LUNA-R
Important
The gun body of this model is finished with special coating. Do not use the wire brush or metal
spatula for cleaning. Do not inscribe letters on the gun body. It may cause peeling off the coating.
MODELS
ＬＵＮＡ - R- Air Cap № - Fluid Tip Size – Type of Feed （G：Gravity，S：Suction）
(Ex.)： LUNA-R-244 -1.3-G ← （Auto-Refinishing (Conventional) - №244 Air Cap - Size1.3ｍｍ - Gravity）
SPECIFICATIONS
Maximum Working Air Pressure： 0.69 MPa,
Chart．1
Tip size（mm）
Air Cap №
Part Number
1.0 1.3
1.5
○
○
○
244
○
○
LUNA-3-244
○
○
○
245
LUNA-3-245
○
○
PARTS LIST
Chart.2
Ref. №
Part Number
1 JJ-6
2 JJ-50-K5
3 See Chart.1
4 See Chart.3
5 LUNA-7C
6 LUNA-8-K5
7 LUNA-35
LUNA-BODY-G
8
LUNA-BODY-S
9 LUNA-44C
10 FUN-443
11 FUN-43
12 FUN-25-K5
13 FUN-12
14 See Chart.3
15 FUN-14-K5
16 LUNA-13C
17 FUN-463
18 FUN-11-K3
19 FUN-46-K10
20 FUN-45-K5
21 FUN-108
22 LUNA-42C
23 LUNA-30
24 FUN-34
25 LUNA-34
Note) Ref. No. 24 (FUN-34) is needed for Ref.10 (FUN- 443) installation. When removing it, be careful not to damage the
surface of seat where inserted. A damaged seat can lead air leakage.
Operation Manual
GUN
CONVENTIONAL (for Auto-Refinishing)
：Read and follow all instructions and SAFETY PRECAUTIONS
before using this equipment
Maximum Working Fluid Pressure： 0.69 MPa
Air consumption
Pattern width
Feed
Gun inlet
pressure
G
220L/min
0.2MPa
S
G
220L/min
0.2MPa
S
Description
Retaining Ring
Seat Kit of 5
Air Cap
Fluid Tip
Baffle
Gasket Kit of 5
Fluid Inlet
Gun Body
Pattern Valve
Valve Seal Kit
Air Valve
Valve Spring
Air Valve Bushing
Needle
Needle Spring Kit of 5
Adjusting Screw
Needle Packing (2 pcs.)
Packing Gland Kit of 3
E-ring Kit of 10
Bearing Stud Kit of 5
Trigger
Cheater Valve
Air Connector
Valve
Seal
Inserting
Tool
(Option)
Spanner
Application
(mm)
260
Metallics, Pearls
300
Clear Coats, Solids
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Chart.3
1
1
Description
1
Size （mm）
1
1.0
1
1.3
1.5
1
1
SB-JE-LUNA-R-C
Fluid
Weight
Air inlet
inlet
(g)
G1/4
G1/4
245
Fluid Tip
Needle
JJ-4-1.0
JJ-41-1.0
JJ-4-1.3
JJ-41-1.3
JJ-4-1.5
JJ-41-1.5
