fire Pit. The plastic junction box is provided for the installation of the battery pack. -
Page 9: Learning The Remote To Module
LEARNING THE REMOTE CONTROL TO THE MODULE The firegear Fire Pit is unique that it comes standard with one remote controlled transmitter (Model RCAF-3). The handheld remote is shipped with this system are already learned (pro- grammed) to the module inside the control box. Additional transmitters can be learned to this electronic module;... -
Page 10: Operation
OPERATION CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance. WARNING: Do not use this appliance if any part has been under water. -
Page 11: Replacement Parts
REPLACEMENT PARTS REV. 10-10-12 Page... -
Page 12: Replacement Parts List
REPLACEMENT PARTS Qty. Item Description Part Number 25-inch Round Stainless Burner Pan OD-FPBOWL/25 OD-FPBOWL/19 19-inch Round Stainless Burner Pan 38-inch Square Stainless Burner Pan OD-FPPAN/38x38 26-inch Square Stainless Burner Pan OD-FPPAN/26x26 OD-FPPAN/20x20 20-inch Square Stainless Burner Pan 14-inch Square Stainless Burner Pan OD-FPPAN/14x14 12-inch Star Burner (used on 14”... -
Page 13: Fire Pit Maintenance
FIRE PIT MAINTENANCE 1. The Fire Pit should be inspected and cleaned before initial use at least annually by a qualified field service person. 2. Any component that is found faulty must be replaced with an approved component. 3. Any tampering or modifying with the Fire Pit is dangerous and voids all warranties. 4. -
Page 14: Wiring Diagram
Thermal Safety (Overheat Protection): Error Code: 4 Beeps every 2 seconds. Description of Fault: Warn users that the modules internal temperature exceeds 170°F. How to Clear: Module’s internal temperature must cool to below 160°F and then press ON button. What to Check: Ensure that there is proper ventilation to the control module. -
Page 15: Accessory Parts
OPTIONAL ACCESSORIES The following accessories are available from your local firegear dealer/distributor. Each accessory comes with a separate installation manual. Read each instruction thoroughly before installing. MODEL: FG-DSI-WWS/H/L MODEL: FG-DSI-WWS MODEL: FG-DSI-WWT Wireless wall switch with Wireless wall switch with... -
Page 16: Warranty
LIMITED WARRANTY Fire Gear LLC hereby warrants to the ORIGINAL PUR- he Owner must provide a bill of sale, cancelled check, or payment record to verify purchase date CHASER of this Fire Pit System, that it will be free from and establish warranty period.
