ASSEMBLY SAFETY

CAUTION! TO AVOID PERSONAL INJURY,
READ, UNDERSTAND AND FOLLOW
THE SAFETY INFORMATION BELOW.
The person or persons who assemble this
machine must have the ability to read,
understand and follow the step by step
assembly procedures and safety instruction
outlined herein.
Wear personal protective equipment (PPE)
such as, but not limited to, protection for
eyes, lungs, ears, head, hands and feet
when operating, servicing or repairing
equipment.
Use lift crane, jack, tackle or fork lift truck to
lift heavy parts and assemblies.
Keep clear of parts which may move or
drop when removing shipping straps or
brackets.
Assembly area should be level, clean and
free of debris to prevent assembly
personnel from tripping or failing.
Inspect all parts for sharp edges, grease, oil
or dirt which might cause injury during
assembly.
If machine requires blocking up, use
blocking material of adequate strength and
in good condition. Blocks must be on a
smooth dry surface.
Never place any part of your body under
blocked-up assemblies if at all possible.
If welding or flame-cutting is required, be
sure no flammable materials are in the
area. Also, clear bystanders from area.
SS7400 SOIL SAVER
1
- Basic Setup
®
After completing each assembly step,
review next step in procedure before
proceeding with that step.
Neatly arrange parts and tools within easy
reach of work area.
Openings in the skin and minor cuts are
susceptible to infection from hydraulic fluid.
If injured by escaping fluid, see a doctor at
once. Without immediate medical
treatment, serious infection can occur.
Never use your hands to locate a hydraulic
leak. Use a piece of wood or cardboard.
Hydraulic fluid escaping under pressure can
penetrate the skin.
Correct fluid leaks before using equipment.
BEFORE DELIVERY
After completing assembly of machine, be
sure all nuts, bolts, other fasteners, and
hydraulic fittings are properly tightened.
Be sure all safety guards and safety locking
devices are in place.
Be sure machine is completely lubricated.
Before operating the machine, be sure to
read the OPERATION section of operator's
manual.
Before delivering the machine, review
machine maintenance, operation, and
safety with the customer.
Complete the Predelivery Inspection and
Service Report at the end of these
instructions.
Product: Primary
Tillage
Model:
SS7400
Bulletin: 2PD684599
Date:
May 1999

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Glencoe SS7400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AGCO Glencoe SS7400

  • Page 1: Assembly Safety

    Product: Primary Tillage Model: SS7400 Bulletin: 2PD684599 Date: May 1999 SS7400 SOIL SAVER - Basic Setup ® ASSEMBLY SAFETY After completing each assembly step, CAUTION! TO AVOID PERSONAL INJURY, • READ, UNDERSTAND AND FOLLOW review next step in procedure before THE SAFETY INFORMATION BELOW.
  • Page 2: Preliminary Instructions

    PRELIMINARY INSTRUCTIONS UNPACKING CAUTION! SOME PARTS ARE EXTREMELY  The Soil Saver is shipped in bundles identified with HEAVY, SHARP AND DIFFICULT TO tags. Be sure all bundles have been received before HANDLE. TO PREVENT POSSIBLE starting assembly. PERSONAL INJURY, HAVE Open all bundles.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS ASSEMBLY SAFETY - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 PRELIMINARY INSTRUCTIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 7 &...
  • Page 4: 9-Shank Models, Rigid Frame, Single-Axle

    RIGID FRAME - SINGLE AXLE...
  • Page 5 RIGID FRAME - SINGLE AXLE 7 & 9-SHANK MODELS TURNBUCKLE ROCKSHAFT and WHEELS 1. Install turnbuckle (double-nut end towards front) Note: See previous page for illustration. using 1" x 3" clevis pins and cotter pins. Extend (turn out) the ends of the turnbuckle 1" for initial 1.
  • Page 6: 7, 9, 11, 13-Shank Models, Rigid Frame, Walking Beam Axle

    RIGID FRAME - WALKING BEAM AXLE...
  • Page 7 RIGID FRAME - WALKING BEAM AXLE 7, 9, 11, 13-SHANK MODELS TONGUE BRACES ROCKSHAFT and WHEELS 1. Position tongue braces and install four Note: See previous page for illustration. 3/4" x 6-1/2" bolts and locknuts at front brace plates. 1. Place main frame on sturdy stands 2.
  • Page 8: 17-Shank Models, Folding Main Frame

    MAIN FRAME - FOLDING MODELS...
  • Page 9 MAIN FRAME - FOLDING MODELS 15 & 17-SHANK MODELS TONGUE BRACES ROCKSHAFT and WHEELS 1. Position tongue braces and install four Note: See previous page for illustration. 3/4" x 6-1/2" bolts and locknuts at front brace plates. 1. Place main frame on sturdy stands 2.
  • Page 10: 17-Shank Models, Folding Wing Frame

    WING FRAME - FOLDING MODELS 15 & 17-SHANK MODELS WING FRAMES 1. Assemble wing frame by placing it on stands at 6. Mount shank assemblies on rear bar only (pp. same height as main frame stands. 19 - 20, 23). Also install extensions if included. Note: Rear bar shanks are easier to mount before rockshaft is installed.
  • Page 11: Main Frame Slicer, All Models

    MAIN FRAME SLICER ALL MODELS 1. Mount both left and right mounting channel 5. Repeat for left slicer gang. Tighten all bolts. assemblies to main frame with 3/4" x 3-1/2" bolts and locknuts. 6. Hook ears of pressure rod to hole in rear of bar on gang frame.
  • Page 12: Wing Frame Slicer, Folding Models

    WING FRAME SLICER FOLDING MODELS 1. Mount gang channel to outer-end bar of wing 4. Fasten slicer gang with upper bearing on top of frame using 3/4" x 3-1/2" bolts and lock nuts. slicer gang tube and lower bearing under slicer gang tube.
  • Page 13: Hydraulic System, Rigid Models

    HYDRAULIC SYSTEM - RIGID MODELS CYLINDERS and HOSES WARNING! OPENINGS IN THE SKIN AND MINOR 1. Mount 4" x 16" hydraulic cylinder with cylinder CUTS ARE SUSCEPTIBLE TO base end to main frame and secure with cylinder pin and hairpin clips (or cotter pins). INFECTION FROM HYDRAULIC FLUID.
  • Page 14: Hydraulic System, Folding Models

    HYDRAULIC SYSTEM - FOLDING MODELS...
  • Page 15 HYDRAULIC SYSTEM - FOLDING MODELS...
  • Page 16 HYDRAULIC SYSTEM - FOLDING MODELS CYLINDERS HOSES Refer to the Torque Values Chart (end of Note: See previous two pages for illustrations. instructions) for important information on the 1. Mount 4" x 16" main frame lift cylinder with: tightening of straight-thread hydraulic fittings. - Base end to rockshaft cylinder anchor ...
  • Page 17: Hydraulic System Charging

    HYDRAULIC SYSTEM CHARGING CHARGING THE CIRCUITS Wing Fold Circuit The main lift cylinders on wing fold models are connected in a series circuit. (Rigid models have 1. With rod ends of wing fold cylinders only one cylinder). Each cylinder has a different disconnected, slowly extend and retract diameter, with the smaller called a “slave”...
  • Page 18 HYDRAULIC SYSTEM CHARGING REPHASING-TYPE HYDRAULIC SYSTEM CYLINDER STROKE Alternate Charging Procedure If the hydraulic lift system is fully charged with no air IMPORTANT! If charging procedure on previous in the system and the implement is still not level page does not provide satisfactory results, use the when raised, check the cylinder stroke.
  • Page 19: Shank Holders

    SHANK HOLDERS GENERAL For locating the shank position on the frame, refer to the shank location diagrams on the following pages. Mark shank holder locations on the frame as indicated. If using twisted shovels, install all shanks so shovels throw soil inward except shovels near wheels. Position those shovels to throw out- ward.
  • Page 20: Deep-Till Shanks

    DEEP-TILL SHANKS INSTALLATION IMPORTANT! Mount optional deep-till shanks only on the rear bar of implement. 1. Refer to following pages for deep-till shank locations (same as standard shank rear bar locations) and mark bar accordingly. 2. Deep-till shanks fit rigid or auto-reset shank holders.
  • Page 21: Shank Locations

    SHANK LOCATIONS...
  • Page 22 SHANK LOCATIONS...
  • Page 23 SHANK LOCATIONS...
  • Page 24: Five-Bar Spike Tooth Harrow

    FIVE-BAR SPIKE TOOTH HARROW...
  • Page 25 FIVE-BAR SPIKE TOOTH HARROW Note: Refer to appropriate harrow location illustration on following pages. ALL MODELS FOLDING MODELS Complete Steps #1 - #9 for rigid models. 1. Mount carriers to rear implement frame with Additionally, 15 and 17-shank folding models have U-bolts, lock washers and nuts.
  • Page 26: Harrow Location

    HARROW LOCATION...
  • Page 27 HARROW LOCATION...
  • Page 28 HARROW LOCATION...
  • Page 29 HARROW LOCATION...
  • Page 30 HARROW LOCATION...
  • Page 31 HARROW LOCATION...
  • Page 32: Rigid Leveler

    RIDGE LEVELER CARRIER and SHANKS Note: Refer to appropriate ridge leveler location illustration on following pages. 1. Mount carrier arms to implement rear frame. 3. Install shank on support tube between bottom clamp plate and tube. Space shanks between main frame shanks. 2.
  • Page 33: Leveler Location

    LEVELER LOCATION...
  • Page 34 LEVELER LOCATION...
  • Page 35 LEVELER LOCATION...
  • Page 36 LEVELER LOCATION...
  • Page 37 LEVELER LOCATION...
  • Page 38 LEVELER LOCATION...
  • Page 39: Hydraulic Slicer Lift

    HYDRAULIC SLICER LIFT RIGID MODELS 1. Install hydraulic cylinder with stroke control as 3. Connect hoses and route through tongue. shown. Install with hose ports on top. Fasten hoses to frame with plastic ties. 2. Install elbows in cylinder.
  • Page 40 HYDRAULIC SLICER LIFT FOLDING MODELS 1. Install hydraulic cylinders as shown, with hose 2. Install elbows in all cylinders. ports on top. IMPORTANT! Each slicer lift cylinder is a 3. Connect hoses and route through tongue. different diameter. If not installed in locations Provide enough slack to allow wings to fold.
  • Page 41: Transport Lights And Reflectors

    TRANSPORT LIGHTS AND REFLECTORS GENERAL The SMV sign and transport lights are shipped separately with the machine bundle.  All Soil Savers are designed to meet current industry standards for location and visibility. Identify the model (7 through 17-shanks) on the following pages and install the lights and SMV sign accordingly.
  • Page 42 TRANSPORT LIGHTS AND REFLECTORS LIGHT CONNECTOR RECEPTACLE Attach connector storage receptacle to tongue (Fig. 10). Use the pre-drilled holes and ″ self-tapping " screws. WIRE HARNESS Install wire harness as in layout. Position harness over frame and connect lights. Beginning at the light posts and working toward the tractor, use plastic ties to securely fasten harness in place.
  • Page 43: Light Locations

    LIGHT LOCATIONS...
  • Page 44 LIGHT LOCATIONS...
  • Page 45 LIGHT LOCATIONS...
  • Page 46 LIGHT LOCATIONS...
  • Page 47 LIGHT LOCATIONS...
  • Page 48 LIGHT LOCATIONS...
  • Page 49: Transport Light Wiring Diagram

    TRANSPORT LIGHTING...
  • Page 50: Torque Values

    TORQUE VALUES SPECIAL TORQUE VALUES IMPORTANT! Over-tightening straight-thread hydraulic fittings damages sealing surfaces of JIC fittings and damages O-rings on adapter fittings. Note: Do not use pipe sealant or Teflon© tape on threads. JIC 37° Flare Adapter Fittings, Adapter-to-Tube " tube or hose: 12 ft-lb (16 N⋅m)* "...
  • Page 51 SS7400 SOIL SAVER Serial No. Model No. Serviced By Date Sold To (Name and Address) INSTRUCTIONS: All items listed below must be inspected and serviced as explained in the Operator’s Manual and / or this form. As each task is completed, place a (√) in the adjoining box. Retain the completed form in dealership files for future customer, dealer, and / or company reference.
