Operator's Manual
Bale Wrapper
ATTIS PT 130
Wolfenbüttel
AGCO GmbH - Gebrüder-Welger-Straße 3 - D-38304
October 2018
Wolfenbüttel
4820.LE.EN01
LELY is a worldwide brand of AGCO
Issue: 1
© AGCO 2018
Original Operator's Manual
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LELY ATTIS PT 130 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AGCO LELY ATTIS PT 130

Summary of Contents for AGCO LELY ATTIS PT 130

  • Page 1 Operator's Manual Bale Wrapper ATTIS PT 130 Wolfenbüttel AGCO GmbH - Gebrüder-Welger-Straße 3 - D-38304 October 2018 Wolfenbüttel 4820.LE.EN01 LELY is a worldwide brand of AGCO Issue: 1 © AGCO 2018 Original Operator's Manual English...
  • Page 2 AGCO ®, or its dealers, accept no responsibility for variations which may be evident in the actual...

  • Page 3: Table Of Contents

    Table of contents Bale Wrapper 1 Safety ..............7 .
  • Page 4 Table of contents 2.5.2.1 Start up screens ........35 2.5.2.2 Main menu .
  • Page 5 Table of contents 6 Specifications ............81 .
  • Page 6 Table of contents Bale Wrapper 4820.LE.EN01...

  • Page 7: Safety

    Table of contents 1 Safety Safety icons ............. 9 Safety instructions .
  • Page 8 Table of contents Bale Wrapper 4820.LE.EN01...

  • Page 9: Safety Icons

    1. Safety GUID-A46B9917-F55D-4257-8730-D6404EEA23FB [V1] 1.1 Safety icons Safety warnings are shown with these icons: DANGER: This is an immediately dangerous situation which, if you ignore it, will cause death or injury. WARNING: An indication of a possible dangerous situation that can cause death or injury. It includes situations where the safety guards are removed, thus increasing the risk of death or injury.

  • Page 10: Safety Instructions

    1. Safety GUID-58DA6EDD-A05D-4B4C-82DE-8C1B3F82F0BC [V1] 1.2 Safety instructions YOU are responsible for the SAFE operation and maintenance of your machine. YOU must make sure that each person who operates or does work on the machine understands all the SAFETY data in this manual. YOU are the key to safety.

  • Page 11: Safe Driving

    1. Safety GUID-C35A84AB-7494-4739-ABC9-19396267E17D [V1] 1.2.2 Safe driving Read and understand the general safety instructions. Make sure that: • You always obey your local road traffic regulations and the speed limits • The machine is in the transport position • All parts that move are locked •...

  • Page 12: Safe Operation

    1. Safety • Do not change the machine • If it is necessary to replace parts, only use parts with manufacturer approval • Make sure that all covers and guards are in position and locked when you complete maintenance work. GUID-990C8397-1962-46DD-ACB6-9540147F86F5 [V1] 1.2.6 Safe operation Read and understand the general safety instructions then:...

  • Page 13: Safety Decals

    1. Safety GUID-A7D946C4-8BD5-4BDA-8E4E-09CE87D491A8 [V1] 1.3 Safety decals GUID-EFD74EDE-C61B-4808-ABAD-FEC51357EB26-high.jpg [High] Fig. 1 Bale Wrapper 4820.LE.EN01...
  • Page 14 1. Safety GUID-C62EA6AC-6F58-4D81-AE1D-5ADEF6B68A0B-high.jpg [High] Fig. 2 Bale Wrapper 4820.LE.EN01...
  • Page 15 1. Safety Decal Description Warning: Risk of injury and entanglement Keep out of the range of all machine parts that turn during operation. Warning: Risk of injury Keep out of the bale release area. A safe distance is more than 3 m. Lift point.

  • Page 16: Examine And Replace The Safety Decals And Notices

    1. Safety Decal Description Warning: Risk of Pinching Keep away from parts that compress. Warning: Pressurized device Release the pressure from the hydraulic and/or the pneumatic system before you do maintenance. Insert film roll. Hydraulic pressure. Warning: Risk of injury Do not step on the area! Lift eyes This symbol shows the location of the lift eyes.
  • Page 17 1. Safety 2. Make sure that the temperature of the installation surface is not less than 5 °C. 3. Find the correct position for the decal before you remove the protective paper. 4. Remove a small part of the cover paper. 5.

  • Page 18: Safety Devices

    1. Safety 1.4 Safety devices GUID-4AE531D8-2B8F-4AF3-ABE6-3FBDEB4E9E34 [V1] 1.4.1 Emergency stop button The emergency stop button is top right on the E-Link basic controller. The emergency stop button stops hydraulic and electrical power to the machine. GUID-C8E84CB8-F830-47FF-84D7-FA64A87779CA [V1] 1.4.2 Lock the transport wheel WARNING: Risk of injury or death This position must be install for road transport.

  • Page 19: Film Knife Cover

    1. Safety GUID-9C515FF0-6B46-41F6-8604-449DEBDDFC86 [V1] 1.4.4 Film knife cover A cover is on the machine to hold the knife in position. GUID-2C0D41EC-460E-40EF-AECC-529946431AE9-high.jpg [High] Fig. 5 GUID-1AAB9616-AC25-4951-87AE-BE1E06D4A48A [V1] 1.4.5 Cover for the chain drive There is a cover installed on the chain drive that stops access of personnel and objects to the components when in operation.

  • Page 20: Wheel Chocks

    1. Safety GUID-FA7F3371-DCA0-4974-95AC-7A90CEB62F94 [V1] 1.4.7 Wheel chocks When the machine is not in use or not connected to the tractor, the wheel chocks must be in position to stop the machine from sudden movement. GUID-61252C8C-99E0-4AE3-BD4C-AC6CD3D47149-high.jpg [High] Fig. 8 GUID-4BD18C34-A03B-4F76-9693-4A640714BB15 [V1] 1.4.8 Transport lock for bale end tipper The bale tipper has to be in its up position for transport.

  • Page 21: Valve To Lock Wrapper Table In Maintenance Position

    1. Safety GUID-ABF71276-6896-4B32-825E-C8E5EC63AD2A [V1] 1.4.10 Valve to lock wrapper table in maintenance position This safety valve is to lock the wrapper table in the maintenance position. Unlock Lock GUID-70BCE0D4-AE03-41E1-8765-A8D2F657F32A-high.jpg [High] Fig. 11 Bale Wrapper 4820.LE.EN01...
  • Page 22 1. Safety Bale Wrapper 4820.LE.EN01...

  • Page 23: Introduction

    Table of contents 2 Introduction Preface ..............25 2.1.1 Manual contents .
  • Page 24 Table of contents Bale Wrapper 4820.LE.EN01...

  • Page 25: Preface

    2. Introduction 2.1 Preface GUID-DA7EE6BA-4E1C-4352-A16F-10C3C1DA7D43 [V2] 2.1.1 Manual contents This manual contains the technical information, operating instructions, maintenance procedures and the troubleshooting information necessary to operate the machine. The information in this manual is for the operator. Make sure that you fully understand all the information before you operate the machine. If you do not, personal injury or damage to the equipment can occur.
  • Page 26 2. Introduction GUID-7024750B-34B2-463E-A491-50E74883C539-high.jpg [High] Fig. 2 Company name Maximum permissible vertical load on the Vehicle category pulling eye Type approval number (only shown if Maximum permissible load on axle 1 required by local legislation) trailer axle weight Vehicle Identification Number (VIN) Type name Maximum permissible weight, sum of all (10) Production and model year...

  • Page 27: Intended Use

    2. Introduction 2.2 Intended use GUID-57F28830-5700-4316-9523-4CBB6B62DD25 [V1] 2.2.1 Correct use The machine is for use only as a wrapper pulled and energized by a tractor and operated with a controller from in the tractor. The machine must only wrap bales compressed from grain crops, hay or silage from grasses which are on the ground of a field (= correct use).

  • Page 28: Descriptions

    2. Introduction 2.3 Descriptions GUID-429AC0E0-1F0A-4FEF-AAA8-54A5E6FD26A1 [V1] 2.3.1 General operation The machine moves when attached to the tractor and hydraulically operated by an E-Link module (6) attached to the tractor cab. The machine moves when: • The loading arm (1) lifts the bale up on to the wrapping table (2).

  • Page 29: Hydraulic System

    2. Introduction GUID-2C9355DC-351B-4F6F-8B9B-E11178124C76-high.jpg [High] Fig. 6 Device to stop use without approval for the Towing GUID-7D0D0BEC-4600-49B0-B315-59F84948D3F6 [V1] 2.3.4 Hydraulic system The functions of the machine operate hydraulically and controlled from the tractor through the E-Link manual controller. GUID-4D53E4A5-B6F6-4568-BD97-F90771D4B6A8 [V1] 2.3.5 Wrapping table The wrapping table turns the forage bale on all axis to put the bale in plastic layers.

  • Page 30: Film Cutter Assembly

    2. Introduction GUID-0DBC4D43-942D-4DA2-A645-3356908D5C7B [V1] 2.3.7 Film cutter assembly After the set number of turns the cutter arm (1) moves to one side to cut the plastic (2), it also holds the plastic film in position for the subsequent bales. GUID-E50C7C9B-1973-46BE-AEBA-DD5F886B513E-high.jpg [High] Fig.

  • Page 31: Extension Kit For 500Mm Film

    2. Introduction GUID-3501E78F-2B16-45E9-9BD4-CD2F0789DAD6 [V1] 2.3.9 Extension kit for 500mm film This extension kit changes the turn speed of the wrapping table rollers to accept film rolls with a width of 500 mm. The extension equipment is a gear wheel and a drive chain extension. An alternative gear wheel replaces the standard gear wheel to change the turn speed of the wrapping table rollers for correct overlap of the...

  • Page 32: Battery Extension Cable

    2. Introduction GUID-8486F8A6-2702-4FEB-AAE6-E91A2E5475F8 [V1] 2.3.12 Battery extension cable The battery cable set is an extension cable to connect the E-link to the tractor battery. GUID-4390B209-D0FA-4F02-9B8E-B07748E994E7 [V1] 2.3.13 Foot plate IMPORTANT: Damage to the machine Stop the tractor if the footplate touches the ground. The foot plate prevents the tipper frame to go down into the soft, wet ground and let the tipper frame operate correctly to remove the bale.

  • Page 33: Controller

    2. Introduction 2.4 Controller GUID-FCC11E3C-C7EF-4FA9-BE48-DF0B7A56C35C [V1] 2.4.1 E-link basic controller The E-Link Basic controller controls and monitors the machine. The E-link Basic Controller has an LCD display, four switches, five buttons and an emergency stop button. These features let personnel set and change values for the machine's operation. The LCD display also shows reports and errors for personnel to view.

  • Page 34: E-Link Basic Software

    2. Introduction 2.5 E-Link basic software GUID-405ADAD5-99C0-4CA6-8CF3-6DD13D9E8856 [V1] 2.5.1 Function of the buttons The E-Link basic controller has the buttons shown in the table below: Number Button/Switch Auto Function Manual Function Display. Emergency stop. Adds one turn to the total number of turns or temporarily stops the count operation for the number of turns.

  • Page 35: Start Up Screens

    2. Introduction The buttons let personnel move through the screens. After approximately five seconds the E- link will go to the usual screen (screen 1). NOTE: Use the buttons as shown to move through the menu structure. The sections in this chapter show personnel how to use and set the menus, use the quick reference charts to see the full function of the interface structure.

  • Page 36: Third Calibration Menu (Cal.3)

    2. Introduction Procedure Push the button to set the E-link Basic to OFF . Push the button and keep pushed in to select the calibration menu. Turn the button to set the E-link Basic to ON. NOTE: You have five seconds to complete the subsequent step. Release the button in less than five seconds from when you turn the E-link Basic ON to start the second calibration menu.

  • Page 37: Operation

    Table of contents 3 Operation First use ..............39 3.1.1 Adjust the height of the drawbar pull eye .
  • Page 38 Table of contents Bale Wrapper 4820.LE.EN01...

  • Page 39: First Use

    3. Operation 3.1 First use GUID-82508BE6-AED0-466D-B2E8-9945515E197E [V1] 3.1.1 Adjust the height of the drawbar pull eye WARNING: Risk of injury or death. Before you make adjustments, you must turn the engine to OFF. Procedure Remove the two fasteners from the drawbar pull eye.

  • Page 40: Adjust The Bale End-Tipper

    3. Operation Adjust the position of the film holder (3) until the installation holes align with the centre of the bale. Make sure that you install the film holder (3) tightly in position. Remove the cover of the gear wheel housing.

  • Page 41: Adjust The Bearings Adjust Plate

    3. Operation GUID-8DFFD26C-8532-491A-AD58-5CDF890D3747 [V1] 3.1.4 Adjust the bearings adjust plate Procedure Release the fasteners of the adjust plate (1) and the roller bearings (2) on the right side of the trailer. Adjust plate Roller bearings 16 mm 22 mm 28 mm Correct roller belt tension GUID-1224FE13-2233-4414-9D7D-F3E738498BB4-high.jpg [High] Fig.

  • Page 42: Adjust The Film Stretch

    3. Operation Interchange the gear wheels (6) and (7) with the gear wheels (4) and (5): ° To increase the length of the film by 55% use the gear wheels with 39 and 60 teeth. ° To increase the length of the film by 70% use the gear wheels with 37 and 62 teeth. Make sure that the gear wheels and the rollers turn smoothly.
  • Page 43 3. Operation Push and hold the switch to the DOWN position to start the wrapper table. Calculate the number of 360 degree turns necessary to wind film around the full surface of the bale: ° (AA + 1) x BB = YY °...

  • Page 44: Connect The Machine To The Tractor

    3. Operation 3.2 Connect the machine to the tractor GUID-E2108A56-8C49-4E69-9AF9-CA367E692638 [V1] 3.2.1 Connect the machine to the tractor WARNING: Risk of sudden movement. Always stop the engine and remove the ignition key when you exit the tractor. WARNING: Risk of ejected high pressure oil. The pressure of the tractor hydraulic system must not be more than 210 bar Procedure Adjust the drawbar pull eye to make sure...

  • Page 45: Calculate The Maximum Permitted Vertical Load On The Coupling Point

    3. Operation Connect the safety towing chain between the machine and the tractor. Remove the dust caps from the two hydraulic hoses. Connect the 3/8" hydraulic hose to a single- acting hydraulic valve on the tractor. Connect the 1/2" hydraulic hose to a connection without pressure on the tractor.
  • Page 46 3. Operation Procedure Find the A-0 value on the VIN plate of the baler. Find the S-value on the type plate of the ball-head / towing eye. Find the value of the permitted load from the hitch of the tractor. From these three values, take the lowest value.

  • Page 47: Transport Position And Driving

    3. Operation 3.3 Transport position and driving GUID-9759C6B2-49E7-4926-BEF7-751375EC0A02 [V1] 3.3.1 Transport position of the bale end tipper (optional) Procedure Always transport the machine with the bale tipper set to the transport (upright) position. GUID-D0E372F7-BC44-469B-AB07-2CE3389B847F-high.jpg [High] Fig. 15 Hold the bale tipper with the bracket and lock it safely with the two pins.

  • Page 48: Place Or Remove The Wheel Chocks

    3. Operation Move the loading arm to the transport position. Turn "OFF" the E-link basic controller. Switch "OFF" the engine and remove the ignition key. GUID-AD2B8C15-0114-4094-A44F-189784645E90-high.jpg [High] Fig. 18 Install the lock pin in to the loading arm, and install the R-clip. Turn "OFF"...
  • Page 49 3. Operation IMPORTANT: Make sure that you remove the wheel chocks before you start to move with a machine connected. Put the wheel chocks in the special storage containers on the machine. NOTE: Make sure that the clips hold the wheel chocks correctly.

  • Page 50: Prepare The Machine To Wrap

    3. Operation 3.4 Prepare the machine to wrap GUID-8C9FAB59-5C63-4629-9908-248E1E3E87B7 [V1] 3.4.1 Move to the working position. CAUTION: Make sure that there are no persons in the area when you do this procedure. Procedure Remove the clip (1) and lock pin (2) from the loading arm and stow them in the transport position hole.

  • Page 51: Replace A Film Roll

    3. Operation If you have a bale tipper attached, move it to the working position. a) Remove the two pins and disconnect the bale tipper bracket. b) Lower the bale tipper to the ground. c) Replace the bracket in the working position and attach with the two pins.
  • Page 52 3. Operation Pull and turn the film lock handle counterclockwise to disengage the film roll. Remove the used film and film roll and then replace with a new item. GUID-0F63B778-969F-45AB-B512-FFC5BF4B65FB-high.jpg [High] Fig. 27 Put the new film roll in the centre of the film holder. Turn the film lock handle clockwise.
  • Page 53 3. Operation Disengage the film lock 1 and let the dispenser 2 move to the film roll. GUID-49C7A6EC-58C2-4280-97D3-661FFB436DCF-high.jpg [High] Fig. 30 Attach the film to the eye bracket on the wrapping table. IMPORTANT: Do not attach the film to the film cutter.

  • Page 54: Operate The Machine

    3. Operation 3.5 Operate the machine GUID-26F01CA6-3067-41A5-BA08-A57ACC0FF15D [V1] 3.5.1 Before you operate the machine Procedure Before you operate the machine: • Make sure that all first use procedures are done. • Make sure that the maintenance is done. • Make sure that all covers are closed and locked in position. •...

  • Page 55: Start Wrapping Manual Mode

    3. Operation NOTE: The wrapping table turns to the loading position automatically after it stops. GUID-57D23296-5642-4B58-86C3-1CC8493963A8 [V1] 3.5.1.2 Start wrapping manual mode You cannot adjust the machine parameters in automatic mode. Set the E-Link Basic control to manual mode to adjust the parameters. Procedure Change to manual mode a) Push the button...

  • Page 56: Shut Down Procedure On The Field

    3. Operation Procedure NOTE: The bale end-tipper sets the bale on its end after release. This will decrease the risk of damage to the bale film and stops the bale from sudden movements. Install the optional bale end-tipper to the machine if operated on slopes frequently. When the machine is in operation without the bale end-tipper always release bales in a perpendicular direction to the slope.

  • Page 57: Disconnect The Machine From The Tractor

    3. Operation 3.6 Disconnect the machine from the tractor GUID-5119662E-306D-4A97-93F6-545BEACF6847 [V1] 3.6.1 Park the machine WARNING: Risk of sudden movement. Always stop the engine and remove the ignition key when you exit the tractor. Procedure Park the machine on solid ground before you disconnect it from the tractor. Collect the wheel chocks from the storage area of the machine and put them behind the transport wheels.

  • Page 58: Take The Machine Out Of Operation

    3. Operation GUID-F19E2B32-E1F1-4EB5-BBFE-688F6ACCCB2D [V1] 3.6.3 Take the machine out of operation. WARNING: Risk of injury or death. Make sure that there are no persons in the area when you do this procedure. Procedure Move the transport wheel and loading arm to the transport position.

  • Page 59: Maintenance And Lubrication

    Table of contents 4 Maintenance and lubrication Prepare the machine to do maintenance ........61 Preventative maintenance schedule .
  • Page 60 Table of contents Bale Wrapper 4820.LE.EN01...

  • Page 61: Prepare The Machine To Do Maintenance

    4. Maintenance and lubrication GUID-0CF02619-3A2B-4578-8B2D-BEC6A3C577EF [V1] 4.1 Prepare the machine to do maintenance WARNING: Risk of contact with dangerous materials. Put on the correct Personal Protective Equipment (PPE) when you use lubricants and oils. Lubricants and oils are dangerous to health and the environment. WARNING: Risk of personal injury.
  • Page 62 4. Maintenance and lubrication Put wheel chocks against the wheels. Disconnect the machine from the tractor. Clean the machine. GUID-61252C8C-99E0-4AE3-BD4C-AC6CD3D47149-high.jpg [High] Fig. 3 Release the pressure in the hydraulic system. GUID-BA5EA653-53BA-4726-B8A4-90E8094AE83C-high.jpg [High] Fig. 4 Bale Wrapper 4820.LE.EN01...

  • Page 63: Preventative Maintenance Schedule

    4. Maintenance and lubrication GUID-6B99D912-28DB-4A66-B110-FCEC139AB61D [V1] 4.2 Preventative maintenance schedule 50 hours 100 Monthly After Before Other hours Operation Extended Storage Lubricate the bearings of the wrapping table rollers. Lubricate the loading arm hinges. Lubricate the stretcher unit gearwheels. Lubricate the parking jack. Lubricate the gearwheels below the wrapping table rollers.

  • Page 64: Lubrication Chart

    4. Maintenance and lubrication GUID-C69BE714-735E-4E18-BC05-F917AE95ECE0 [V1] 4.3 Lubrication chart WARNING: Risk of contact with dangerous materials. Put on the correct Personal Protective Equipment (PPE) when you use lubricants and oils. Lubricants and oils are dangerous to health and the environment. WARNING: Risk of personal injury.

  • Page 65: Lubricate The Machine

    4. Maintenance and lubrication GUID-A1DEE467-0212-4530-AFBC-46D0F34B3E74 [V1] 4.4 Lubricate the machine GUID-4570770A-B7C9-41A0-AC2D-A714B9221009-high.jpg [High] Fig. 5 Transport Wheel Hinge Parking Jack Wrapping Roller Bearings (x4) Loading Arm Hinges (x3) Stretcher Unit Gearwheels (x4) Loading Arm Hinge Bale Wrapper 4820.LE.EN01...

  • Page 66: Lubricate The Wrapping Table

    4. Maintenance and lubrication GUID-0A308F50-3BE0-44DE-8762-63821EE2E7D2 [V1] 4.4.1 Lubricate the wrapping table GUID-E2E471D5-1BCB-4463-8787-3EE65C1361F4-high.jpg [High] Fig. 6 Wrapping table cylinder Wrapping table hinge GUID-D29605EE-A4AE-493F-BA73-008692C31C86 [V1] 4.4.2 Lubricate the gear wheels of the transmission WARNING: Risk of contact with dangerous materials. Put on the correct Personal Protective Equipment (PPE) when you use lubricants and oils. Lubricants and oils are dangerous to health and the environment.

  • Page 67: Lubricate The Drive Chain Of The Wrapping Table Rollers

    4. Maintenance and lubrication Apply Molykote BR2 plus grease to the gearwheels. GUID-325DB636-3EF1-48C5-9AE4-C82DC208F429-high.jpg [High] Fig. 8 Install the cover plate on the gearbox. Install the three bolts on the gearbox cover. GUID-664AF55C-DC72-44BC-AE9D-18D615CEA2C1-high.jpg [High] Fig. 9 GUID-1B4AFAA1-7FDE-4DC2-B5D3-DF3327D11429 [V1] 4.4.3 Lubricate the drive chain of the wrapping table rollers WARNING: Risk of injury Put on the correct Personal Protective Equipment (PPE) when you use lubricants and oils.
  • Page 68 4. Maintenance and lubrication Remove the drive chain housing from the machine. GUID-D63B5D35-AE37-4793-B048-E87B2FCF573D-high.jpg [High] Fig. 11 Lubricate the drive chain with GX85-W140 transmission oil. GUID-F7324E6E-61F6-4266-A619-99A8674FA8D1-high.jpg [High] Fig. 12 Install the drive chain housing on the machine. GUID-D63B5D35-AE37-4793-B048-E87B2FCF573D-high.jpg [High] Fig. 13 Install the two bolts on the drive chain housing.

  • Page 69: Adjust The Chain Tension

    4. Maintenance and lubrication GUID-8AB4AA57-3E18-4DAC-8FD9-F159F5C2BB4C [V1] 4.5 Adjust the chain tension Procedure Remove the two bolts from the drive chain housing. GUID-F0791CD5-855D-46A3-9FAE-B28635F0C2CC-high.jpg [High] Fig. 15 Remove the drive chain housing from the machine. GUID-D63B5D35-AE37-4793-B048-E87B2FCF573D-high.jpg [High] Fig. 16 Loosen the nut on the chain tensioner. Put 70 Nm of force on the drive chain tensioner.
  • Page 70 4. Maintenance and lubrication Install the drive chain housing. GUID-D63B5D35-AE37-4793-B048-E87B2FCF573D-high.jpg [High] Fig. 18 Install the two bolts on the drive chain housing. GUID-F0791CD5-855D-46A3-9FAE-B28635F0C2CC-high.jpg [High] Fig. 19 Bale Wrapper 4820.LE.EN01...

  • Page 71: Measure The Oil Pressure In The Accumulator

    4. Maintenance and lubrication GUID-C252FEC7-67F2-4AD3-8EBA-4148100192FF [V1] 4.6 Measure the oil pressure in the accumulator Procedure Open the film cutter. GUID-E031BBEB-44D4-4422-AB1A-700331734BEE-high.jpg [High] Fig. 20 Connect the hose of the oil pressure pump to the quick coupling of film cutter cylinder. Set the oil pressure pump to ON. Measure the oil pressure in the accumulator: •...

  • Page 72: Examine The Hydraulic Hoses For Damage And Leaks

    4. Maintenance and lubrication GUID-8E1604DE-76AE-4C03-96B0-2571AEC2C744 [V2] 4.7 Examine the hydraulic hoses for damage and leaks CAUTION: Risk of injury from hydraulic fluids that can go through skin. Use a piece of cardboard and DO NOT use your fingers, face or other body parts to examine for leaks.

  • Page 73: Replace The Film Knife

    4. Maintenance and lubrication GUID-949342A4-EBE7-47FF-A7F6-2CE1279A1CAE [V1] 4.8 Replace the film knife CAUTION: Risk of injury Put on protective gloves when the knives are changed. Procedure Open the film cutter. Remove the fasteners from the spring shaft of the film cutter. GUID-DEEF1BD7-93C7-4E67-993A-AC3FC4333DDA-high.jpg [High] Fig.
  • Page 74 4. Maintenance and lubrication Remove and discard the old knife from the machine and replace it with a new knife. GUID-676ABD38-41B0-40F5-BAE3-DBAAB5038926-high.jpg [High] Fig. 26 Install the two bolts and the knife holder to attach the knife to the machine. GUID-2C0D41EC-460E-40EF-AECC-529946431AE9-high.jpg [High] Fig.

  • Page 75: Clean The Machine

    4. Maintenance and lubrication GUID-F473A270-7A55-43D8-975E-2980AD5F5B22 [V1] 4.9 Clean the machine WARNING: Risk of contact with dangerous materials. Put on the correct Personal Protective Equipment (PPE) when you use lubricants and oils. Lubricants and oils are dangerous to health and the environment. IMPORTANT: Equipment Damage.

  • Page 76: Torque The Nuts Of The Transport Wheel

    4. Maintenance and lubrication GUID-141ADDC5-1374-4FE3-AA84-E6C197DB0329 [V1] 4.10 Torque the nuts of the transport wheel Procedure Put the machine on flat and level ground. Put the wheel wedges in position. In the correct sequence shown, torque the transport wheel nuts to the specified torque. Wheel Nut Torque 270 Nm GUID-093381B8-158C-404E-8BCE-4C6F043802AE-high.jpg [High]...

  • Page 77: Troubleshooting

    Table of contents 5 Troubleshooting Replace the transport wheel ..........79 The wrapping table turns too quickly .
  • Page 78 Table of contents Bale Wrapper 4820.LE.EN01...

  • Page 79: Replace The Transport Wheel

    5. Troubleshooting GUID-EA6B9B7B-6E1D-44D0-9F65-1C105AD02703 [V1] 5.1 Replace the transport wheel WARNING: Risk of injury Make sure that there are no persons in the area when you move the machine to the transport position. Procedure Push button and lower the loader arm to the ground. Make sure that the transport wheel is not in contact with the ground.

  • Page 80: The Wrapping Table Turns Too Quickly

    5. Troubleshooting GUID-7339E600-AD14-49E2-9530-E44089070EAA [V1] 5.2 The wrapping table turns too quickly Cause: An alarm operates to tell you that the wrapper table rotates too quickly. Solution: Decrease the speed of the wrapper table. Use flow valve or decrease oil flow from tractor. Bale Wrapper 4820.LE.EN01...

  • Page 81: Specifications

    Table of contents 6 Specifications Dimensions ............83 Specifications .
  • Page 82 Table of contents Bale Wrapper 4820.LE.EN01...

  • Page 83: Dimensions

    6. Specifications GUID-BD93DFDB-5134-44DA-82B7-98ABAA9E5CA9 [V1] 6.1 Dimensions The dimensions will change because of the type of tyres and the installed height of the drawbar head. See the table for the maximum dimensions. GUID-3C2B7501-7E54-47C2-BA90-9CF51A7D7AC7-high.jpg [High] Fig. 1 Bale Wrapper 4820.LE.EN01...
  • Page 84 6. Specifications Item Dimension Maximum Width (A) * 3718 mm Length (B) 6040 mm Height (C) (loader arm down) 2180 mm Height (D) 2266 mm Dimensions * If necessary for local law, the machine will have marks to identify the width when B exceeds 2,55m. Bale Wrapper 4820.LE.EN01...

  • Page 85: Specifications

    6. Specifications GUID-836D0F0A-B5D4-44F9-B69C-97778454C18D [V1] 6.2 Specifications technical data Transport length 4720 mm Transport width 2540 mm Transport height 2300 mm Bale diameter 900 mm - 1300 mm Bale width 1250 mm Bale weight 1000 kg Maximum permitted weight on draw bar (A-0) 500 kg Maximum permitted weigh on axle (A-1) 1950 kg...

  • Page 86: Shipment

    6. Specifications 6.3 Shipment GUID-F07ABCBD-8127-4409-8A7F-36A295AAE128 [V1] 6.3.1 Lift the machine WARNING: Risk of injury Make sure that no persons are near or below the machine when you lift it. IMPORTANT: Damage to the machine Make sure that you use applicable lift equipment attached to specified hard points. There are two lift eyes at the rear of the machine and a hard point at the front of the machine on the drawbar.

  • Page 87: Attach The Machine To A Truck

    6. Specifications GUID-1AA95066-BF5E-41BD-ADD3-F4F8F8398211-high.jpg [High] Fig. 4 To make sure that you lift safely use applicable equipment that obeys the specifications. Before you lift the machine: • The machine must be empty • Lock all parts correctly to prevent movement • Make sure that there is sufficient space for the machine •...

  • Page 88: Disposal

    6. Specifications GUID-003B700F-54C1-44C3-A009-A7C6C02D6A71 [V1] 6.4 Disposal Disposing this machine correctly will help save valuable resources and prevent any potential negative effects on human health and the environment, which could otherwise arise from inappropriate waste handling. Decommissioning and disassembly of the machine can be dangerous and must be done only by qualified recycling organizations.

  • Page 89: Quick Reference Charts

    Table of contents 7 Quick reference charts Main menu ............. 91 Second calibration menu (CAL.2) .
  • Page 90 Table of contents Bale Wrapper 4820.LE.EN01...

  • Page 91: Quick Reference Charts 7.1 Main Menu

    7. Quick reference charts GUID-C93860EF-E0C3-4186-A3A7-73E047643AB5 [V1] 7.1 Main menu The main menu is in six sections with a display screen for each section. This will let personnel: • set the number of turns (wraps) to complete a wrapped bale. • set/reset the field counter. •...
  • Page 92 7. Quick reference charts GUID-82A83042-005D-4AE3-827A-89F0CF4499BD [V1] 7.2 Second calibration menu (CAL.2) To access the second calibration menu follow the procedure below: Procedure Push the button to set the E-link Basic to OFF . Push the button and keep pushed in to select the calibration menu. Turn the button to set the E-link Basic to ON.
  • Page 93 7. Quick reference charts GUID-BA46DCC7-562E-43D3-A48E-99CF9B46C63F [V1] 7.3 Third calibration menu (CAL.3) To access the third calibration menu follow the procedure below: Procedure Push the button to set the E-link Basic to OFF . Push the button and keep pushed in to select the calibration menu. Turn the button to set the E-link Basic to ON.
  • Page 94 7. Quick reference charts Bale Wrapper 4820.LE.EN01...
  • Page 95 Index Index accumulator pressure ..........71 Operation adjustments ........39–42 adjust chain tension ..........attach the machine ........... 87 preface ..............prepare for maintenance .......... 61 bale end tipper ............public road transport safety ........11 bale tipper ............20, 47 before operate machine ...........
  • Page 96 Index Bale Wrapper 4820.LE.EN01...
  • Page 98 © AGCO Corporation, 2018. All rights reserved. 4820.LE.EN01 (English) October 2018...
