Important: Read and follow all instructions and SAFETY PRECAUTIONS before using this equipment.
Keep this instruction manual carefully within close reach for reference at any time.
The gun body of this product is coated. Never use a wire brush or metal spatula when cleaning.
Also, do not attempt to engrave on the surface as this may cause the coating to peel off.
Models
LUNA2X – B – Fluid Tip Size Type of Feed (G: Gravity type / S: Suction type)
(Ex.): LUNA2
B
X–
SPECIFICATIONS
Maximum Working Air Pressure: 0.69Mpa,
*Using air pressure of 0.2MPa or higher may cause pattern abnormality "mid-cracking".
Chart 1.
Air Cap No.
Tip size (mm)
Part No.
254
1.3/1.5/1.8(G)
LUNA2i-3-254
1.3/1.5/1.8(S)
244PLS
LUNA2-3-244PLS
255
1.3/1.5/1.8(G)
LUNA2i-3-255
1.3/1.5/1.8(S)
245PLS
LUNA2-3-245PLS
246PLS
1.5/1.8(G)
LUNA2-3-246PLS
1.5/1.8(S)
255
LUNA2i-3-255
Parts List
Chart 2.
Ref No.
Part No.
1 LUNA2i-6-BK
2 JJ-50-K5
3 See Chart 1.
4 See Chart 3.
5 LUNA2-7
6 LUNA-8-K5
7 LUNA2-35
8 LUNA2-G-BODY
9 LUNA2-44
10 LUNA2-443
11 LUNA2i-43
12 FUN-25-K5
13 LUNA2-12
14 See Chart 3.
15 LUNA2i-14-K5
16 LUNA2-13-B
17 FUN-463
18 FUN-11-K3
19 FUN-46-K10
20 FUN-45-K5
21 FUN-108
22 LUNA2-42
23 LUNA2-30
24 LUNA2-34
LUNA2X (Cross series)
Spray Gun Operation Manual
–13G
(Air Cap 254 & 244PLS - Size 1.3mm – Gravity)
Air consumption
Feed
G : Gravity
type
S : Suction
type
Description
Retaining Ring
Seat
Air Cap
Fluid Tip
Baffle
Gasket (5 pcs.)
Fluid Inlet
Gun Body
Pattern Valve
Valve Seal Kit
Air Valve
Valve Spring (5 pcs.)
Air Valve Bushing
Needle
Needle Spring (5 pcs.)
Adjusting Screw (brass)
Needle Packing
Packing Gland (3 pcs.)
E-ring Kit (10 pcs.)
Bearing Stud (5 pcs.)
Trigger
Cheater Valve
Air Connector
Valve Seal Inserting Tool
(Option)
Maximum Working Fluid Pressure: 0.69MPa
gun inlet
Pattern size
pressure
191L/min
280mm
0.15MPa
(Tip size 1.3)
200L/min
240mm
0.15MPa
(Tip size 1.3)
182L/min
290mm
0.15MPa
(Tip size 1.3)
220L/min
270mm
0.15MPa
(Tip size 1.3)
200L/min
200mm
0.15MPa
(Tip size 1.8)
182L/min
280mm
0.15MPa
(Tip size 1.8)
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Note: Ref. No. 24 (LUNA2-34) is needed for Ref. No. 10
1
(LUNA2-443) installation. When removing it, be careful not
1
to damage the surface of seat where inserted. A damaged
1
seat may cause air leakage.
1
Description
1
Tip Size (mm)
1
1
1.3
1
1.5
1.8
1
Fluid
Applications
Inlet
Base
Thin flat
Base
Standard flat
Clear
Thin arch
G1/4
Clear
Standard arch
Primer Surfacer
Thick arch
Primer Surfacer
Thin arch
Fluid Tip
LUNA2-4-1.3
LUNA2-41-1.3
LUNA2-4-1.5
LUNA2-41-1.5
LUNA2-4-1.8
LUNA2-41-1.8
Air Inlet
Weight
G1/4
265g
Valve Seal
Inserting Tool
Direction
of
Needle Packing
Needle

Advertisement

loading
Need help?

Need help?

Do you have a question about the LUNA2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for DeVilbiss LUNA2 Series

  • Page 1 LUNA2X (Cross series) Spray Gun Operation Manual Important: Read and follow all instructions and SAFETY PRECAUTIONS before using this equipment. Keep this instruction manual carefully within close reach for reference at any time. The gun body of this product is coated. Never use a wire brush or metal spatula when cleaning. Also, do not attempt to engrave on the surface as this may cause the coating to peel off.
  • Page 2 SAFETY PRECAUTIONS This manual contains information that is important for you to know and understand. This information relates to USER SAFETY and PREVENTING EQIPMENT PROBLEMS. Read and follow SAFETY PRECAUTIONS before using this equipment. FIRE AND EXPLOSION HAZARD 1. When spraying, adequate exhaust must be provided to keep air free of accumulations of flammable vapors which may cause fire or explosion.
  • Page 3 PREVENTIVE MAINTENANCE 1. Daily lubrication and cleaning are necessary to maintain the best condition of the gun. 2. To clean the gun body, wipe exterior with solvent dampened cloth. Do not submerge the gun body in solvent as any solids may get into the air passage and cause troubles. 3.
  • Page 4 SERVICE CHECK Normal Spray Pattern Problem Cause Correction will not spray. No pressure to Gun. Check air and material lines. Adjusting Screw (16) not properly adjusted. Adjust. Improper spray patterns A,B: Material build up on the Air Cap or Fluid Tip. A,B: Readjustment and clean the Air Cap or Fluid Tip.
