DeVilbiss LUNA2-PL Series Operation Manual

Important: Read and follow all instructions and SAFETY PRECAUTIONS before using this equipment.
Keep this instruction manual carefully within close reach for reference at any time.
The gun body of this product is coated. Never use a wire brush or metal spatula when cleaning.
Also, do not attempt to engrave on the surface as this may cause the coating to peel off.
Models
LUNA2-K – Air Cap No. – Fluid Tip Size – Type of Feed （P： Pressure Type）
(Ex.): LUNA2
Ｘ–
SPECIFICATIONS
Maximum Working Air Pressure: 0.69Mpa,
Chart 1.
Tip Size (mm)
Air Cap No.
Part No.
GY(0.8) FX(1.1)
○ ○
PL1
LUNA2-3-PL1
○ ○
PL2
LUNA2-3-PL2
○ ○
PL3
LUNA2-3-PL3
※PL1, PL2 / ●Spray Distance： 200mm ●Spray Pressure： 0.2Ｍｐａ ●Fluid Delivery： 200cc/min ●Paint Viscosity： 20sec（HIS） ●Size： FX
※PL3 / ●Spray Distance： 200mm ●Spray Pressure： 0.29Ｍｐａ ●Fluid Delivery： 300cc/min
Parts List
Chart 2.
Ref No. Part No.
1 LUNA2i-6-BK
2 JJ-50-K5
3 See Chart 1.
4 See Chart 3.
5 LUNA2-7
6 LUNA-8-K5
7 LUNA2-35SUS
8 LUNA2-S-BODY
9 LUNA2-44
10 LUNA2-443
11 LUNA2i-43
12 FUN-25-K5
13 LUNA2-12
14 See Chart 3.
15 LUNA2i-14-K5
16 LUNA2-13-B
17 FUN-463
18 FUN-11-K3
19 FUN-46-K10
20 FUN-45-K5
21 FUN-108
22 LUNA2-42
23 LUNA2-30
24 LUNA2-34
LUNA2Ｘ-PL
Suray Gun Operation Manual
– –
PL1 FX P (No. PL1 Air Cap – Size FX (1.1mm) – Pressure Type)
Feed
Consumption
FF(1.4)
Pressure
○
LVMP
○ Pressure
LVMP
○ Pressure
Standard
Description
Retaining Ring
Ring Seat
Air Cap
Fluid Tip
Baffle (with Gasket)
Gasket (5 pcs.)
Fluid Inlet
Gun Body
Pattern Valve
Valve Seal Kit
Air Valve
Valve Spring (5 pcs.)
Air Valve Bushing
Needle
Needle Spring (5 pcs.)
Needle Adjusting Screw
Needle Packing
Packing Gland (3 pcs.)
E-ring Kit (10 pcs.)
Bearing Stud (5 pcs.)
Trigger
Cheater Valve
Air Connector
Valve Seal Inserting Tool
(Sold separately)
Maximum Working Fluid Pressure: 0.69MPa
Air Pattern Size
(mm)
205Nｌ/min
170
205NI/min 220
240Nｌ/min 210
●Paint Viscosity： 20sec（HIS） ●Size： FX
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
Note: Ref. No. 24 (LUNA2-34) is needed for Ref. No. 10
1
(LUNA2-443) installation. When removing it, be careful
1
not to damage the surface of seat where inserted. A
1
damaged seat may cause air leakage.
1
Chart 3.
1
Description
1
Size (mm)
1
1
GY(0.8)
1
FX(1.1)
1
1
FF(1.4)
1
Applications Fluid Inlet
For General
G1/4
Industries
Fluid Tip
LUNA2-4-GY-S
LUNA2-4-FX-S
LUNA2-4-FF-S
Weight
Air Inlet
(g)
G1/4 265
Needle
LUNA2-41-GY
LUNA2-41-FZ
LUNA2-41-FZ
