- Page 1 Assembly Instructions SimplEbale - Work and field lamp kit Kit number: ACX3743730 North America November 2023 4205 River Green Parkway 79037896A_en Duluth GA 30096 USA English © AGCO 2023...
- Page 2 CALIFORNIA Proposition 65 Warning WARNING: Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproductive harm. WARNING: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer, birth defects, and other reproductive harm.
- Page 3 Make an order for missing parts. General If more assistance is necessary you should speak to your AGCO dealer. This manual is only applicable to the models specified on the front cover. Fastener torques Always replace fasteners with fasteners of the same specification.
- Page 4 1 Safety Part number references All parts that are supplied in the kit are referenced in the bill of materials. Each part is added to a table in the installation steps, below is an example. Description Quantity Number Part number X446235234000 Long key X446234100000...
- Page 5 1 Safety Safety icons The safety warnings show in the manual with these icons: DANGER: This is an immediately dangerous situation which, if you ignore it, will cause death or injury. WARNING: This is an immediately dangerous situation which, if you ignore it, can cause death or injury.
- Page 6 Do not change the equipment. An adjustment not specified by the manufacturer can change the function of the machine and cause damage or personal injury. Only use AGCO approved replacement parts. WARNING: To prevent injury and machine damage, you must: •...
- Page 7 1 Safety Waste disposal Incorrect disposal of waste can cause pollution to the environment. Some examples of dangerous waste materials include oil, fuel, coolant, battery chemicals and air-conditioning refrigerant. • Only use an approved container to collect the waste material. Always seal the container after you drain the fluids.
- Page 8 1 Safety SimplEbale - Work and field lamp kit 79037896A_en...
- Page 9 2 Introduction Bill of materials Fig. 1 SimplEbale - Work and field lamp kit 79037896A_en...
- Page 10 2 Introduction Kit number: ACX3743730 Quantity Description Number Part number 7883382 Bolt - 3/8 X 16 X 1 ACX3743580 Lamp strip 700750444 Cable tie - edge 7883325 Bolt - 5/16 X 18 X 3/4 704726 Nut - 5/16 X 18 X 3/4 700707010 Wiring harness clamp 7724347...
- Page 11 3 Installation Install the work and field lamps NOTE: To make this procedure easy to understand, the illustrations can show some components removed. Procedure NOTE: Install the light on the front side of the support. Position the lamp strip (1) on the front side of support.
- Page 12 3 Installation Hold the lamp strip (1) in the center position. Make 2 holes (2) and (4) to a diameter of 3/16 in the support (3). Fig. 2 Number Part number Description Quantity ACX3743580 Lamp strip Install the bolts (1), the washers (2) and (3) and the nut (4).
- Page 13 3 Installation Connect the electrical connector (4). Install the clamp (2), the bolt (1) and the nut (3). Fig. 4 Number Part number Description Quantity 7883382 Bolt - 3/8 X 16 X 1 700707010 Wiring harness clamp 700711238 Flange nut - 3/8 X 16 Install the clamp (1) and the nut (2).
- Page 14 3 Installation Release the latch (2) for the cover. Open the cover (1). Fig. 6 10. NOTE: The light will be mounted to the underside of the shield. Position the lamp strip (1) on the top of the shield over the baler flywheel. Fig.
- Page 15 3 Installation 11. Hold the lamp strip (1) in the center position. 12. Make a mark for the holes for mounting the light. 13. Make 2 holes (2) and (4) to a diameter of 3/16 in the support (3). Fig. 8 Number Part number Description...
- Page 16 3 Installation 16. Connect the electrical connector. 17. Install the cable ties (1). Fig. 10 Number Part number Description Quantity 700750444 Cable tie - edge 18. Install the cable ties (1). Fig. 11 Number Part number Description Quantity 700750444 Cable tie - edge SimplEbale - Work and field lamp kit 79037896A_en...
- Page 17 3 Installation 19. Release the latch (2). 20. Open the cover (1). Fig. 12 21. Install the lamp strip (4) to the support. 22. Install the bolts (6), the washers (2) and (5) and the nuts (3). Fig. 13 Number Part number Description Quantity...
- Page 18 3 Installation 23. Connect the electrical connector (1). 24. Secure the harness to the bracket with the cable ties. Fig. 14 25. Remove and discard the bolts that are securing both the clamps. 26. Remove the clamps. NOTE: Move the hoses if necessary. Fig.
- Page 19 3 Installation 27. Install the lamp bracket (1) with the 2 existing clamps (4). 28. Install the washers (3) and the bolts (2). Fig. 16 Number Part number Description Quantity 700190409 Lamp bracket - straight 7883382 Bolt - 3/8 X 16 X 1 700702916 Washer - 3/8 29.
- Page 20 3 Installation 30. Install the work lamp (1) and the nut (2). 31. Connect the electrical connector. Fig. 18 Number Part number Description Quantity ACW3783570 Lamp SimplEbale - Work and field lamp kit 79037896A_en...
- Page 21 3 Installation 32. NOTE: The rear work lights can also be mounted to the light bar ACX4185220 in the SimplEbale road lamp kit. Install the bracket (2), the bolt (1), the washer (4) and the nut (3). Fig. 19 Number Part number Description Quantity...
- Page 22 3 Installation 36. Install the bracket (1), the bolt (2), the washer (3) and the nut (4). Fig. 21 Number Part number Description Quantity ACX3743860 Lamp bracket - L 700054 Carriage bolt - 3/8 X 16 X 1–1/4 700702916 Washer - 3/8 700711238 Flange nut - 3/8 X 16 37.
- Page 23 3 Installation 39. Install the clamps (1), bolts (2) and nuts (3). Fig. 23 Number Part number Description Quantity 70929720 Wiring harness clamp Bolt - 3/8 Nut - 3/8 40. Install cable ties to hold wiring harnesses away from moving components. Fig.
- Page 24 © AGCO Corporation, 2023. All rights reserved. 79037896A_en (English) November 2023...
