Oem shock absorber spacer kit to suit ford f-150 14th gen p702 2021+
Hide thumbs

Advertisement

Table of Contents

OEM SHOCK ABSORBER SPACER KIT TO SUIT FORD F-150
NOTE
Some images contained in these instructions are generic and are
a representation of the actual model and/or parts used. Some steps
may also show parts out of sequence to the instructional steps.
SAFETY WARNING
Ironman 4X4 requires you read and understand the safety and pre-install
directions on page 2 and 3 before commencing installation of this product.
NOTE: Occupational Health and Safety procedures
©Copyright 2023 Ironman 4x4 Pty Ltd. No part of this publication may be reproduced or replicated without the prior written consent of Ironman 4x4 Pty Ltd
INSTALLATION
INSTRUCTIONS
must be observed at all times
76-109-001
14th Gen (P702) 2021+
Approximately
Document Number: 76-109-001/211223
6 Hours
