Operation guide
40 | 180R9265 | AQ115586503035en-001003
Installation, Operation and Maintenance APP 16-22 pumps
APP 11 - APP 13
Description
APP 11 - APP 13
10 × 8 × 45
Parallel key,
mm
DIN 6885
0.39 × 0.31 × 1.77
inch
G ¼", Hexagon AF = 6 mm
Bleeding
M42 x 1.5; depth 17 mm
Inlet port
M42 x 1.5; depth 17 mm
Outlet port
125 B 4
Pump mounting
ange
APP 16 – APP 22
Description
APP 16 – APP 22
12 × 8 × 70
Parallel key,
mm
DIN 6885
0.47 × 0.31 × 2.76
In
G ¼", Hexagon AF = 6 mm
Bleeding
M52 x 1.5; depth 21 mm
Inlet port
M52 x 1.5; depth 21 mm
Outlet port
125 B 4
Pump mounting
ange
Accessories
Type
2" Victaulic
2" inlet hose kit
2 m / 79"
2" Victaulic
2" inlet Vic.
Super Duplex
1,5" Victaulic
Non-return
(OD 48.3 mm)
valve (outlet)
Super Duplex
For more details on the accessories, please
contact Danfoss High Pressure Pumps.
Accessories
Type
2" Victaulic
2" inlet hose
kit 2 m/79"
2" Victaulic
2" inlet Vic.
Super Duplex
2" Victaulic
Non-return
(OD 63 mm)
valve (outlet)
Super Duplex
For more details on the accessories, please
contact Danfoss High Pressure Pumps.
Code no.
180Z0298
180Z0166
180H0053
Code no.
180Z0298
180Z0165
180H0256
© Danfoss | 2023.03
