ModBus Data Listing
Register Function name
No.
131Fh Start freq. of active frequency
matching
1320h Software lock mode selection
1321h (Reserved)
1322h Motor cable length parameter
1323h Run/power-on warning time
1324h
1325h Rotation direction restriction
1326h Reduced voltage start selection
1327h Function code display restriction b037
1328h Initial display selection
1329h Automatic user parameter regis-
tration
132Ah Torque limit selection
132Bh Torque limit 1 (fwd-power in
4-quadrant mode)
132Ch Torque limit 2 (rev/regen. in
4-quadrant mode)
132Dh Torque limit 3 (rev/power in
4-quadrant mode)
132Eh Torque limit 4 (fwd/regen. in
4-quadrant mode)
132Fh Torque limit LADSTOP enable
1330h Reverse Run protection enable
1331h to (Reserved)
1332h
1333h Dual Rating Selection
1334h Controlled deceleration on
power loss
1335h DC bus voltage trigger level of
ctrl. decel.
1336h Over-voltage threshold of ctrl.
decel.
1337h Deceleration time of ctrl. decel.
1338h
1339h Initial freq. drop of ctrl. decel.
133Ah to (Reserved)
133Eh
133Fh Maximum-limit level of window
comparators O
1340h Minimum-limit level of window
comparators O
1341h Hysteresis width of window
comparators O
1342h Maximum-limit level of window
comparators OI
1343h Minimum-limit level of window
comparators OI
1344h Hysteresis width of window
comparators OI
Function R/W Monitoring and setting items
code
b030 R/W 0 (frequency at the last shutoff), 1 (max-
imum frequency), 2 (set frequency)
b031 R/W 0 (disabling change of data other than
"b031" when SFT is on), 1 (disabling
change of data other than "b031" and fre-
quency settings when SFT is on), 2 (dis-
abling change of data other than "b031"),
3 (disabling change of data other than
"b031" and frequency settings), 10
(enabling data changes during operation)
– – –
b033 R/W 5 to 20
b034 (high) R/W 0 to 65535
b034 (low) R/W
b035 R/W 0( Enable for both dir)/ 1 (Enable for for-
ward only)/ 2 (Enable for reverse only)
b036 R/W 0 (minimum reduced voltage start time)
to 255 (maximum reduced voltage start
time)
R/W 0 (full display), 1 (function-specific dis-
play), 2 (user setting), 3 (data compari-
son display), 4 (basicdisplay), 5(monitor
display)
b038 R/W 001-060
b039 R/W 0 (disabling), 1 (enabling)
b040 R/W 00 (quadrant-specific setting), 01
(switching by terminal), 02 (analog
input)
b041 R/W 0 to 200/255 (no)
b042 R/W 0 to 200/255 (no)
b043 R/W 0 to 200/255 (no)
b044 R/W 0 to 200/255 (no)
b045 R/W 0 (disabling), 1 (enabling)
b046 R/W 0 (disabling), 1 (enabling)
– – –
b049 R/W 0(CT mode)/1(VT mode)
b050 R/W 0 (disabling), 1 (enabling), 2, (nonstop
operation at momentary power failure
(no restoration)) 3, (nonstop operation
at momentary power failure (restoration
to be done))
b051 R/W 0 to 10000
b052 R/W 0 to 10000
b053 (high) R/W 0.01 to 36000
b053 (low) R/W
b054 R/W 0 to 1000
v – –
b060 R/W 0. to 100. (lower limit : b061 + b062 *2)
(%)
b061 R/W 0. to 100. (lower limit : b060 - b062*2) (%) 1 [%]
b062 R/W 0. to 10. (lower limit : b061 - b062 / 2) (%) 1 [%]
b063 R/W 0. to 100. (lower limit : b064 + b066 *2)
(%)
b064 R/W 0. to 100. (lower limit : b063 - b066 *2) (%) 1 [%]
b065 R/W 0. to 10. (lower limit : b063 - b064 / 2) (%) 1 [%]
Section B-4
Data
resolution
–
–
–
–
1 [10h]
–
–
–
–
–
–
1 [%]
1 [%]
1 [%]
1 [%]
–
–
–
–
–
0.1 [V]
0.1 [V]
0.01 [sec.]
0.01 [Hz]
–
1 [%]
1 [%]
293
