USER MANUAL
Gas cylinder cabinets
according to EN 14470-2
5 YEARS WARRANTY
Upon conclusion of an asecos service
and maintenance agreement (BasicPlus
tari ) with a fixed term of 5 years, you
will get a warranty extension for a
maximum of 5 years for your safety
storage cabinet.
For detailed information about our
warranties please visit:
5
Years
Warranty
*
Advertisement
Table of Contents
Related Manuals for asecos G-CLASSIC-30 G30.205.140
Summary of Contents for asecos G-CLASSIC-30 G30.205.140
- Page 1 EP.V.34173.00 | 10/2023 5 YEARS WARRANTY Upon conclusion of an asecos service and maintenance agreement (BasicPlus tari ) with a fixed term of 5 years, you will get a warranty extension for a maximum of 5 years for your safety storage cabinet.
- Page 2 G-CLASSIC-30 G30.205.140 G30.205.120 G30.205.090 G30.205.060 G30.205.060.R G-ULTIMATE-90 G90.205.140 G90.205.120 G90.205.090 G90.205.060 G90.205.060.2F G90.205.060.R G90.205.060.2F.R G90.145.060 G90.145.060.R...
- Page 3 YOUR PERSONAL DOCUMENTATION TO THE asecos SAFETY CABINET Dear Customer, you have made a decisive investment in safety for your company by purchasing this asecos safety storage cabinet. You now own an innovative product made of top-quality materials guaranteeing the highest quality standards.
-
Page 4: Table Of Contents
Many thanks Your asecos team 1. NOTES • GUIDELINES • GUARANTEE ......... . .5 1.1. -
Page 5: Notes • Guidelines • Guarantee
The guarantee for this product is agreed between you (the customer) and your dealer (the seller). As the manufacturer, asecos guarantees the products listed in the operating instructions for a period of 24 months from the date of delivery. All model safety equipment are subject to a compulsory annual inspection by spe- cialised sta authorised by the manufacturer. -
Page 6: Tilting The Cabinet
2.2. TILTING THE CABINET CAUTION: Tilting the cabinet may only be done without jolts! 3. ERECTION • COMMISSIONING • FUNCTION 3.1. ALIGNMENT OF THE CABINETS 3.2. COMMISSIONING • Before putting into operation for the first time, the user must carry out an examination of the safety storage cabinet for possible damage, such as defective or loose sealing elements, correct alignment and perfect func- tioning of the door elements. -
Page 7: Opening Of Double Wing Door
4.2. OPENING OF DOUBLE WING DOOR G-ULTIMATE-90 G-CLASSIC-30 5. INTERIOR FITTINGS 5.1. MOUNTING RAILS • for fittings for pressurised gases, height-adjustable 5.2. CYLINDER RETAINER [A] G-ULTIMATE-90 [B] G-CLASSIC-30 a permanently mounted on the rear wall b tension belts for securing the gas cylinders c adjustable in depth (G-ULTIMATE-90) -
Page 8: Cylinder Retainer Sidewall
Adjustable in depth with G-ULTIMATE-90 Cylinder retainer G90.205.060.2F 4× 4× 5.3. CYLINDER RETAINER SIDEWALL SIDE CYLINDER RETAINER (adjustable without tools) • is hooked into a mounting rail and is adjustable in height SIDE CYLINDER RETAINER (bolted) = 4 mm = 20 mm •... -
Page 9: Shelf And Heavy Duty Grid
STANDARD COMFORT 5.5. SHELF AND HEAVY DUTY GRID The shelf or heavy duty grid will be installed in the factory at a height of 1100 mm. Special positions are possible but require prior technical clarifications as well as the creation of a chargeable approval / assembly drawing. -
Page 10: Drill Holes And Drilling Distances
6.3. DRILL HOLES AND DRILLING DISTANCES The drill hole may be drilled max. 1 mm larger than the outer diameter of the pipeline or electric cable used. The pipeline or cable can be routed through the cabinet ceiling without any further insulation measures. Example •... -
Page 11: Storage
7. STORAGE • The total volume of the stored gas cylinders must not exceed 210 l + 10 l (purging gas cylinder). Applicable for all models: Depending on the type class of the cabinet, observe the respective valid national regulations! 8. -
Page 12: Grounding Premium
Legende A 1 × screw M6×30 E 1 × nut with clamping part B 4 × washer Ø 6,4 F earthing wire with ring cable lug (on-site C 2 × spring washer Ø 6,4 connection) D 2 × serrated lock washer Ø 6,4 G metal part of the safety storage cabinet 8.2. -
Page 13: Montage Of Fire Protection Sleeve
PROTECTION VALVES NOTE for mounting the fire protection collars, ventilation nozzles and fire protection valves The fire protection collars, ventilation nozzles or fire protection valves are not mounted at the factory for transport reasons and are included with the cabinet. ›... -
Page 14: Fire • Disposal
11.1. WEARING PARTS Various safety-related components of the safety storage cabinet are wearing parts and must be replaced at regular intervals by asecos Service. A list of the parts a ected for your safety cabinet is available on request from service@asecos.com. -
Page 16: Technical Drawing
12. TECHNICAL DRAWING Top view Top view Top view Earthing link Earthing link Earthing link Pipe lead-through area Pipe lead-through area Pipe lead-through area Exhaust air DN 75 Fresh air Exhaust air DN 75 Fresh air Exhaust air DN 75 Fresh air Ø75 1206 1006... -
Page 17: Technical Data
13. TECHNICAL DATA Key for “Technical data” table External dimen- Internal dimen- Type Weight of empty Maximum load Distributed load Air change 120 sions W x D x H sions W x D x H cabinet times G-LINE type 90 kg/m²... - Page 18 +34 935 745911 +34 935 745912 info@asecos.es asecos Ltd. asecos asecos Schweiz AG asecos AB Safety and Environmental Protection Safety and Environmental Protection Inc. Sicherheit und Umweltschutz Säkerhet och miljöskydd Profile House c/o Schumann Burghart LLP Gewerbe Brunnmatt 5...
