Table Of Contents - Bosch Power Xpress EV800 Series Installation Instructions Manual

Bosch Automotive Service Solutions Inc.
Power Xpress™ Dual Bollard Charge Station Installation Guide | 1 | en

Table of Contents

1.0 Installation Safety
2.0 Installation Contents: Bollard and EVSE
2.1 Power Xpress EVSE (EL-50600-300) for Bollard Charge Station
2.2 Bollard and Hardware (EL-50600-500)
3.0 Tools Suggested for Installation (Not Provided)
4.0 Materials Required for Installation
5.0 Applicable Electrical Systems
5.1 220/240V Single Phase (North America)
5.2 208V 3-Phase Wye Connection (North America)
5.3 240V 3-Phase Delta Connection (North America) with Center Tap on
One Leg
5.4 230V Above Ground (Europe) / 230V Single Phase
6.0 Electrical Requirements for Battery Charging
7.0 Amperage and Breaker Parameters
8.0 Standard Installation
9.0 EVSE Power and Status LED Indications
10.0 Troubleshooting
10.1 Ground Fault Circuit Interrupt (GFCI) Tripped
10.2 Missing Ground
11. Limited Warranty
2
2
2
2
3
3
3
3
3
4
4
4
5
6
13
13
14
14
14
576414 | REV. A | 28.10.2016
