Summary of Contents for asecos ION Series
- Page 1 EP.V.35874.00 | 12.2023 EP.V.35857.00 | 12.2023 USER MANUAL Safety storage cabinets for storage and charging of lithium ion batteries...
- Page 2 ION-PRO-90 ION-CORE-90 IO90.195.120.PC.WDC IO90.195.120.PS.WDC IO90.195.060.CC.WDC IO90.195.120.CS.WDC IO90.195.060.CS.WDC...
- Page 3 YOUR PERSONAL DOCUMENTATION TO THE asecos SAFETY CABINET Dear Customer, you have made a decisive investment in safety for your company by purchasing this asecos safety storage cabinet. You now own an innovative product made of top-quality materials guaranteeing the highest quality standards.
-
Page 4: Table Of Contents
1. NOTES • GUIDELINES • GUARANTEE ......... . .5 1.1. -
Page 5: Notes • Guidelines • Guarantee
The guarantee for this product is agreed between you (the customer) and your dealer (the seller). As the manufacturer, asecos guarantees the products listed in the operating instructions for a period of 24 months from the date of delivery. All model safety equipment are subject to a compulsory annual inspection by spe- cialised staff authorised by the manufacturer. -
Page 6: Transport
2. TRANSPORT CAUTION: Transport the cabinet in an upright position on a pallet truck, tied and secured against slipping, until the final place of installation is reached.The transport locks in the door joints may only be removed directly at the place of installation! Inappropriate transport can lead to concealed damage to the fire protection insulation! We can only guarantee the necessary quality if the cabinet is transported to the place of its use by our specially trained staff. -
Page 7: In-Plant Transport
2.3. IN-PLANT TRANSPORT • In-plant transport is also possible without transport locks (inserted as standard in the door joints) ATTENTION with cabinets including extraction unit: The doors must be locked prior to transport! The extraction unit is inside the cabinet and is only mounted after the in-plant transport to the place of use. -
Page 8: Commissioning
4. COMMISSIONING • Before putting into operation for the first time, the user must carry out an examination of the safety storage cabinet for possible damage, such as defective or loose sealing elements, correct alignment and perfect func- tioning of the door elements. Use the cabinet and accessories only if they are in an orderly condition. -
Page 9: Ion-Pro-90: Self-Test
4.2. ION-PRO-90: SELF-TEST Starts 5 seconds after connection to the mains supply 4.3. ION-PRO-90: INSTALLATION OF THE EXTRACTION UNIT 4.4. ION-PRO-90: POTENTIAL-FREE ALARM CONTACT NOTE: The potential-free alarm contact is used to connect a signal to a control centre/control room. Direct integration into a fire alarm control panel (FACP) is not recommended or may only be carried out in consul- tation with the person responsible for the system. -
Page 10: Ion-Core-90: Potential-Free Alarm Contact
4.5. ION-CORE-90: POTENTIAL-FREE ALARM CONTACT NOTE: The potential-free alarm contact is used to connect a signal to a control centre/control room. Direct integration into a fire alarm control panel (FACP) is not recommended or may only be carried out in consul- tation with the person responsible for the system. -
Page 11: Shelves (Height-Adjustable)
Version other regions: fusing 16 A 10 A 13 A 16 A Please get in touch with your asecos contact person. The maximum power and protection may differ here. max. total power 3,68 kW 2,3 kW 2,99 kW 3,68 kW Optional: 3-phase, 400 V (accessories article 38038) Note on model with a width of 600 mm IO90.195.060.CC.WDC: Only 2 of the 3 connected phases are... -
Page 12: Storage
7. STORAGE 7.1. GENERAL INFORMATION ON BATTERIES ATTENTION: Never store obviously damaged lithium-ion batteries inside buildings. Dispose of them without delay in disposal containers that are provided outside the building and approved for transport. CAUTION Only batteries with a maximum output of 2 kW and a maximum weight of 15 kg may be stored in the cabinets. -
Page 13: Ion-Core-90: Smoke Detector
9. ERROR • FALSE ALARMS 9.1. ERROR DURING SELF-TEST ATTENTION: After pressing the reset button, the self-test begins again. If the error persists, please contact the asecos Service department. 9.2. FALSE ALARM OF THE SMOKE DETECTOR •... -
Page 14: Alarm Overview
10. ALARM OVERVIEW 10.1. ION-PRO-90: ERROR AND ALARM OVERVIEW EVENT LED GREEN LED RED ACOUSTIC ALARM ACTIONS Error during self-test turned on 5 signal tones 1.) Restart with RESET button if error persists: 2.) Contact Service Service interval reached flashing Contact Service Power failure Flashes every 20 seconds... -
Page 15: Warning Message
11.1. WARNING MESSAGE >50 °C if connected • Actions Immediate visual inspection of the system by the company’s own qualified personnel. Initiation of necessary actions. If the interior temperature falls below 50 °C, the system returns to normal operation and the visual and acous- tic signals are switched off. -
Page 16: Alarm Stage 2
CE conformity are maintained. For this purpose, the cabinet must be handed over to the main factory of asecos GmbH in Gründau, where the specialist department - depending on the degree of damage - will make an assessment of the economic efficiency and technical possibilities of a repair. -
Page 17: Opening The Cabinet After The Fire
This annual check can be carried out with the necessary care, and for securing your warranty claims in the case of fire, only by an authorised asecos employ- ee (refer also to our service brochure regarding this). -
Page 18: Ion-Core-90: Smoke Detector Maintenance
In the case of defects or complaints about our products (within and also after the warranty period), and for requesting safety checks or taking out a service contract, please contact our service hotline on: Tel: +44 1785 22 70-90 | info@asecos.co.uk (for great Britain and Ireland) Tel: +49 1805 92 20 92 | service@asecos.com (international) -
Page 20: Technical Data
14. TECHNICAL DATA ION-PRO-90 IO90.195.120.PC.WDC IO90.195.120.PS.WDC Type External dimensions W x D x H 1193 x 615 x 2224 mm 1193 x 615 x 1953 mm Internal dimensions W x D x H 1050 x 522 x 1647 mm 1050 x 522 x 1647 mm Weight without interior equipment Distributed load kg/m²... -
Page 21: Ion-Core-90
15.2. ION-CORE-90 (155) (155) (155) Fresh air Exhaust air DN 75 Exhaust air DN Exhaust air DN Fresh air Fresh air IO90.195.060.CC.WDC IO90.195.120.CS.WDC IO90.195.060.CS.WDC... - Page 22 +34 935 745911 +34 935 745912 info@asecos.es asecos Ltd. asecos asecos Schweiz AG asecos AB Safety and Environmental Protection Safety and Environmental Protection Inc. Sicherheit und Umweltschutz Säkerhet och miljöskydd Profile House c/o Schumann Burghart LLP Gewerbe Brunnmatt 5...
