Summary of Contents for asecos V-MOVE-90
- Page 1 EP.V.31417.04 | 08/2024 10 YEARS WARRANTY Upon conclusion of an asecos service and maintenance agreement (PREMIUM tari ), you will get a warranty extension for up to 10 years for your V-LINE safety storage cabinet. USER MANUAL Years Safety storage cabinets according to EN 14470-1...
- Page 2 V-MOVE-90 V90.196.081.VDAC:0012 V90.196.081.VDAC:0013 V90.196.045.VDAC:0012 V90.196.045.VDAC:0013...
- Page 3 YOUR PERSONAL DOCUMENTATION TO THE asecos SAFETY CABINET Dear Customer, you have made a decisive investment in safety for your company by purchasing this asecos safety storage cabinet. You now own an innovative product made of top-quality materials guaranteeing the highest quality standards.
-
Page 4: Table Of Contents
Many thanks Your asecos team 1. NOTES • GUIDELINES • GUARANTEE ......... . .5 1.1. -
Page 5: Notes • Guidelines • Guarantee
The guarantee for this product is agreed between you (the customer) and your dealer (the seller). As the manufacturer, asecos guarantees the products listed in the operating instructions for a period of 24 months from the date of delivery. All model safety equipment are subject to a compulsory annual inspection by spe- cialised sta authorised by the manufacturer. -
Page 6: Marking And Symbols On The Cabinet
1.4. MARKING AND SYMBOLS ON THE CABINET Various stickers with di erent symbols are attached to the cabinet. An explanation of the individual symbols and illustrations is provided below. Prohibition sign: No open Mandatory sign: Refer to Mandatory sign: Keep doors Recommendation: Connec- flame instruction manual/booklet... -
Page 7: Dismantling Of The Transport Packaging
2.2. DISMANTLING OF THE TRANSPORT PACKAGING 2× 2× 4× 5× 2.3. IN PLANT TRANSPORT CAUTION: The cabinet must not be moved by pulling the opened drawer! Pulling or sliding may only be carried out in the body housing! Steps for manoeuvring the cabinet: •... -
Page 8: Connection To The Power Supply
3.2. CONNECTION TO THE POWER SUPPLY CAUTION The cabinet must be connected to the power supply at least 1 hour before storing items for the first time! 3.3. ALIGNMENT OF THE CABINETS After disabling the automatic door closing (see 4.4) and opening the drawer, the cabinet can be aligned using the integrated adjusting aids. -
Page 9: Locking Of The Cabinet
NOTES to figures 4 and 5 Only one vertical drawer can be opened at a time while the other one remains closed. 3.4. LOCKING OF THE CABINET 3.5. UNLOCKING OF THE CABINET 3.6. AUTOMATIC DOOR CLOSING SYSTEM TSA... -
Page 10: Disable The Automatic Door Closing System
3.7. DISABLE THE AUTOMATIC DOOR CLOSING SYSTEM >3 sec ATTENION: In case of fire the automatic door closing is always ensured! 4. SAFETY FUNCTIONS 4.1. AUTOMATIC CLOSING IN THE EVENT OF FIRE 47 °C 4.2. BLOCKING THE DRAWER WHILE OPENING Release blockage CAUTION If no direct user intervention occurs after the blockage, the cabinet will give an acoustic and visual alarm... -
Page 11: Blocking The Drawer While Cosing
4.3. BLOCKING THE DRAWER WHILE COSING Release blockage CAUTION If no direct user intervention occurs after the blockage, the cabinet will give an acoustic and visual alarm after 20 seconds. In that case, please remove the blockade and follow the previous steps! 4.4. -
Page 12: Emergency Unlocking In The Event Of A Power Failure
fire. To ensure safety in the event of a fire, the vertical pull-out must be pushed fully into the cabinet by hand. The self-closing function in the event of fire must be repaired immediately by asecos Service. -
Page 13: Surcharge Top Mounted Cabinet
6. SURCHARGE TOP MOUNTED CABINET The V-LINE safety storage cabinets can be loaded if the cabinet was ordered with article HF.L.32864 (order no. 38275). These cabinets are then structurally adjusted at the factory and additionally marked on the outside as load-bearing. head section rear CAUTION: head section front... -
Page 14: Interior Fittings
7. INTERIOR FITTINGS 7.1. BOTTOM COLLECTING SUMP In accordance with EN 14470-1:2023-09 (point 5.7): A bottom collecting sump/drawer tray must be installed below the lowest centre level. The bottom collecting sump/drawer tray must have a minimum collection volume of 10 % of all containers stored in the cabinet [1], or at least 110 % of the volume of the largest individual container [2], whichever is greater. -
Page 15: Storage
To install the second safe guard rail system on the opposite side, follow the steps from point 6 again. Pay attention to the correct use of the required brackets. 8. STORAGE • Vessels containing aggressive chemicals (acids and alkalis) are to be kept in special cabinets for acids and al- kalis or on shelves for acids and alkalis as well as in safety storage cabinets with metal-free interior equipment. -
Page 16: Ventilation
Legende A 1 × screw M6×30 E 1 × nut with clamping part B 4 × washer Ø 6,4 F earthing wire with ring cable lug (on-site C 2 × spring washer Ø 6,4 connection) D 2 × serrated lock washer Ø 6,4 G metal part of the safety storage cabinet 10. -
Page 17: Safety Checks
12.3. WEARING PARTS Various safety-related components of the safety storage cabinet are wearing parts and must be replaced at regular intervals by asecos Service. A list of the parts a ected for your safety cabinet is available on request from service@asecos.com. -
Page 18: Technical Data
13. TECHNICAL DATA 13.1. TABLE WITH TECHNICAL DATA In general V90.196.045.VDAC V90.196.081.VDAC Type External dimensions W x D x H 449 x 860 x 1966 819 x 860 x 1966 Internal dimensions W x D x H 331 x 775 x 1750 701 x 775 x 1750 Weight without interior equip. - Page 20 +34 935 745911 +34 935 745912 info@asecos.es asecos Ltd. asecos asecos Schweiz AG asecos AB Safety and Environmental Protection Safety and Environmental Protection Inc. Sicherheit und Umweltschutz Säkerhet och miljöskydd Profile House c/o Schumann Burghart LLP Gewerbe Brunnmatt 5...
