Omron CPM1A Operation Manual page 50

Specifications
CPU Unit and Expansion I/O Unit Output Specifications
Relay Outputs
Item
Max. switching capacity
Min. switching capacity
Service life of relay
ON delay
OFF delay
Circuit configuration
Pre-V1 Units
500
300
200
100
50
30
20
10
5
3
2
0.1 0.2 0.3 0.5 0.7
2 A, 250 VAC (cosφ = 1)
2 A, 24 VDC
(4 A/common)
10 mA, 5 VDC
Electrical: 150,000 operations (resistive load, 24 VDC) 100,000 operations (inductive
load, 220 VAC, cos φ=0.4)
Mechanical for pre-V1 Units: 10,000,000 operations
Mechanical for V1 Units: 20,000,000 operations
15 ms max.
15 ms max.
Note 1. The service life of relay output contacts shown in the table assumes the
worst conditions. The following graph shows the results of OMRON's ser-
vice life tests at a switching rate of 1,800 times/hour.
2. The CPM1A-20EDR Expansion I/O Unit with Relay Outputs does not con-
form to the EC Directives. Use the CPM1A-20EDR1 or CPM1A-8ER Expan-
sion I/O Unit, which has the CE marking, when conformance to EC Direc-
tives is required.
120 VAC, resistive load
24 VDC, τ = 7 ms
120 VAC, cosφ = 0.4
240 VAC, cosφ = 0.4
24 VDC/240 VAC, resistive load
Switching rate:
1,800 times/hour
1 2 3 5
Contact current (A)
Specification
Output
LED
Internal
Circuits
V1 Units
Section 2-1
OUT
OUT
COM Maximum
250 VAC: 2 A
24 VDC: 2 A
120 VAC, resistive load
24 VDC, τ = 7 ms
120 VAC, cosφ = 0.4
240 VAC, cosφ = 0.4
24 VDC/240 VAC, resistive load
Switching rate:
1,800 times/hour
Contact current (A)
27
