Installation, Operation and Maintenance APP 16-22 pumps
If alternative mounting is desired, please contact
Danfoss High Pressure Pumps.
Choose proper tolerances to ensure an easy
mounting of the elastic coupling without use of
tools.
Please take care to observe the recommended
length tolerances of the chosen coupling, as an
axial force on the pump will damage the pump.

3.2 Direction of rotation

Is indicated by means of an arrow on the pump
label.
PUMP
Type APP 16
Code no. 180BXXXX
Serial no. XXXXXXXX-XXX

3.3 Orientation

The pump can be mounted/orientated in any
horizontal direction with the inlet and the outlet
pointing upwards, downwards or to either side.
C
C
MADE IN DENMARK
Danfoss A/S, 6430 Nordborg, Denmark
C
C
C - Bleeding
C
C
C
