- Page 1 1. Scale VCO1 2. Tune VCO1 3. Scale VCO2 4. Tune VCO2 5. Octave up 6. Octave down 7. VCA click noise 8. 5V ref...
- Page 2 1. Scale VCO1 2. Tune VCO1 3. Scale VCO2 4. Tune VCO2 5. Octave up 6. Octave down 7. VCA click noise...
- Page 3 1. Open the back cover of the unit 2. Plug it in power and leave it to warm up for at least 10 min. At that point, if you have access to a multymeter and know how to use it, with trimmer #8 tune for exact 5v at pin1 of MCP4922 chip.
