Flushing valve curves

24 | 180R9265 | AQ115586503035en-001003
Installation, Operation and Maintenance APP 16-22 pumps
All pumps except APP (W) 5.1 - 10.2 are supplied
with an integrated ushing valve that allows the
uid to ow from inlet to the outlet, when the
pump is not running.
6.5 APP 16–22 integrated ushing valve
Pressure [barg]
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0
Flow [l/min]
