REAR PANEL CONNECTIONS
AUDIO OUTPUTS
LEFT/RIGHT:
Unbalanced, ¼ inch audio outputs.
Headphones:
¼ inch stereo headphone jack. This jack output has the same sound as the
LEFT/RIGHT outputs and its volume is controlled by the MASTER LEVEL knob on the
front panel.
MIDI
IN/OUT MIDI DIN connector for receiving / transmitting MIDI messages from/to an
external MIDI device.
USB
This connector allows the Murmux to transmit and receive MIDI messages similar to when
MIDI DIN is being used, but also allows firmware updates and preset backups or restore.
15VDC Power jack input
Power ON/OFF Switch
Please use only the provided power supply.
10
