- Page 1 EP.V.34172.00 | 04/2023 USER MANUAL 10 YEARS WARRANTY Upon conclusion of an asecos service and Safety storage cabinets according to EN 14470-1 maintenance agreement (PREMIUM Q tari ), you will get a warranty extension for up to 10 BEDIENUNGSANLEITUNG years for your Q-LINE safety storage cabinet.
- Page 2 Q-CLASSIC-15 Q-CLASSIC-30 Q15.195.116 Q15.195.056 Q30.195.116 Q30.195.086.WD Q30.195.056 Q15.195.056.R Q30.195.116.FU.WDAS Q30.195.086.WDR Q30.195.056.R Q30.195.086.FU.WDAS Q30.195.056.FU.WDAS Q30.195.086.FU.WDASR Q30.195.056.FU.WDASR Q-DISPLAY-30 Q30.195.086.WDFW Q-CLASSIC-90 Q90.195.120 Q90.195.090 Q90.195.060 Q90.195.120.MV Q90.135.120 Q90.195.120.FU.WDAS Q90.195.090.FU.WDAS Q90.195.060.R Q90.195.120.MM Q90.195.060.FU.WDAS Q90.195.060.FU.WDASR Q90.195.120.ME.WDC Q-PHOENIX-90 Q-PEGASUS-90 Q90.195.120.FD Q90.195.060.FD Q90.195.120.WDAC Q90.195.090.WDAC Q90.195.060.WDAC Q90.195.060.WDACR...
- Page 3 YOUR PERSONAL DOCUMENTATION TO THE asecos SAFETY CABINET Dear Customer, you have made a decisive investment in safety for your company by purchasing this asecos safety storage cabinet. You now own an innovative product made of top-quality materials guaranteeing the highest quality standards.
-
Page 4: Table Of Contents
Many thanks Your asecos team 1. NOTES • GUIDELINES • GUARANTEE ......... . .5 1.1. -
Page 5: Notes • Guidelines • Guarantee
The guarantee for this product is agreed between you (the customer) and your dealer (the seller). As the manufacturer, asecos guarantees the products listed in the operating instructions for a period of 24 months from the date of delivery. All model safety equipment are subject to a compulsory annual inspection by spe- cialised sta authorised by the manufacturer. -
Page 6: Marking And Symbols On The Cabinet
1.4. MARKING AND SYMBOLS ON THE CABINET Various stickers with di erent symbols are attached to the cabinet. An explanation of the individual symbols and illustrations is provided below. Prohibition sign: No open Mandatory sign: Refer to Mandatory sign: Keep doors Recommendation: Connec- flame instruction manual/booklet... -
Page 7: Dismantling Of The Transport Packaging
2.3. DISMANTLING OF THE TRANSPORT PACKAGING = 8× = 4× 2.4. IN PLANT TRANSPORT • In-plant transport is also possible without transport locks (inserted as standard in the door joints) 4× ATTENTION Q-LINE type 90, width 600 mm The clearance drive-in width of the base is 520 mm. Q-LINE type 15/30, width 560 mm The clearance drive-in width of the base is 406 mm. -
Page 8: Q-Mover
2.6. Q MOVER • Order no. 30037, available from your authorised dealer a: upright transport b: upright transport through standard doors (headroom 1986 ± 2mm) 4× CAUTION: Written notification of any damage to the cabinet must be given immediatly! 3. ERECTION • COMMISSIONING • FUNCTION 3.1. -
Page 9: Commissioning
After alignment, the transport base can be closed with an optionally available base cover. Cabinet width 1193 mm 893 mm 599 mm Order No. 30036 30069 30112 Q-CLASSIC-15/30 with adjusting aids in plinth 4× max. 2× (!) After alignment, the transport base can be closed with an optionally available base cover. Cabinet width 1164 mm 864 mm... -
Page 10: Opening And Closing Mechanisms
4. OPENING AND CLOSING MECHANISMS 4.1. OPENING THE CABINET Q LINE Manual opening of the individual doors Q CLASSIC 15 Q CLASSIC 30 For two-door cabinets: Manual opening of both doors with only one hand. The cabinet is equipped with AGT. with door version WDC with door version WDAS Q DISPLAY 30... -
Page 11: Interior Fittings
Sequence Changing the closing times with the aid of the jumper 1: 15 sec 2: 60 sec 3: 4.5 min Battery replacement =4× =4× =4× CAUTION: The electrical cable on the housing may not come into contact with the locking linkage of the cabinet! 5. -
Page 12: Perforated Insert
CAUTION: The height of metal-free tray shelves in safety storage cabinets may only be adjusted on site by authorized asecos employees, as further pre-assembly work is necessary for this! 5.6. GRID SHELVES HEIGHT ADJUSTABLE... -
Page 13: Drawers
5.7. DRAWERS Q-LINE models with carcase width 120 or 90 cm (version without dividing wall) Before first use and loading, the bottom drawer must be additionally secured against unintentional removal. Securing the lowest drawer against possible lifting out CAUTION: Depending on the number, the drawers are installed at the factory in fixed positions in the cabinet. Subject to technical feasibility, special classifications are possible at an additional cost. -
Page 14: Storage Box
CAUTION: The height of the drawers in safety storage cabinets may be adjusted only by authorised asecos employees, since the safe retraction of the drawers in case of fire must be guaranteed! 5.8. -
Page 15: Leaks
5.9. LEAKS PLEASE NOTE Liquid in the bottom collecting sump / drawer and in the sump of pull-out tray, must be taken up immedi- ately and using suitable means. The choice of the means is your own responsibility, depending on the leaked chemical. -
Page 16: Ground Connection
7.1. GROUND CONNECTION All models have an earthing connection. The cabinet body (side and top panels) is metallically conductively connected to each other via the earthing connection. The earthing connection is prepared for the creation of the potential equalisation on site. •... -
Page 17: Ventilation
This annual check can be carried out with the necessary care, and for securing your warranty claims in the case of fire, only by an authorised asecos employ- ee (refer also to our service brochure regarding this). -
Page 18: Wearing Parts
10.2. WEARING PARTS Various safety-related components of the safety storage cabinet are wearing parts and must be replaced at regular intervals by asecos Service. A list of the parts a ected for your safety cabinet is available on request from service@asecos.com. -
Page 20: Technical Drawing
11. TECHNICAL DRAWING (155) (155) (155) (155) Exhaust air DN Exhaust air DN Fresh air Fresh air Fresh air Exhaust air DN 75 1007 Q90.195.120 Q90.195.120.MV Q90.195.090 Q90.195.090.FU.WDAS Q90.195.060 Q90.195.060.R Q90.195.120.MM Q90.195.120.FU.WDAS Q90.195.090.WDAC Q90.195.060.FU.WDAS Q90.195.060.FU.WDASR Q90.195.120.WDAC Q90.195.120.ME.WDC Q90.195.060.WDAC Q90.195.060.WDACR Q90.135.120 (155) (155) Exhaust air DN 75... -
Page 21: Technical Data
12. TECHNICAL DATA 12.1. TABLE WITH TECHNICAL DATA The surface load is calculated by dividing the total weight of the cabinet (empty cabinet plus load) by its loading area. This is calculated by multiplying the width of the cabinet by the depth (sum of the depth of the cabinet and 1000 mm of space in front of it). - Page 22 12.2. TABLE WITH STORAGE CAPACITIES Legend for “Storage capacities” table Load capacity (kg) of storage levels Retention capacity (ltr.) Maximum container volume in the cabinet (ltr.) Q-LINE Interior equipment 1 shelf 5 perforated insert 9 bottom collecting sump 2 tray shelf 6 drawer 10 Metal-free bottom collecting sump 3 Tray shelf, metal-free...
