Quick Reference Guide
S67/S68/S96 • S77/S78/S97 • S88/S98 Models
It is YOUR responsibility to read and understand the safety section in your
Operator's Manual and the manual for all attachments before operating your
machine. Remember YOU are the key to safety. Good safety practices not only
protect you, but also the people around you.
Study the features in your Operator's Manual and make them a working part of
your safety program. Keep in mind that the safety section in your Operator's
Manual is written only for this type of machine. Practice all other usual and
customary safe working precautions, and above all REMEMBER - SAFETY IS
YOUR RESPONSIBILITY. YOU CAN PREVENT SERIOUS INJURY OR
DEATH.
Advertisement
Table of Contents
Related Manuals for AGCO Gleaner S67
Summary of Contents for AGCO Gleaner S67
- Page 1 Quick Reference Guide S67/S68/S96 • S77/S78/S97 • S88/S98 Models It is YOUR responsibility to read and understand the safety section in your Operator’s Manual and the manual for all attachments before operating your machine. Remember YOU are the key to safety. Good safety practices not only protect you, but also the people around you.
-
Page 3: Table Of Contents
Contents Combine Setup Cereal Grain – Wheat. Oats,Barley • Mile-Grain-Sorgum • Dry Corn (< 20% Moisture) • High Moisture Corn (> 24% Moisture) • Soybeans • Canola/Rapeseed • Millet • Edible Beans • Sunflowers • Flax • Grass Seed (Bluegrass, Bentgrass) •... -
Page 4: Combine Setup
Combine Setup Cereal Grain - Wheat, Oats, Barley Initial Combine Setup 0.1”- 0.75” 0.375” Wheat 5 - 7 Fast Solid 0.2” (19 mm) (10mm) 0.1”- 0.75” 0.375” Oats 3 - 6 Fast Solid 0.2” (19 mm) (10mm) 0.1”- 0.75” 0.375” Barley 5 - 7 Fast... -
Page 5: Mile-Grain-Sorgum
Milo - Grain Sorghum Initial Combine Setup 0.625” 0.313” 450-600 0.2” -0.4” 5 - 7 Fast Solid (16mm) (8mm) Set concave to stem thickness just below head for starting point. • Run in low range of rotor gearbox for greater torque if possible (S8 •... -
Page 6: High Moisture Corn (> 24% Moisture)
High Moisture Corn (> 24% moisture) Initial Combine Setup Remove 0.625” lower 250-300 0.6” - 0.8” 5 - 7 Slow Solid (16 mm) * sieve * IMPORTANT: Set chaffer to achieve acceptable grain bin sample. • Opening chaffer can be done anytime. However, due to the nature of the electronics, closing the chaffer should be done at the end of the field after cleanout by completely opening and then closing to the lower number that you desire and then adjusting up to the desired chaffer... -
Page 7: Soybeans
Soybeans Initial Combine Setup 0.75” 0.375” 0.2” -0.4” 5 - 7 Fast Solid (19mm)* (10mm) • *Use suggested settings with standard chaffer or use .6" (15 mm) with corn chaffer Initial Header & Header Drive Setup Release and adjust cutterbar on flex headers. Adjust header height •... -
Page 8: Canola/Rapeseed
Canola/Rapeseed Initial Combine Setup 0.75” 0.375” 400-600 0.2” -0.4” 3 - 5 Fast Solid (19 mm) (10 mm) Initial Header & Header Drive Setup Variable speed header drive (if equipped) in slowest position for draper • headers and direct cut headers. Right-hand pivot drive belt positioned on large countershaft drive sheave. -
Page 9: Edible Beans
Initial Header & Header Drive Setup Variable speed header drive (if equipped) in slowest position for draper • headers and direct cut headers. Right-hand pivot drive belt positioned on large countershaft drive sheave. • Feed chains (front and rear) should be in high position and fast speed. •... -
Page 10: Sunflowers
Sunflowers Initial Combine Setup 0.625” 0.25” 0.4” 3 - 6 Fast Solid (16mm) (6mm) Initial Header & Header Drive Setup Header must be equipped with sunflower attachment to minimize headand • seed loss at the header. Variable speed header drive in slowest position. •... -
Page 11: Grass Seed (Bluegrass, Bentgrass)
Grass Seed (Bluegrass, Bentgrass) Initial Combine Setup 0.75” 0.157” 0.0”- 0.2” 0 - 2 ** Fast* Solid (19 mm)* (4 mm) * - If baling straw is preferred, set chopper to low speed. ** - The Light Seed Kit #700959206 can be installed and used for grass seed harvest but should be removed for any other crop. -
Page 12: Alfalfa
Alfalfa Initial Combine Setup 0.25”- 0.925” 0.1” 400 - 600 0.0” -0.3” 3 - 6 ** Fast* Solid (6 mm- (2.5 mm) 16mm) * - If baling straw is preferred, order impeller if needed. ** - The Light Seed Kit #700959206 can be installed and used for alfalfa seed harvest but should be removed for any other crop. -
Page 13: Industrial Hemp
• GLEANER does not offer a collection system for collecting flower. There are a couple systems out there. Contact your local dealer for assistance on flower collection, they can get in touch with AGCO for assistance... -
Page 14: Clover
Clover Initial Combine Setup 0.25”- 0.925” 0.1” 400 - 600 0.0” -0.3” 2 - 6 ** Fast* Solid (6 mm- (2.5 mm) 16mm) * - If baling straw is preferred, order impeller if needed. ** - The Light Seed Kit #700959206 can be installed and used for clover seed harvest but should be removed for any other crop. -
Page 15: Troubleshooting
Troubleshooting Header Ragged and uneven cutting of crop Possible Cause Correction Cutting mechanism not operating at Check basic speed of combineand recommended speed. check header drives. Reel speed too slow for groundspeed. Increase reel speed. Reel height too high. Lower reel. Reel position is either too far forwardor Adjust reel position so reel batshold too far back on reel arms. - Page 16 Header Shattering of grain ahead of cutter bar Possible Cause Correction Reel speed not coordinatedwith Change reel speed to coordinatewith ground speed. ground speed. Ground speed too fast for conditionof Decrease ground speed. crop. Reel height too low. Raise reel. Loss of grain heads and cut crop at cutter bar Possible Cause Correction...
- Page 17 Header Crop bunching on cutter bar Possible Cause Correction Reel too high. Lower reel. Reel too far forward. Set reel back. Reel speed too slow. Increase reel speed. Sticky header pan. Remove dirt, gum or rust. Conveyor too high. Lower header conveyor. Worn conveyor flighting.
- Page 18 Header Reel wrapping in tangled and weedy crops Possible Cause Correction Place reel ahead and down. Make sure reel tines clear the sickle with reel in Incorrect location of pickup reel. lowest position. Reel speed too fast. Reduce speed of reel. Pickup reel tines pitched too much to Adjust tine pitch.
- Page 19 Header Header conveyor plugging or material not moving from center of conveyor into front feed chain (Flex Header) Possible Cause Correction Straw retarder clearance from conveyor Adjust straw retarder. flight too great. Adjust reel height. Adjust reel speed and flow of material into header Reel not adjusted to provide smooth conveyor reel fore and aft positionfor flow of material into header conveyor.
-
Page 20: Feed Conveyer
Feed Conveyor Feeder chains plugging or wrapping Possible Cause Correction Refer to previous section on HEADER or CONVEYOR PLUGGING (PG. 15) Uneven feed from header. condition for header performance checks. Check feed chain drive sheave installation with grain header belts driving off larger sheave diameter. -
Page 21: Processor
Processor Slugging or overloading of cylinder Possible Cause Correction Adjust engine high idle to proper Engine not up to correct speed. speed. Check condition of belt and replace or clean if it becomes worn or oily.Check Cylinder drive belt slipping. and lubricate gearbox input torque sensor mechanism. - Page 22 Processor Cylinder vibration Possible Cause Correction Dirt and material stuck to insideof Clean material from inside of cylinder cylinder bars. bars. Place cylinder drive gearbox in neutral and operate cylinder drive through its variable speed range to determine if vibration is still present. If so, check the following: 1.
-
Page 23: Grain Quality
Grain quality Excessive cracked grain in grain tank Possible Cause Correction Crop too damp or green. Wait for crop conditions to improve. Cylinder speed too fast for crop grain Decrease cylinder speed just enoughto cracking but still do a good job. stop threshing. - Page 24 Grain quality Grain not threshed from heads or shelled from cob or pod Possible Cause Correction Decrease concave clearance and adjust cylinder speed to prevent Concave clearance too great. cracking. Increase cylinder speed enough to do good job of threshing. Do not increase Cylinder speed too slow.
- Page 25 Grain quality Foreign material in clean grain Possible Cause Correction Adjust engine high idle to proper Engine not up to correct speed. speed. Separator drive belt, fan drive belt, or Inspect drives, replace any damaged cleaning shoe drive belt slipping. belts and adjust idlers as required.
- Page 26 Grain quality Sieves plugging with straw and chaff Possible Cause Correction Insufficient air blast from cleaning fan. Increase fan choke setting. Consider increasing air, then decrease sieve opening in 0.06” (1.6 mm) Sieve opening too wide. increments. Decrease chaffer opening in 0.06”(1.6 Chaffer opening too wide.
-
Page 27: Grain Loss
Grain loss Excessive tailings Possible Cause Correction Increase sieve opening in 0.06” (1.6 Insufficient sieve opening. mm) increments. Insufficient air blast from cleaning fan. Increase fan choke setting. Consider increasing air, then decrease chaffer opening in 0.06” (1.6 mm) Chaffer opening too wide. increments. - Page 28 Grain loss Grain loss over cleaning shoe (cont.) Possible Cause Correction Round end, shallow tooth 1.125” (28.6 mm) shoe spacing - used in all crops except corn. Round end, deep tooth 1.625” (41.3 mm) spacing - generally used in corn but has also been found to provide desired cleaning in some crops such Incorrect chaffer for crop being...
-
Page 29: Loss Calculation
Loss Calculation “Quick check” for combine grain loss Spreading discharge Grain loss calculated per square foot across the entire field. To perform a quick estimate for total grain loss from the combine, count the number of seeds found in a square foot behind the combine. Determine the quantity of loss in at least three places throughout the field to arrive at an average. -
Page 30: Rotor Loss
Rotor loss Remove the straw spreader, the chaff spreader and raise the shoe tailboard so that shoe and rotor discharge remain separate. Count the grain in a one-foot run of the rotor discharge path, which is 24 inches wide to ensure that all grain is counted. •... -
Page 31: Advanced" Grain Loss Calculation Procedure
“Advanced” grain loss calculation procedure For the most accurate determination of grain lost through the combine harvester, grain must be “caught” directly from the rotor discharge separately from grain “caught” from the shoe discharge, and weighed. TABLE 3 - CALCULATED LOSS IN TOTAL WEIGHT OF GRAIN PER SWATH 15 ft. -
Page 32: Standard Payable Moisture & Density Chart
Standard Payable Moisture & Density Chart Alfalfa 12.0 Barley 14.0 Canola 10.0 Corn 15.5 Edible Beans 14.5 Flax Grass Seeds 12.0 Lentils 10.5 Millet 11.0 Mustard Navy Beans 14.5 Oats 14.0 Peas (Black-Eyed) 12.0 Peas (Field) 10.5 Popcorn (Yellow) 14.0 Popcorn (White) 14.0 Rape Seed... - Page 39 Notes • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ • _______________________________ •...
- Page 40 AGCO • 4205 River Green Parkway, Duluth, GA 30096 • Fax 770.813.6038 • gleanercombines.com AGCO may at any time, and from time to time, for technical or other necessary reasons, modify any of the data, specifications or warranty of the products described herein. Some equipment shown may be optional.
