"C" Group: Intelligent Terminal Functions
Option Terminal
Code Symbol
82
PRG
83
HLD
84
ROK
85
EB
86
DISP
255
no
3-7-3

Output Terminal Configuration

Func.
Code
C021
Output [11] function[EDM
assignable]
C022
Output [12] function
C026
Alarm relay function
C027
[EO] terminal selection (Pulse/
PWM output)
Input Function Summary Table
Function Name
Executing EzSQ pro-
gram
Retain output frequency ON
Permission of Run com-
mand
Rotation direction
detection (C007 only)
Display limitation
No function
The inverter provides configuration for logic (discrete) and analog outputs,
shown in the table below.
"C" Function
Name
48 programmable functions avail-
able for logic (discrete) outputs
(see next section)
48 programmable functions avail-
able for logic (discrete) outputs
(see next section)
13 programmable functions:
00... Output frequency (PWM)
01... Output current (PWM)
02... Output torque (PWM)
03... Output frequency (Pulse
train)
04... Output voltage (PWM)
05... Input power (PWM)
06... Electronic thermal load ratio
(PWM)
07... LAD frequency (PWM)
08... Output current (Pulse train)
10... Heat sink temperature
(PWM)
12... General output (PWM)
15... Pulse train input monitor
16... Option(PWM)
Description
ON Executing EzSQ program
OFF No execution
Retain the current output frequency
OFF No retention
ON Run command permitted
OFF Run command is not permitted
ON Forward rotation
OFF Reverse rotation
ON Only a parameter configured in b038 is shown
OFF All the monitors can be shown
ON (input ignored)
OFF (input ignored)
Description
Section 3-7
Run Defaults
Mode
EU Units
Edit
00 [RUN] –
01 [FA1] –
05 [AL] –
07 –
